1.4.3 4-Port (Flowing Reference Gas) Version

This optional configuration shown in Figure 3 below is used for zero-suppressed ranges and some other special
applications. Typically, a flowing reference gas of 100% H
are available:
Ranges: 90 to 100%
80 to 100%
Note: For factory calibration pricing on the standard ranges and gases, or for pricing on other zero-suppressed
ranges and gases, please consult the factory.
XMTC User's Manual
Gases: H
CO
He in N
Figure 3: 4-Port (Flowing Reference Gas) XMTC
or CO is used. The following standard ranges and gases
2 2
in N
2 2
in N or air
2 2
or air
2
