4. TECHNICAL SPECIFICATIONS

Bandwidth
Phase response error
Gain
THD+N (IHF-A)
IMD
S/N ratio (IHF-A)
Channel separation
Inputs
Level, nominal (for 1 V output)
Impedance
Sensitivity (programmable for each input)
Outputs
level
impedance
Volume control
channel imbalance
Sphinx Control
Remote control
Mechanical decoupling of housings
Power supply
Supply capacitance
Power consumption
Dimensions (h x w x d)
Weight
This unit conforms to the EMC interference regulations issued by the EU and to the CE standards.
This unit complies with safety regulation VDE 0860 and therefore with international safety regulation IEC 65.
Technical specifications may be changed by SPHINX without prior notice if technical developments make this
necessary.
Service Manual
0 - 500,000 Hz (+0/-3 dB)
<1°
20 dB max.
<0.008% (2nd harm., < 100 kHz and 6 V into 600 ohm)
<0.0015% (2nd harm., 10 – 20,000 Hz and 6 V into 600
ohm)
<0.0015%
>110 dB
>110 dB
2x XLR balanced
6x WBT cinch unbalanced
0.16 V (-18 dBV)
XLR: 10 kohm / cinch: 50 kohm
adjustable between –9 dB and +9 dB
2x XLR balanced
1x WBT cinch unbalanced
1x cinch Tape
10 V max. (20 dBV) (1 - 100,000 Hz, THD <0.001%)
<10 ohm
Relay-controlled in steps of 0.2 dB
Range 100 dB
less than 0.2 dB
3x optical
OUT-1: 1 second delayed
OUT-2: normal
OUT-3: programmable via Auto On
full function
Transrotor absorbing 'pucks'
External, in completely separate housing
148,000 µF total
50 W
68 x 482 x 328 mm (one housing only)
14 kg
