Status description
Inverter thermal overload
Inverter limitation
Short circuit
Electronic power supply fault

6.10.2 Measurements table

– User Manual
Modbus MS Card
Description of the physical quantity
I mains 2
I1 (I phase 1) output
I2 (I phase 2) output
I battery
Nominal value active power
U12 mains 1
U mains 2 (phase 1)
U mains 2 (phase 2)
U12 mains 2
U1N output
U2N output
U12 output
U battery
Output active power (phase 1)
Output active power (phase 2)
Output apparent power (phase 1)
Output apparent power (phase 2)
Output total active power
Output total apparent power
% output load level
Mains 1 frequency
Mains 2 frequency
Output frequency
Battery backup time
Battery charging level
U mains 1 (phase 1)
U mains 1 (phase 2)
Nominal value apparent power
Nominal voltage of battery element
34009048XT_EN/AD
Status to 0 Status to 1
no yes
no yes
no yes
no yes
Word (hex)
106
109
10A
10E
111
115
11E
11F
121
124
125
127
12D
130
131
133
134
136
137
139
13E
140
141
149
14B
150
151
209
213
Bit
Word (hex)
4C 3
4C 4
4F 1
50 6
Unit
A
A
A
A
W of KW
V
V
V
V
V
V
V
V
W
W
VA
VA
W
VA
%
Hz
Hz
Hz
Min
%
V
V
VA or KVA
V
Page
46/55
