6.6.2 Measurements table

Description of the physical quantity
I Mains 1
I output
Nominal value active power
U output
U battery
Output active power
Output apparent power
% output load level
Power factor (Cos PHI)
Mains 1 frequency
Output frequency
Battery backup time
Battery charging level
U mains 1
Nominal value apparent power
Nominal voltage of battery element
– User Manual
Modbus MS Card
Word (hex)
100
109
111
124
12D
136
137
139
13D
13E
141
149
14B
150
209
213
34009048XT_EN/AD
Unit
A
A
W of KW
V
V
W
VA
%
-
Hz
Hz
Min
%
V
VA or KVA
V
