6.11.2 Measurements table

– User Manual
Modbus MS Card
Description of the physical quantity
I1 (I phase 1) mains 1
I2 (I phase 2) mains 1
I3 (I phase 3) mains 1
I1 (I phase 1) mains 2
I2 (I phase 2) mains 2
I3 (I phase 3) mains 2
I1 (I phase 1) output
I2 (I phase 2) output
I3 (I phase 3) output
I battery
Nominal value active power
U12 mains 1
U23 mains 1
U31 mains 1
U mains 2 (phase 1)
U mains 2 (phase 2)
U mains 2 (phase 3)
U12 mains 2
U23 mains 2
U31 mains 2
U1N output
U2N output
U3N output
U12 output
U23 output
U31 output
U battery
Output active power (phase 1)
Output active power (phase 2)
Output active power (phase 3)
Output apparent power (phase 1)
Output apparent power (phase 2)
Output apparent power (phase 3)
Output total active power
Output total apparent power
% output load level
Peak factor phase 1 x 100
Peak factor phase 2 x 100
Peak factor phase 3 x 100
34009048XT_EN/AD
Word (hex) Unit
100 A
101 A
102 A
106 A
107 A
108 A
109 A
10A A
10B A
10E A
111 W of KW
115 V
116 V
117 V
11E V
11F V
120 V
121 V
122 V
123 V
124 V
125 V
126 V
127 V
128 V
129 V
12D V
130 W
131 W
132 W
133 VA
134 VA
135 VA
136 W
137 VA
139 %
13A -
13B -
13C -
