Configuration manual
System Parameters
The configuration of the Previdia Compact control panel, its interfaces and external connections provides for the settings
of a series of parameters reachable from the control panel by accessing control panel programming (paragraph 2.2) and
then pressing the Configuration button on the menu shown on the screen.
Once inside the Configuration menu (paragraph 2.3), the control panel screen will show an image of the control panel
frontplate highlighting the access buttons to the configuration sections.
3.1

General parameters of the control panel

Tapping on the appropriate icon inside the control panel configuration screen accesses the configuration
section of some of the control panel parameters.
The available parameters are:
• Panel name, editable field for the description of the
control panel
• Mains failure delay, field for the delay (expressed in
minutes) which must pass between detection of mains
failure by the control panel and mains failure signalling
• Disable buzzer, option that, if activated, disables the
control panel buzzer
• Direct alarm on second prealarm, option that, if
activated, generates an alarm signal as soon as two
detectors go into prealarm status, regardless of the zone
they belong to. Otherwise the alarm condition will
activate at the end of the first prealarm time.
The Esc and Set buttons will allow you to exit the section
without changing the programming or saving it.
3.2

Configuring the Ethernet network

If an Ethernet network connection is used, it will be necessary to set up the IP address and parameters of the network.
This operation must be carried out for each of the Previdia control panels and repeaters connected to the Ethernet
network via LAN cable.
To set the network parameters you must enter the programming phase of the control panel (paragraph 2.2)
and then tap on the appropriate icon inside the control panel configuration screen.
The available parameters are:
• IP address
• Netmask
• Gateway
• Port
The Esc and Set buttons will allow you to exit the section
without changing the programming or saving it.
System Parameters
Previdia Compact
060 Mains failure delay (min)
Disable buzzer
Direct alarm on second prealarm
Access level:3
IP 192 168
Net mask 255 255
Gateway 192 168
Port 6001
Access level:3
Chapter 3
Panel name
Esc
Set
1 121
255 0
1 1
Esc Set
11
