6. CARE AND MAINTENANCE

Clean the exterior with a soft, lint-free, anti-static
cloth. Do not use force while wiping the surface.
To remove difficult stains use a few drops of
detergent on a moist cloth, sweep carefully and
wipe dry afterwards.
If some scratching occurs, please consult your
Sphinx dealer first. He can give you advice about
possible solutions.
7. TECHNICAL SPECIFICATIONS
Bandwidth
Phase response error
Gain
Minimum Power Output (1 - 20,000 Hz)
THD+N (IHF-A)
IMD
S/N ratio (IHF-A)
Channel separation
Slew rate
Damping factor
Input
level, nominal
impedance
Supply capacitance
Power consumption
Dimensions (h x w x d)
Weight
This unit conforms to the EMC interference regulations issued by the EU and to the CE standards.
This unit complies with safety regulation VDE 0860 and therefore with international safety regulation IEC 65.
Technical specifications may be changed by SPHINX without prior notice if technical developments make this
necessary.
©1999 Audioscript BV
SPHINX
Do not use polishing or cleaning agents: they
may damage the sensitive acrylic finish.
Do not use aerosol cleaning agents.
Most contain solvents which might react with and
damage the acrylic finish.
0 - 300,000 Hz (+0/-0.25 dB)
<2° (0 - 20,000 Hz)
29.5 dB max. 29.85 times.
>2x 94.5 W into 8 ohm (19.8 dBW), THD <0.01%
>2x 157.5 W into 4 ohm (22.0 dBW), THD <0.01%
>2x 217.6 W into 2 ohm (23.4 dBW), THD <0.01%
nd
<0.06% / 0.006% (2 harmonic, 10 - 20,000 Hz)
<0.005% (50 W into 8 Ω)
>85 dB / 98 dB
>90 dB (1 - 20,000 Hz)
>20 V/µs
>500 (1 - 1,000 Hz)
cinch: unbalanced
1.25V (1.9 dBV)
20 kΩ
26,000 µF total per channel
550 W max. (15 W standby)
73 x 434 x 350 mm
10 kg
