Chapter 1

1.1 Making Pre-Checks

1.1.1 Selecting the Site of Installation
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
Select the site of installation against the following requirements; if possible, visit the user's before delivery of the
machine:
1) There must be a power outlet properly grounded and rated as indicated (-/+10%) for exclusive use by the machine.
2) The environment of the room must be as indicated in the following diagram, and the machine must not be installed
near a water faucet, water boiler, humidifier, or refrigerator:
(%RH)
<Environmental zone assured>
[A]: Zone A: Satisfies all the conditions of the standard image quality and paper feed performance.
[B]: Zone B: Inferior to Zone A in terms of the standard image quality and paper feed performance, or may not apply.
[C]: Zone C: Problems associated with safety, malfunctions, or incorrect message display do not occur, but image
quality and paper feed performance are not guaranteed.
3) The machine must not be installed near a source of fire or in an area subject to dust or ammonium gas.
If the area is exposed to direct rays of the sun, provide curtains to the window.
4) The level of ozone generated by the machine will not affect the health of individuals around it. Some, however,
may find its odor unpleasant as while remaining in contact with it for long hours. Be sure that the room is well
2
100
[C]
90
85
[B]
75
70
[A]
50
25
20
15
10
5
0
10
15
7.5
20
25
30
23
27.5
32.5
F-1-1
35
40
(degC)
0011-1068
