4.2.11 Print model
This screen summarizes the bioprinting process. You can monitor the activity of each printhead and
curing module while printing.
Always pause bioprinting before opening the door. Do not remove printheads before
bioprinting has stopped. Doing so risks aborting the process and compromising your
cells.
1
2
3
4
5
6
1.
Printhead 1 – Allows you to monitor the specific properties of printhead 1.
2.
Printhead 2 - Allows you to monitor the specific properties of printhead 2.
3.
Printhead 3 - Allows you to monitor the specific properties of printhead 3.
4.
Left photo-curing module – Allows you to monitor the specific properties of the left photo-
curing module.
5.
Right photo-curing module – Allows you to monitor the specific properties of the right
photo-curing module.
6.
Z Offset - Adjust printbed position during printing.
7.
Progress indicator – Displays progress and time left to completion.
8.
Bioprint - Tap to start the bioprinting process.
36
7
8
