Summary of Contents for Key-Disp KD58C
-
Page 2: Table Of Contents
Contents Product name and model ....................... 1 Specifications ............................1 Appearance and Size ........................1 Function and Button Definition ...................... 2 ◆Function Summary ........................2 ◆Function Layout......................2 ◆Button Definition ........................2 Install Instructions..........................2 General Operation ........................... 2 ◆Switching the E-bike System On/Off................... 2 ◆Display Interface........................2 ◆Switching Push-assistance mode On/Off................3 ◆Switching the Lighting On/Off.................... - Page 3 Power-on Password Enable/Disable................10 Power-on Password Change....................10 ◆Exit settings..........................10 Recover default settings.......................11 Quality assurance and warranty scope..................11 Connection layout..........................12 Warnings............................12 Attached list 1 Error code definition.................... 13 Attached list 2 Assist level ratio defaults................13...
-
Page 4: Product Name And Model
Product name and Model Electric Bicycle Intelligent Display, Model: KD58C. Specifications ● 24V/36V /48V Power Supply ● Rated current: 10mA ● The maximum working current: 30mA ● Off-state leakage current: <1μA ● Working temperature: -20 ~ 60 ℃ ● Storage temperature: -30 ~ 70 ℃... -
Page 5: Function And Button Definition
ON/OFF, UP, DOWN to represent these 3 symbols ( Install Instructions KD58C can be mounted on the left side of handlebar close to its grip. Adjust the angle for a good screen view. Cut off the power before connecting the corresponding connectors between display and controller. -
Page 6: Switching Push-Assistance Mode On/Off
Display indication cycle interface ◆Switching Push-assistance Mode On/Off To activate the push-assistance function, press and hold the DOWN button. After 2 seconds, the E-bike will go on at a uniform speed of 6 Km/h and “P” is shown on the screen at the same time. -
Page 7: Power Indicator
Assist Level “4” ◆Power Indicator The output power of the motor can be indicated by below interface. Motor Power Interface ◆Error code Indication The components of the E-bike system are continuously and automatically monitored. When an error is detected, the respective error code is indicated in text indication area. Refer to the detailed definition of the error codes in Attached list 1. -
Page 8: Trip Distance Clearance
General Settings interface ◆Trip Distance Clearance Clear Trip means trip distance clearance. Press the UP or DOWN button to choose YES or NO. The default value is NO. To clear a trip, choose YES and press the ON/OFF button to confirm. The screen says 'OK' and returns to the G eneral Settings interface. -
Page 9: Speed Limit Settings
◆Speed limit Settings Set LS represents speed limit settings. When current speed is faster than speed limit, the E-bike system will be switched off automatically. Limited speed range is 12Km/h to 40Km/h. The default value is 25Km/h. To change basic settings, press UP/DOWN to increase or decrease until the desired value is displayed. -
Page 10: Assist Level Settings
Personalized parameter settings Interface ◆Assist Level Settings Power Set means assist level settings Power assist Level mode In assist level settings, there are 8 modes for your choice: 0-3, 1-3, 0-5, 1-5, 0-7, 1-7, 0-9, 1-9. The default value is 0-5. To select the mode of assist level, press UP/DOWN to increase or decrease until the desired mode is displayed. -
Page 11: Controller Over-Current Cut Settings
◆Controller Over-current Cut Settings Current Set represents controller over-current cut settings. The current value can be changed from 7.0A to 25.0A. To change basic settings, press the “+” or the “-” button to increase or decrease the value of the current. To store a changed setting, press the “ON/OFF”... -
Page 12: Slow Start Up Settings
Speed Sensor Settings ◆Slow Start up Settings Slow Start represents slow start up. The range is 1-4 seconds. 4 is the slowest. To change slow start up settings, press the UP or DOWN button to change the value and press the ON/OFF button to confirm. The screen says 'OK' and return to previous menu. -
Page 13: Power-On Password Settings
◆Power-on Password Settings Password Set represents power-on password settings. The default password is 1212. When the screen shows P2:0000, you need to input the current password or the default password”1212”. Press UP/DOWN to change the numbers and press ON/OFF to confirm digits one by one until the correct 4-digit password is completed. -
Page 14: Exit Settings
◆Exit settings In the settings state, Press the ON/OFF button to confirm the input. Hold the ON/OFF button for 2s to save the settings and then exit the current settings. Hold the DOWN button for 2s to cancel the operating but not to store the settings, and then return to previous menu. -
Page 15: Connection Layout
4. Have the display repaired when it does not work properly. ▉This manual instruction is a universal version for DISPLAY KD58C. Some versions of this display may be different from specification to specification as to the software. -
Page 16: Attached List 1 Error Code Definition
Attached list 1: Error code definition Error Code Definition Current Abnormality Throttle Abnormality Motor Phase Abnormality Motor Hall Signal Abnormality Brake Abnormality Communication Abnormality Attached list 2：Assist level ratio defaults Level level mode 0-3/1-3 — — — — — — 0-5/ 1-5 —...
Need help?
Do you have a question about the KD58C and is the answer not in the manual?
Questions and answers
I can not get the unit to power on at all. Battery is fully charged and turned on.
The Key-Disp KD58C may not power on despite a fully charged battery due to several reasons:
1. Power-on Password Enabled: If the power-on password is enabled, you must enter the correct password to turn on the display.
2. Connection Issues: Ensure the connector is properly linked and secure, as improper connection can prevent power from reaching the display.
3. Error Codes: Check for any error codes on the display (e.g., Error Code 30 for communication abnormality) that may indicate a malfunction.
4. Display Malfunction: If the display is not functioning properly, it may need repair.
If all these checks are in order and the display still does not power on, consider troubleshooting the electrical connections or seeking repair.
This answer is automatically generated
My KD58C display only goes to P4 and the password request. I can’t get into the settings as none of the suggested passwords work.
To reset the password for the Key-Disp KD58C display, follow these steps:
1. Access the settings by holding the ON/OFF button for 2 seconds.
2. Navigate to the power-on password settings (P2:0000).
3. Use the UP/DOWN buttons to modify the digits of the password.
4. Press the ON/OFF button to confirm each digit until the new 4-digit password is entered.
5. Once the password is set, press the ON/OFF button to save and exit.
If you are unable to recall the existing password, you may need to recover default settings by:
1. Pressing the UP and ON/OFF buttons simultaneously for 2 seconds.
2. Selecting Y (Yes) using the UP/DOWN buttons to confirm resetting to default settings.
3. Holding the ON/OFF button for 2 seconds to reset, returning the password to its default value (1212).
