Table A-7. RCM5400W Jumper Configurations (continued)
Header
Description
JP5
Flash memory size.
JP6
Wi-Fi power supply control.
NOTE: The jumper connections are made using 0 Ω surface-mounted resistors.
OEM User's Manual
Pins Connected
1–2 ≤ 1MB
2–3 > 1MB
Control disabled—Wi-Fi power
1–2
supply is always on
Control enabled so that the Wi-Fi
2–3
power supply is under
microprocessor control
Factory
Default
×
×
89
