SPHINX Myth 5

6. TECHNICAL SPECIFICATIONS

Bandwidth
Phase response error
Gain
Minimum Power Output (1 - 20.000 Hz)
Output voltage / current, max.
THD+N (IHF-A)
IMD
S/N ratio (IHF-A)
Channel separation
Slew rate
Damping factor
Inputs
Cinch, unbalanced
Level, nominal
Impedance
Outputs
Cinch
Headphones
Clamp
Supply capacitance
Power consumption
Dimensions (h x w x d)
Weight
This unit conforms to the EMC interference regulations issued by the EU and to the CE standards.
This unit complies with safety regulation VDE 0860 and therefore with international safety regulation IEC 65.
Technical specifications may be changed by SPHINX without prior notice if technical developments make this
necessary.
©1999 Audioscript BV
Service Manual
10 - 190,000 Hz (+0/-3 dB)
<1° (from 0 - 20,000 Hz)
40.5 dB max. (102.3 times)
>2x 74 W into 8 Ω (18.7 dBW), THD <0.01%
>2x 115 W into 4 Ω (20.6 dBW), THD <0.01%
>2x 144 W into 2 Ω (21.6 dBW), THD <0.01%
23 V / 20 A
nd
<0.006% (2 harm., 10-20,000 Hz)
<0.030%
>95 dB
>68 dB (1 - 20,000 Hz)
>24 V/µs
>650 (1 - 1,000 Hz)
1x Line 2, 1x Line 1, 1x CD, 1x Tuner, 1x Tape
1.25 V
20 kΩ
1x Tape
1x 6.3 mm stereo jack, adjustable level
1x loudspeaker L, 1x loudspeaker R
35,200 µF total
600 W max.
73 x 434 x 350 mm
8 kg
