Table 2. RCM5400W Pinout Configurations (continued)
Pin Pin Name
40 PD0
41 PD1
42 PD2
43 PD3
44 PD4
45 PD5
OEM User's Manual
Default Use
I/O Strobe I0
Timer C0
D8
Input/Output
INT0
SCLKD/TCLKF
QRD1B
IA6
I/O Strobe I1
Timer C1
D9
Input/Output
INT1
RXD/RCLKF
QRD1A
Input Capture
I/O Strobe I2
Timer C2
D10
Input/Output
DREQ0
TXF/SCLKC
QRD2B
IA7
I/O Strobe I3
Timer C3
D11
Input/Output
DREQ1
RXC/RXF
QRD2A
Input Capture
I/O Strobe I4
D12
Input/Output
PWM0
TXB/TCLKE
IA6
I/O Strobe I5
D13
Input/Output
PWM1
RXB/RCLKE
Input Capture
Alternate Use
Serial Port F
Notes
