Industrial Electronic Devices

User Manual

Revision 1.101

English

CAN / Modbus TCP Master – Converter

(Order Code: HD67414)

For Website information:

www.adfweb.com?Product=HD67414

For Price information:

www.adfweb.com?Price=HD67414

Benefits and Main Features:

Very easy to configure

Wide supply input range

Electrical isolation

Industrial temperature range:

-40°C / 105°C (-40°F / 221°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

Axis Solutions Pvt Ltd is the Authorized Distributor of

www.axisindia.in | info@axisindia.in

User Manual CAN / Modbus TCP Master - Converter

Document code: MN67414_ENG

For other Gateways / Bridges:

CAN from/to Modbus

Need help?

Do you have a question about the HD67414 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67414

Page 1 Revision 1.101 Page 1 of 28 Industrial Electronic Devices User Manual Revision 1.101 English CAN / Modbus TCP Master – Converter (Order Code: HD67414) For Website information: www.adfweb.com?Product=HD67414 For Price information: www.adfweb.com?Price=HD67414 Benefits and Main Features: For other Gateways / Bridges:...
Page 2 User Manual CAN / Modbus TCP Master - Converter Document code: MN67414_ENG Revision 1.101 Page 2 of 28 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page INDEX Updated...
Page 3 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 3 of 28 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 4 of 28 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 5 of 28 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67414-E4x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 6 of 28 Industrial Electronic Devices Figure 1b: Connection scheme for HD67414-E7x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7 Industrial Electronic Devices CHARACTERISTICS: The “HD67414” series are rugged devices used to interface CAN devices with Modbus TCP Slaves. With his particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal, vertical, oblique).
Page 8 POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax HD67414-Exx-xx Consumption at 24V DC: Device W/VA HD67414-Exx-xx Caution: Not reverse the polarity power HD67414-E4x-xx HD67414-E7x-xx Note: It is possible to use also negative tensions.
Page 9 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 9 of 28 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
Page 10 Industrial Electronic Devices CAN: The connection of the CAN in the HD67414-E4x-xx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page. The connection of the CAN in the HD67414-E7x-xx device must be made with a AMP SuperSeal 1.5 Male connector.
Page 11 ETHERNET: The connection of Ethernet in the HD67414 device must be made with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable.
Page 12 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 12 of 28 Industrial Electronic Devices USE OF COMPOSITOR SW67414: To configure the Converter, use the available software that runs with Windows called SW67414. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 13 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 13 of 28 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “CAN / Modbus TCP Master - Converter”...
Page 14 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 14 of 28 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 15 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 15 of 28 Industrial Electronic Devices SET COMMUNICATION: This section defines the fundamental communication parameters of two Buses, CAN and Modbus TCP. By pressing the “Set Communication” button from the main window for SW67414 (Fig. 2) the window “Set communication”...
Page 16 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 16 of 28 Industrial Electronic Devices COB REQUEST: By pressing the “COB Request” button from the main window for SW67414 (Fig. 2) the window “Define Modbus TCP Request in Read” appears (Fig.
Page 17 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 17 of 28 Industrial Electronic Devices In the field “Max Error” the number of consecutive errors that the Master waits before discarding the row from the cycle of requests is defined;...
Page 18 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 18 of 28 Industrial Electronic Devices COB SETTING: By pressing the “COB Setting” button from the main window for SW67414 (Fig. 2) the window “Define Modbus TCP Request in Write” appears (Fig.
Page 19 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 19 of 28 Industrial Electronic Devices For example: If we want to write the Holding Register (Fig. 6) we must send a CAN frame with COB ID=$0020 and 8 bytes of data (Fig.
Page 20 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 20 of 28 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Connect the USB cable;...
Page 21 Page 21 of 28 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67414 device. Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67414 device.
Page 22 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 22 of 28 Industrial Electronic Devices MECHANICAL DIMENSIONS: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 23 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 23 of 28 Industrial Electronic Devices Type A ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 24 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 24 of 28 Industrial Electronic Devices Type B ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 25 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 25 of 28 Industrial Electronic Devices Type C ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 26 Page 26 of 28 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67414 – E y z – s f Fixing lugs A: Type A B: Type B C: Type C...
Page 27 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 27 of 28 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 28 User Manual CAN / Modbus TCP Master Document code: MN67414_ENG Revision 1.100 Page 28 of 28 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
