Appendix E. CE Mark Compliance
E.2 EMI Filter Board
For CE compliance, an EMI filter board has been added to the XMTC (see Figure 88 below). This board is connected
internally to terminal block
EMI filter board. The RS232 digital output connections are made to terminal block
CAUTION!
EMI Filter Board Mounting Screw
94
TB1
. The power and analog output connections are now made to terminal block
Do not make any connections to unassigned or unused terminals.
Figure 88: XMTC with EMI Filter Board - Wiring Connections
TB2-3 = RS232 GND (green)
TB2-2 = RS232 TX (white)
TB2-1 = RS232 RX (red)
TB3-4 = -4 to 20 mA (green)
TB3-3 = +4 to 20 mA (white)
TB3-2 = 24VDC Return (black)
TB3-1 = +24VDC Line (red)
TB3 Side View

EMI Filter Board

TB2 Side View
TB2
.
XMTC User's Manual
TB3
