1.4 Installing the Card
Reader
1.4.1 Points to Note
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
When installing the card reader, the card reader at-
tachment-D1 is required.
1.4.2 Checking the Con-
tents
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
<Card reader-E1>
[1]
F-1-32
[1]
Card reader-E1
[2]
TP screw (M3x12)
[3]
Toothed washer
[4]
Repeating harness A
0011-1080
0011-1081
[2]
[3]
[4]
1 pc.
1 pc.
1 pc.
1 pc.
The repeating harness, TP screw (M3x12), and
toothed washer are not used.
<Card reader attachment-D1>
[2]
F-1-33
[1]
Card reader mount
[2]
Card reader cover
[3]
Harness cover (base + lid)
[4]
Repeating harness B
[5]
Edge saddle
[6]
TP screw
[7]
Binding screw (M4x6)
1.4.3 Installation Proce-
dure
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
1) Turn off the main power switch [1] of the host ma-
Chapter 1
1 pc.
1 pc.
3 pcs.
1 pc.
1 pc.
2 pcs.
4 pcs.
0011-1082
17
