1.6 Installing the Reader
Heater
1.6.1
Unpacking
Checking the Contents
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
Before installing, make sure the heater PCB has been
installed.
1) Prepare the following parts.
]
[2]
[4]
[5]
F-1-68
[1]
Reader heater
[2]
Heater harness
[3]
Harness guide
[4]
Right heater base
[5]
Heater cover
[6]
Clamp
and
0011-3368
[3]
[6]
[
2 pcs.
1 pc.
1 pc.
1 pc.
2 pcs.
6 pcs.
[7]
TP screw (M3x6)
1.6.2
Installing
Reader Heater Har-
ness
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
Before installing, make sure the host machine is
turned off. If it is turned on, go through the following:
1. Turn off the main power switch.
2. Disconnect the power cable (from the power out-
let).
3. Disconnect the power cable.
F-1-69
1) Open the front cover [1].
Chapter 1
5 pcs.
the
0011-3371
29
