5.6.3 Status

Group Register
Misc. 6000
Status
6001, 6002
6003, 6004
6005, 6006
6007, 6008
6009
6010
6011
6012
6013
6014
6015
6016
6017
6018
6019
6020
6021
Page 68 of 86
Content Description
Program This value is incremented each time a complete
Scan Count program cycle occurs in the module.
Product These two registers contain the product code of
Code "CAS"
Product These two registers contain the product version for
Version the currently running software.
Operating These two registers contain the month and year
System values for the program operating system.
Run These two registers contain the run number value for
Number the currently running software.
Port 1 This field contains the number of requests made from
Command this port to slave devices on the network.
List
Requests
Port 1 This field contains the number of slave response
Command messages received on the port.
List
Response
Port 1 This field contains the number of command errors
Command processed on the port. These errors could be due to a
List Errors bad response or command.
Port 1 This field contains the total number of messages sent
Requests out of the port.
Port 1 This field contains the total number of messages
Responses received on the port.
Port 1 This field contains the total number of error messages
Errors Sent sent out of the port.
Port 1 This field contains the total number of message errors
Errors received on the port.
Received
Port 2 This field contains the number of requests made from
Command this port to slave devices on the network.
List
Requests
Port 2 This field contains the number of slave response
Command messages received on the port.
List
Response
Port 2 This field contains the number of command errors
Command processed on the port. These errors could be due to a
List Errors bad response or command.
Port 2 This field contains the total number of messages sent
Requests out the port.
Port 2 This field contains the total number of messages
Responses received on the port.
Port 2 This field contains the total number of message errors
Errors Sent sent out the port.
Reference
