CARE AND MAINTENANCE

Clean the exterior with a soft, lint-free, anti-static
cloth. Do not use force while wiping the surface.
To remove difficult stains use a few drops of
detergent on a moist cloth, sweep carefully and
wipe dry afterwards.
If some scratching occurs, please first consult your
Sphinx dealer. He can give you advice about
possible solutions.

TECHNICAL SPECIFICATIONS

Bandwidth
Phase response error
Gain
Minimum Power Output (1 - 20.000 Hz)
Output voltage / current, max.
T HD+N (IHF-A)
IMD
S/N ratio (IHF-A)
Channel separation
Slew rate
Damping factor
Inputs
XLR, balanced
cinch, unbalanced
level, nominal
impedance
Outputs
cinch
level
headphones
clamp
Supply capacitance
Power consumption
Dimensions (h x w x d)
Weight
This unit conforms to the EMC interference regulations from the EU and to the CE standards.
This unit complies with safety regulation VDE 0860 and thus with international safety regulation IEC 65.
Technical specifications can be changed by SPHINX without prior notice if technical developments make this
necessary.
©1998 Audioscript BV
SPHINX
Do not use polishing or cleaning agents: they
may damage the sensitive acrylic finish.
Do not use aerosol cleaning agents.
Most contain solvents which might actively react
and damage the acrylic finish.
0 - 60,000 Hz (+0/-3 dB with RF input filter)
<15° (from 0 - 20,000 Hz)
21 dB max.
>2x 80 W into 8 (19.0 dBW), THD <0.01%
>2x 120 W into 4 (20.8 dBW), THD <0.02%
>2x 160 W into 2 (22.0 dBW), THD <0.02%
34 V / 20 A
<0.01% (80 W into 8
<0.03%
>106 Db
>80 dB (1 - 20,000 Hz)
>25 V/µs
>200 (1 - 20,000 Hz)
1x Line 2
1x Line 2, 1x Line 1, 1x CD, 1x Tuner, 1x Tape
0.15 V (-16.5 dBV) for 60 W into 8
20 k (3 k balanced)
1x Tape
10 V max. (20 dBV) (1 - 20,000 Hz, THD <0.01%)
1x 6.3 mm stereo jack, adjustable level
1x loudspeaker L, 1x loudspeaker R
54,400 µF per channel
480 W max. (57.5 W standby)
110 x 482 x 330 mm
12 kg
Project Ten
)
11
