Cellink BIO X User Manual page 39

4.3.2 Choose printer setup
Configure printhead, bioink and printer settings. Customize your print according to the needs of your
experiment.
1
2
1. Navigation bar – Toggle between printhead and print bed settings.
2. Toggle printhead – Tap to select if you want to use the printhead or not.
If you select to use the printhead further settings will appear.
3. Bioink profile – Select a predefined bioink profile or create a new one. BIO X comes preloaded
with profiles for all CELLINK bioinks.
4. Printhead type – Select the type of printhead to use.
5. Extrusion time – Drag the slider on a graduated scale to choose the extrusion time for
printing droplets.
6. Pressure - Choose the pressure to use during extrusion.
7. Temperature - Choose the temperature of the printhead.
3
5
6
4
7
