Distributor of Digi International: Excellent Integrated System Limited
Datasheet of 20-101-1194 - MODULE RABBITCORE RCM3309 ROHS
Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com
B.5 Prototyping Board Jumper Configurations
Figure B-12 shows the header locations used to configure the various Prototyping Board
options via jumpers.
JP4
Figure B-12. Location of Prototyping Board Configurable Positions
98
JP1
JP2
Battery
JP5
JP3
RabbitCore RCM3309/RCM3319
