Cellink BIO X User Manual page 28

Calibration settings appear after selecting a printhead. Use or modify an existing profile, or create a
new one. Bioink and photo-curing parameters are the same for all bioinks and printheads, but the
printhead parameters change depending on the printhead selected.
1. Nozzle type – Select the nozzle type and size.
2. Printhead settings – These settings change depending on which intelligent
printhead you use. Consult the manual for the specific printhead for more
information.
3. Photo-curing wavelength – Tap to select which wavelength to use for photo curing.
4. Print speed – Tap to select the speed of the printhead.
5. Curing speed – Tap to select the speed of the movement of the photo-curing module.
28
1
4
2 3
5
