PAS Ratio Settings

To modify the value of PAS ratio, press the "+" button or "-" button to choose the

desired value, and then press the "i" button to confirm

For example, the range is "50 percent" of "1" level, bottom value can be modified, and

the default value is 50 percent.

To store the modified setting, press the "i" button and turn to the next PAS ratio

settings.

After all PAS ratio inputted, hold the "i" button for 2s to confirm and then return to

previous menu.

Please refer to Attached list 2.

Set Current represents controller over-current cut settings. The current value can be

changed from 7.0A to 25.0A.

To change basic settings, press the "+" or the "-" button to increase or decrease the

value of the current.

To store a changed setting, hold the "i" button and then return to previous menu.
