INSTALL ON PINS 2 AND 3
SEE NOTE 2
1
NOTES:
1. ASSEMBLE PER IPC-A-610 AND/OR PANAMETRICS STANDARD 957-002.
2. R19 NOT INSTALLED (SPECIALS ONLY).
3. ALL UNINSTALLED COMPONENT HOLES TO BE SOLDER FREE.
4. DISCARD LOCKWASHER AND NUT ON S2 (DO NOT INSTALL).
5. INSTALL P6 WITH LONGER LEADS INTO PCB AS SHOWN FOR PROPER STACKUP WITH MATED ASSEMBLY.
SOLDER MUST BE FLUSH TO BOARD. DO NOT CUT, TRIM OR TIN EXCESS LEADS.
6. INSTALL CHASSIS GROUND WIRE ON THE BOTTOM SIDE OF THE PCB. APPLY LOCTITE 416 INSTANT
ADHESIVE AND LOCTITE 7452 ACCELERATOR OR EQUIVALENT TO TACK WIRE TO PCB.
XMTC User's Manual
78
78
INSTALL ON PINS 2 AND 3
P8
P7
78
P4
68
TB1A
70
TB1B
INSTALL ON PIN1 ONLY
71
TB2B
69
TB2A
ASSEMBLY TOP

Appendix C. Installation and Wiring Diagrams

SEE NOTE 5
GROUPS
NO. DESCRIPTION
01 STANDARD
02
03
02
TC
