Configuring Cisco IOS IP SLAs Operations
Configuration Examples for Configuring Cisco IP SLAs Operations
Number of history Lives kept: 0
Number of history Buckets kept: 15
History Filter Type: None
Enhanced History:
Sample Output for Show IP SLA Command: Example
This is an example of the output from the command:
Switch# show ip sla application
IP SLAs
Version: 2.2.0 Round Trip Time MIB, Infrastructure Engine-II
Time of last change in whole IP SLAs: 22:17:39.117 UTC Fri Jun
Estimated system max number of entries: 15801
Estimated number of configurable operations: 15801
Number of Entries configured
Number of active Entries
Number of pending Entries
Number of inactive Entries
Supported Operation Types
Type of Operation to Perform: 802.1agEcho
Type of Operation to Perform: 802.1agJitter
Type of Operation to Perform: dhcp
Type of Operation to Perform: dns
Type of Operation to Perform: echo
Type of Operation to Perform: ftp
Type of Operation to Perform: http
Type of Operation to Perform: jitter
Type of Operation to Perform: pathEcho
Type of Operation to Perform: pathJitter
Type of Operation to Perform: tcpConnect
Type of Operation to Perform: udpEcho
IP SLAs low memory water mark: 21741224
Configuring a Responder UDP Jitter IP SLAs Operation: Example
This example shows how to configure the device as a responder for the UDP jitter IP SLAs operation in the next
procedure:
Switch(config)# ip sla responder udp-echo 172.29.139.134 5000
Configuring a UDP Jitter IP SLAs Operation: Example
This example shows how to configure a UDP jitter IP SLAs operation:
Switch(config)# ip sla 10
Switch(config-ip-sla)# udp-jitter 172.29.139.134 5000
Switch(config-ip-sla-jitter)# frequency 30
Switch(config-ip-sla-jitter)# exit
Switch(config)# ip sla schedule 5 start-time now life forever
Switch(config)# end
Switch# show ip sla configuration 10
IP SLAs, Infrastructure Engine-II.
: 0
: 0
: 0
: 0
