6.2.2 Measurements table

Description of the physical quantity
I mains 2
I output
U mains 2
U output
U battery
Output active power
Output apparent power
% output load level
Power factor x 100
Mains 1 frequency
Output frequency
Battery backup time
Battery charging level
U mains 1
Nominal voltage of battery element
– User Manual
Modbus MS Card
34009048XT_EN/AD
Word (hex) Unit
106 A
109 A
11E V
124 V
12D V
136 W
137 VA
139 %
13D -
13E dHz
141 dHz
149 Min
14B %
150 V
213 V
