MVI56-CAS ♦ ControlLogix Platform
Teledyne CA Slave Module
Group
Register
5011
5012
5013
5014
5015
5016
5017
5018
5019
5020
5021
5022
5023
Page 66 of 86
Content
Description
Baud Rate
This is the baud rate to be used on the port. Enter the
baud rate as a value. For example, to select 19K baud,
enter 19200. Valid entries for this field include 110, 150,
300, 600, 1200, 2400, 4800, 9600, 19200, 28800, 38400,
57600, and 115.
Parity
This is the parity code to be used for the port. None, Odd,
Even.
Data Bits
This parameter sets the number of data bits for each word
used by the protocol. Valid entries are 5 or 8.
This parameter sets the number of stop bits to be used
Stop Bits
with each data value set. Valid entries are 1 and 2.
RTS On
This parameter sets the number of milliseconds to delay
after RTS is asserted before the data is transmitted. Valid
values are 0 to 65535.
RTS Off
This parameter sets the number of milliseconds to delay
after the last byte of data is sent before the RTS modem
signal will be set low. Valid values are 0 to 65535.
Minimum
This parameter specifies the minimum number of
Response
milliseconds to delay before responding to a request
Time
message. This pre-send delay is applied before the RTS
on time. This may be required when communicating with
slow devices.
Use CTS
This parameter specifies if the CTS modem control line is
Line
to be used. If the parameter is set to 0, the CTS line will
not be monitored. If the parameter is set to 1, the CTS line
will be monitored and must be high before the module will
send data. This parameter is normally only required when
half-duplex modems are used for communication (2-wire).
Slave ID
This parameter defines the virtual slave address for the
internal database. Any request received by the port with
this address will be processed by the module. Be certain
each device has a unique address on a network. Valid
range for this parameter is 1 to 255 (247 on some
networks).
Use Guard
Not implemented.
Band
Guard
Not Implemented.
Band Time
Direct
This parameter enables direct control. If enabled, a Select
Control
command is not required before a Control command.
Valid entries are 0 and 1.
Swap
This parameter sets the data swapping. The swapping is
Config
set as a bit field. Bit 0 corresponds to status data, Bit 1 to
analog data, and Bit 2 to meter data.
Reference
