6.7.2 Measurements table

– User Manual
Modbus MS Card
Description of the physical quantity
I output
Nominal value active power
U mains 2
U output
U battery
Output total active power
Output total apparent power
% output load level
Mains 1 frequency
Mains 2 frequency
Output frequency
Battery backup time
Battery charging level
U mains 1 (phase 1)
U mains 1 (phase 2)
U mains 1 (phase 3)
Nominal value apparent power
Nominal voltage of battery element
34009048XT_EN/AD
Word (hex) Unit
109 A
111 W of KW
11E V
124 V
12D V
136 W
137 VA
139 %
13E Hz
140 Hz
141 Hz
149 Min
14B %
150 V
151 V
152 V
209 VA or KVA
213 V
Page
40/55
