B.5 Prototyping Board Jumper Configurations
Figure B-6 shows the header locations used to configure the various Prototyping Board
options via jumpers.
Figure B-6. Location of Configurable Jumpers on Prototyping Board
Table B-4 lists the configuration options using either jumpers or 0 Ω surface-mount resistors.
Table B-4. RCM5400W Prototyping Board Jumper Configurations
Header Description
JP1 +5 V Current Measurement
JP2 +3.3 V Current Measurement
JP3
PC0/TxD/LED DS2
JP4
102
JP1
JP2
JP16
JP6
JP5
JP12
JP4
JP3
JP14
JP8
JP7
JP18
JP9
JP10
JP24 JP23
1–2 Via trace or jumper
1–2 Via trace or jumper
JP3
TxD on header J4
1–2
JP4
PC0 to LED DS2
1–2
n.c. PC0 available on header J2
UX49
JP25
Pins Connected
Factory
Default
Connected
Connected
×
