CAN / MQTT – Converter

(Order Code: HD674-A038)

For Website information:

www.adfweb.com?Product=HD674-A038

For Price information:

www.adfweb.com?Price=HD674-A038

Benefits and Main Features:

Isolation between two buses

Temperature range: -40°C / +105°C (-40°F / +221°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual CAN / MQTT - Converter

Document code: MN674-A038_ENG

For other Gateways / Bridges:

CAN from/to Modbus

Need help?

Do you have a question about the HD674-A038 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD674-A038

Page 1 Revision 1.000 Page 1 of 36 Industrial Electronic Devices User Manual Revision 1.000 English CAN / MQTT – Converter (Order Code: HD674-A038) For Website information: www.adfweb.com?Product=HD674-A038 For Price information: www.adfweb.com?Price=HD674-A038 Benefits and Main Features: For other Gateways / Bridges: Isolation between two buses CAN from/to Modbus Temperature range: -40°C / +105°C (-40°F / +221°F)
Page 2: Table Of Contents
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 2 of 36 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page INDEX Updated...
Page 3: Security Alert
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 3 of 36 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4: Example Of Connection
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 4 of 36 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5: Connection Scheme
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 5 of 36 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD674-A038-E4x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 6 of 36 Industrial Electronic Devices Figure 1b: Connection scheme for HD674-A038-E7x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7: Characteristics
Industrial Electronic Devices CHARACTERISTICS: The “HD674-A038” series are rugged devices used to interface CAN devices with a MQTT network. With his particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal, vertical, oblique).
Page 8: Power Supply
POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax HD674-A038-Exx-xx Consumption at 24V DC: Device W/VA HD674-A038-Exx-xx Caution: Not reverse the polarity power HD674-A038-E4x-xx HD674-A038-E7x-xx Note: It is possible to use also negative tensions.
Page 9: Leds
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 9 of 36 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
Page 10: Ethernet
ETHERNET: The connection of Ethernet in the HD674-A038 device must be made with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable.
Page 11: Can
Industrial Electronic Devices CAN: The connection of the CAN in the HD674-A038-E4x-xx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page. The connection of the CAN in the HD674-A038-E7x-xx device must be made with a AMP SuperSeal 1.5 Male connector.
Page 12: Use Of Compositor Sw674-A038
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 12 of 36 Industrial Electronic Devices USE OF COMPOSITOR SW674-A038: To configure the Converter, use the available software that runs with Windows called SW674-A038. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 13: New Configuration / Open Configuration
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 13 of 36 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “CAN / MQTT - Converter”...
Page 14: Software Options
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 14 of 36 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 15 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 15 of 36 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
Page 16: Set Communication
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 16 of 36 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, CAN and MQTT. By Pressing the “Set Communication” button from the main window for SW674- A038 (Fig.
Page 17 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 17 of 36 Industrial Electronic Devices THERNET ONNECTION The means of the fields for “Ethernet Connection” are: In the field “Device Name (Hostname)” the Hostname to assign to the converter is defined;...
Page 18 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 18 of 36 Industrial Electronic Devices This section is used to define the main parameters of MQTT line. The means of the fields are: In the field “Server URL”...
Page 19 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 19 of 36 Industrial Electronic Devices In the field “Username” the username for the connection to the MQTT server is defined; In the field “Password” the password for the connection to the MQTT server is defined. THERNET This section is used to define the general parameters of Ethernet.
Page 20 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 20 of 36 Industrial Electronic Devices NTP: This section is used to define the general parameters of TLS. The means of the fields are: In the field “Server URL”...
Page 21: Mqtt Set Topic
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 21 of 36 Industrial Electronic Devices MQTT SET TOPIC: By Pressing the “MQTT Set Topic” button from the main window for SW674-A038 (Fig. 2) the window “Set MQTT Topics” appears (Fig. 4). This section is used to define the MQTT topics where the converter will publish the data from CAN and the topic that the converter will subscribes for writing the data to CAN.
Page 22 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 22 of 36 Industrial Electronic Devices MQTT S UBSCRIBE Figure 4b: “Set MQTT Topics  MQTT Subscribe” window The means of the fields are: In the field “Topic” the MQTT topic is defined; In the field “QoS”...
Page 23: Receive Frames
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 23 of 36 Industrial Electronic Devices RECEIVE FRAMES: By pressing the “Receive Frames” button from the main window for SW674-A038 (Fig. 2) the “Receive CAN Frames” window appears (Fig. The COB inserted in this table contains the data to write on MQTT side.
Page 24 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 24 of 36 Industrial Electronic Devices In the field “Byte4” insert the byte of the internal memory array where saving 4th byte of the CAN message; In the field “Byte5” insert the byte of the internal memory array where saving 5th byte of the CAN message; In the field “Byte6”...
Page 25: Send Frames
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 25 of 36 Industrial Electronic Devices SEND FRAMES: By pressing the “Send Frames” button from the main window for SW674-A038 (Fig. 2) the “Send CAN frames” window appears (Fig. 6). The COB inserted in this table contains the data received from MQTT side.
Page 26 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 26 of 36 Industrial Electronic Devices In the field “Byte5” insert the byte of the internal memory array where taking 5th byte of the CAN message; In the field “Byte6” insert the byte of the internal memory array where taking 6th byte of the CAN message; In the field “Byte7”...
Page 27: Update Device
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 27 of 36 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button it is possible to load the created Configuration into the device; and also the Firmware, if is necessary.
Page 28 Industrial Electronic Devices Note: When you install a new version of the software it is better if the first time you do the update of the Firmware in the HD674-A038. Note: When you receive the device, for the first time, you have to update also the Firmware in the HD674-A038 device.
Page 29: Template String: Definition Of Mqtt Payload
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 29 of 36 Industrial Electronic Devices TEMPLATE STRING: DEFINITION OF MQTT PAYLOAD In the section “Set Communication” of the SW674-A038, it is possible to define a Template string for the MQTT messages. The template is necessary in order to define the structure of the payload of the MQTT message and the info contained.
Page 30: Mechanical Dimensions
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 30 of 36 Industrial Electronic Devices MECHANICAL DIMENSIONS: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 31 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 31 of 36 Industrial Electronic Devices Type A ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 32 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 32 of 36 Industrial Electronic Devices Type B ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 33 User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 33 of 36 Industrial Electronic Devices Type C ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 34: Ordering Informations
Page 34 of 36 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD674-A038 – E y z – s f Fixing lugs A: Type A B: Type B C: Type C...
Page 35: Disclaimer
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 35 of 36 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 36: Warranties And Technical Support
User Manual CAN / MQTT - Converter Document code: MN674-A038_ENG Revision 1.000 Page 36 of 36 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
