Cellink BIO X User Manual page 27

1
2
1. Navigation bar – Use this to toggle between the settings for the different
printheads and the print bed.
2. Toggle printhead – Tap to indicate if you want to use the printhead or not.
If you select the printhead, you will be prompted with more settings.
3. Bioink profile – Select the bioink profile you want to use. BIO X comes
preloaded with profiles for all CELLINK bioinks.
4. Printhead type – Select the type of printhead you want to use. Different
settings will appear below depending on what type of printhead you
select. BIO X comes preloaded with profiles for all of CELLINK's intelligent
printheads.
5. Photo curing – Choose whether to use UV to crosslink the model. If using UV crosslinking,
more settings will appear.
3 4 5
