SET COMMUNICATION:

This section defines the fundamental communication parameters of two buses, J1939 and CAN.
By pressing the "Set Communication" button from the main window for SW67439 (Fig. 2) the
window "Set Communication Setting" appears (Fig. 3).
The meaning of the fields of "J1939" are:
In the field "Baudrate" the data rate of J1939 bus is defined;
In the field "TimeOut Data
side will be set to '0xFF';
If the field "Enable Peer to
PGNs inserted in the section "Receive J1939";
In the field "Device ID
The meaning of the fields of "CAN" are:
In the field "Baudrate" the data rate of CAN bus is defined.
ADFweb.com Srl – IT31010 – Mareno – Treviso
(s)" a time is defined. When this time is expired, the data on CAN
Peer" is checked, the gateway accepts all the IDs that have the
J1939" the J1939 address for the converter is defined.
User Manual J1939 / CAN - Converter
Document code: MN67439_ENG Revision 1.101 Page 16 of 33
Page 16 of 33
Figure 3: "Set Communication" window
