MVI56-CAS ♦ ControlLogix Platform
Teledyne CA Slave Module
4.2

LED Status Indicators

The LEDs indicate the module's operating status as follows:
ProSoft Color
Module
CFG Green
P1 Green
P2 Green
APP Amber
BP ACT Amber
OK Red/
Green
BAT Red
During module configuration, the OK LED will be red and the APP and BP ACT
LEDs will be on. If the LEDs are latched in this mode for a long period of time,
look at the configuration error words in the configuration request block. The
structure of the block is as shown below.
Offset
0
1
2
3
4
5 to 248
249
If the APP, BP ACT and OK LEDs blink at a rate of every one-second, this
indicates a serious problem with the module. Call Prosoft Technology support to
arrange for repairs.
Page 44 of 86
Status Indication
On Data is being transferred between the module and a remote
terminal using the Configuration/Debug port.
Off No data is being transferred on the Configuration/Debug
port.
On Data is being transferred between the module and the TCA
network on its TCA Port 1.
Off No data is being transferred on the port.
On Data is being transferred between the module and the TCA
network on its TCA Port 2.
Off No data is being transferred on the port.
On The MVI56-CAS is working normally.
Off The MVI56-CAS module program has recognized a
communication error on one of its TCA ports.
On The LED is on when the module is performing a write
operation on the backplane.
Off The LED is off when the module is performing a read
operation on the backplane. Under normal operation, the
LED should blink rapidly on and off.
Off The card is not receiving any power and is not securely
plugged into the rack.
Green The module is operating normally.
Red
The program has detected an error or is being configured. If
the LED remains red for over 10 seconds, the program has
probably halted. Remove the card from the rack and re-
insert the card to restart the module's program.
Off The battery voltage is OK and functioning.
On The battery voltage is low or battery is not present. Allow
battery to charge by keeping module plugged into rack for 24
hours. If BAT LED still does not go off, contact ProSoft
Technology, as this is not a user serviceable item.
Description
Reserved
9000
Module Configuration Errors
Port 1 Configuration Errors
Port 2 Configuration Errors
Spare
-2 or -3
Diagnostics and Troubleshooting
Length
1
1
1
1
1
244
1
