◆Battery Indicator

The five battery bars represent the capacity of the battery.The five battery bars bright
when the battery is in high voltage. When the battery is in low voltage, battery frame will
flash at the frequency of 1HZ to notice that the battery needs to be recharged immediately.

◆Motor Power Indicator

The power of the motor can be read via the interface.
◆USB connection indication (optional)
When the display is inserted into a USB external device, the display interface will
show as below.

Assistance Level Conversion Interface

Battery Indicator

Motor Power Indication Interface
