Dimensions ( unit : mm ) (continued )
When only input blocks for M12 connector are connected
L2 ( Rail mounting pitch : 12.5 )
Stations 1
L1 [mm] : Rail length
110.5
L2 [mm] : Mounting pitch
100
L3 [mm] : Manifold length
82
L4 [mm] 12

Installation

Connect each connector of Input unit, input blocks,
and end block ( portion indicated by arrow in the
figure to the right ).
Holding with hands so that there will be no gap
between blocks, place the jointed unit and blocks on
DIN rail.
Tighten the bolts of Input unit and end block to
secure the jointed unit and blocks to DIN rail.
Be sure to tighten the bolts by proper tightening
torque. ( Tightening torque : 0.6N m )
28
DIN Rail
(L4)
L3
5
L1
2 3 4 5 6
123 148 173 185.5 210.5
112.5 137.5 162.5 175 200
102 122 142 162 182
12 12.5 12.5 13 13

Specification

Specifications for Input unit
Item
Connected block
Connected block station
Supply voltage for block
Supply current for block
Current consumption
Short circuit protection
Specifications for input block
7 8
Item
223 248
Applicable sensor
212.5 237.5
202 222
No. of input points
13.5 13.5
Rated voltage
Logical "1" input voltage
Logical "0" input voltage
Logical "1" input current
Logical "0" input current
Input delay time
Indicator LED
Insulation
Supply current to sensor
Specification
Current source type input block ( PNP input block )
or
Current sink type input block ( NPN input block )
Max. 8 blocks
24VDC
0.65A Max.
100mA or less ( at rated voltage )
Operates at 1A Typ. ( Cuts power supply. )
Can be reset by returning the power after cutting the
power supply to input and control section of GW unit.
Specification
Current source type Current sink type
( PNP output )
2 points/8 points ( for M8 connector only )
24VDC
15V to 26.4V
0V to 5V
5mA Typ.
1.5mA
1msec. or less
Green LED
N/A
Max. 480mA/Input unit manifold
( NPN output )
0V to 8V
19V to 26.4V
-5mA Typ.
-1.5mA
