Package Contents - ProSoft Technology inRAx MVI56-CAS User Manual

MVI56-CAS ♦ ControlLogix Platform
Teledyne CA Slave Module
100 Mbytes of free hard disk space (or more based on application
requirements)
256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color
1024 × 768 recommended)
CD-ROM drive
HyperTerminal or other terminal emulator program.
Note: You can install the module in a local or remote rack. For remote rack installation,
the module requires EtherNet/IP or ControlNet communication with the processor.
1.2

Package Contents

The following components are included with your MVI56-CAS module, and are all
required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following
items are present.
Qty. Part Name
MVI56-CAS
1
Module
1 Cable
3 Cable
2 Adapter
1 ProSoft
Solutions
CD
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
Page 10 of 86
Part Number Part Description
MVI56-CAS Teledyne CA Slave Module
RS232 Null For RS232 Connection to the CFG Port
Modem
Cable #14, RJ45 to For DB9 Connection to Module's Port
DB9 Male Adapter
1454-9F Two Adapters, DB9 Female to Screw Terminal.
For RS422 or RS485 Connections to Port 1 and 2
of the Module
Contains sample programs, utilities and
documentation for the MVI56-CAS module.
Start Here
ProSoft Technology, Inc.
December 26, 2007
