1.1 RCM5400W/RCM5450W Features

• Small size: 1.84" × 2.85" × 0.55"
(47 mm × 72 mm × 14 mm)
• Microprocessor: Rabbit 5000 running at 73.73 MHz
• Up to 35 general-purpose I/O lines configurable with up to four alternate functions
• 3.3 V I/O lines with low-power modes down to 2 kHz
• Six CMOS-compatible serial ports — four ports are configurable as a clocked serial port
(SPI), and two ports are configurable as SDLC/HDLC serial ports.
• Alternate I/O bus can be configured for 8 data lines and 6 address lines (shared with
parallel I/O lines), I/O read/write
• Airoha single-chip 802.11b/g transceiver
• Real-time clock
• Watchdog supervisor
Currently there are two RCM5400W production models. Table 1 summarizes their main
features.
Feature
Microprocessor
Flash Memory
Data SRAM
Fast Program-Execution SRAM
Serial Flash Memory (data)
Serial Ports
Wi-Fi
NOTE: There is a special version of the RCM5400W RabbitCore module for Japan. It is
functionally identical to the standard RCM5400W module and uses the same compo-
nents, but has been assembled to meet the Japan regulatory requirements. Be sure to
order the correct version for the market where you plan to use the RCM5400W. The
two versions can be distinguished by the labels on the RF shield as shown below.
Standard Release Label
RABBIT RCM5400W
DIGI ® INTERNATIONAL
901-0190
2
Table 1. RCM5400W Features
RCM5400W
Rabbit
512K
512K
512K
1MB
6 shared high-speed, CMOS-compatible ports:
6 are configurable as asynchronous serial ports;
4 are configurable as clocked serial ports (SPI);
2 are configurable as SDLC/HDLC serial ports;
1 asynchronous serial port is used during programming
802.11b/g standard, ISM 2.4 GHz
RCM5450W
®
5000 at 73.73 MHz
1MB
512K
1MB
2MB
Japan Version Label
RABBIT RCM5400W
®
DIGI INTERNATIONAL
901-0191
RabbitCore RCM5400W
