6.6 Data for Eaton 5PX and Eaton 5P

6.6.1 Status table

Status description
Load protected
UPS coupled
Unit general alarm
UPS in backup
Battery low warning
Low battery
Communication fault
UPS overload
Emergency stop
Battery to be checked
Device ventilation fault
UPS Class
Battery present
Mode buck
Mode Boost
Mains 1 voltage out of tolerance
Mains 1 frequency out of tolerance
Charger general fault
Battery charge
Short circuit
– User Manual
Modbus MS Card
Status to 0
no
no
no
no
no
no
absent
no
absent
no
no
001 : off line / line interactive
011 : on line - unitary/parallel
100 : on line – parallel with NS
101 : on line – hot standby
redundancy
absent
no
no
no
no
no
no
no
34009048XT_EN/AD
Status to 1 Word (hex)
yes 40
yes 40
yes 40
yes 40
yes 40
yes 40
present 40
yes 40
present 40
yes 40
yes 40
41
present 42
yes 44
yes 44
yes 44
yes 44
yes 49
yes 49
yes 4F
Bit
0
1
2
4
5
6
9
A
B
D
E
1 to 3
0
0
1
8
B
0
1 & 3
1
