The LED during Normal mode

• Blinks green: Remote sends a command.
• Blinks green/red: batteries are low, you should
change them within a few days.
• Blinks red: replace batteries immediately.
Replace them within 30 minutes or else all
information in memory will be erased!

The LED during 'Learn' mode

• Indicates orange: Remote is in 'Learn' mode.
• Blinks orange: Remote awaits the command to
be 'learned' from the other remote control.
• Indicates green: the new command has been
'learned'.
• Indicates red: the new command has NOT been
'learned'.
• Blinks for 10 seconds red, yellow and green:
memory full, you cannot program new
commands.
Note: You can still change any commands
already programmed.

Batteries

The two batteries have a life span of approximately
one year during normal use, but shorter when used
more intensely.
Replacement batteries: 1.5 V, model penlite or AAA
(one of these codes is indicated on the packaging
and the batteries). You may also use rechargeable
1.5 V batteries.
Do not leave the battery compartment empty for
more than 30 minutes or else all information in
memory will be erased!
Note: Position the new batteries exactly as shown
in the illustration at the bottom of the battery
compartment, otherwise the memory might be
erased completely!

Other things worth knowing...

The 'advanced user' will understand that you can
program any function for any button! You are
therefore able to custom configure the Remote
Control and use it for several pieces of equipment.
The memory holds a maximum of 120 commands.
Warning: If you don't know exactly what you are
doing, please consult your Sphinx dealer!
Service Manual

Encountering problems...

Remote Control does not work
Wrong component selected
Wrong Remote mode ('Learn'
instead of Normal)
Wrong command programmed
Distance to component
exceeds 7 m
Angle between Remote and
component exceeds ±30°
Sensor window on front dirty
Batteries empty or incorrectly
placed
Strong (sun)light in room
Component is not switched on
(!)
Memory erased
Remote Control does not 'learn'
Wrong Remote mode (Normal
instead of 'Learn')
Distance between two remotes
exceeds 2 cm
Signal to be learned is not
infrared
Sensor window on front dirty
Batteries in remote(s) empty
Strong (sun)light hits sensor
window
Component reacts differently than expected or
not at all
Wrong component selected
Wrong command programmed
Component or Remote does
not function
Batteries in remote empty
Select the correct one
Select correct mode
Re-program with Learn
mode
Use Remote at closer
range
Decrease angle
Clean window
Use new batteries or
replace the old ones
correctly
Shade off light source
Switch it on
Re-program completely
Select correct mode
Place them closer
together
'Learning' only possible
with infrared systems
Clean window
Use new batteries
Shade off light source
Select the correct one
Re-program with Learn
mode
Check component with
its original remote
Use new batteries
