Reference

5 Reference
In This Chapter
5.1

Product Specifications

The MVI56 Teledyne CA Slave Module allows ControlLogix I/O compatible
processors to interface easily with TCA protocol compatible devices.

5.1.1 Features and Benefits

The MVI56-CAS module acts as an input/output module between the TCA
network and the ControlLogix backplane. The data transfer from the ControlLogix
processor is asynchronous from the actions on the TCA network. A 5000-word
register space in the module exchanges data between the processor and the
TCA network.

5.1.2 General Specifications

Single Slot - 1756 backplane compatible
Local or remote rack
The module is recognized as an Input/Output module and has access to
processor memory for data transfer between processor and module
Ladder Logic is used for data transfer between module and processor.
Configuration data obtained through user-defined ladder. Sample ladder file
included
ProSoft Technology, Inc.
December 26, 2007
Product Specifications............................................................ 47
Functional Overview............................................................... 49
Cable Connections................................................................. 57
MVI56-CAS Database Definition ............................................ 63
MVI56-CAS Status Data Definition......................................... 63
MVI56-CAS Configuration Data Definition ............................. 65
MVI56-CAS Command Control .............................................. 70
Protocol Commands............................................................... 70
MVI56-CAS ♦ ControlLogix Platform
Teledyne CA Slave Module
Page 47 of 86
