Configuring Network Security with ACLs
How to Configure Network Security with ACLs
Command
1. configure terminal
2. time-range time-range-name
3. absolute [start time date]
[end time date]
or
periodic day-of-the-week hh:mm to
[day-of-the-week] hh:mm
or
periodic {weekdays | weekend | daily}
hh:mm to hh:mm
4. end

Applying an IPv4 ACL to a Terminal Line

This task restricts incoming and outgoing connections between a virtual terminal line and the addresses in an ACL:
Command
1. configure terminal
2. line [console | vty] line-number
3. access-class access-list-number
{in | out}
4. end

Applying an IPv4 ACL to an Interface

Command
1. configure terminal
2. interface interface-id
3. ip access-group {access-list-number
| name} {in | out}
4. end
Purpose
Enters global configuration mode.
Assigns a meaningful name (for example, workhours) to the time range
to be created, and enters time-range configuration mode. The name
cannot contain a space or quotation mark and must begin with a letter.
Specifies when the function it will be applied to is operational.

You can use only one absolute statement in the time range. If you
configure more than one absolute statement, only the one
configured last is executed.

You can enter multiple periodic statements. For example, you could
configure different hours for weekdays and weekends.
See the example configurations.
Returns to privileged EXEC mode.
Purpose
Enters global configuration mode.
Identifies a specific line to configure, and enters in-line configuration mode.

console—Specifies the console terminal line. The console port is DCE.

vty—Specifies a virtual terminal for remote console access.
The line-number is the first line number in a contiguous group that you want
to configure when the line type is specified. The range is from 0 to 16.
Restricts incoming and outgoing connections between a particular virtual
terminal line (into a device) and the addresses in an access list.
Returns to privileged EXEC mode.
Purpose
Enters global configuration mode.
Identifies a specific interface for configuration, and enters interface
configuration mode.
The interface is a Layer 2 interface (port ACL).
Controls access to the specified interface.
The out keyword is not supported for Layer 2 interfaces (port ACLs).
Returns to privileged EXEC mode.
