Figure 5: Construction Drawing For Top Cover Plate - SPHINX Project Eight Service Manual

Reference pre-amp
Hide thumbs
Table of Contents

Advertisement

SPHINX Project Eight
Service Manual

Figure 5: Construction Drawing for top cover plate

All sizes in millimeters
315
For holes use drill size of
approx. Ø 6 mm
Holes use same spacing as the
ones shown below
Top View
66
33
48
48
48
48
6
12
6
16
