Description of the physical quantity
U31 mains 2
U1N output
U2N output
U3N output
U12 output
U23 output
U31 output
U battery
Output active power (phase 1)
Output active power (phase 2)
Output active power (phase 3)
Output apparent power (phase 1)
Output apparent power (phase 2)
Output apparent power (phase 3)
Output total active power
Output total apparent power
% output load level
Power factor x 100
Mains 1 frequency
Mains 2 frequency
Output frequency
Battery backup time
U mains 1 (phase 1)
U mains 1 (phase 2)
U mains 1 (phase 3)
Nominal value apparent power
Nominal voltage of battery element
34009048XT_EN/AD
Unit
Word (hex)
123 V
124 V
125 V
126 V
127 V
128 V
129 V
12D V
130 W
131 W
132 W
133 VA
134 VA
135 VA
136 W
137 VA
139 %
13D -
13E Hz
140 Hz
141 Hz
149 Min
150 V
151 V
152 V
209 VA or KVA
213 V
