Specification

1. SI unit for SV series valve ( EX500-S
Item
Connected block Solenoid valve ( single, double )
Relay output module ( 1-point output, 2- point output )
Connected block
Double solenoid valve
station
Relay output module ( 2-point output )
Single solenoid valve
Relay output module ( 1-point output )
Supply voltage for block 24VDC
Supply current for block 0.65A Max.
Current consumption 100mA or less ( at rated voltage )
2. SI unit for VQC series valve ( EX500-Q
Item
Connected block Solenoid valve ( single, double )
General purpose output block ( EX500-Q
Connected block Double solenoid valve
station
Single solenoid valve
General purpose output block
( EX500-Q
Supply voltage for block 24VDC
Supply current for block 0.75A Max.
Current consumption 100mA or less ( at rated voltage )
3. Applicable valve series
Manifold
Series
Cassette
SV1000
SV2000
-
SV3000
-
SV4000
-
VQC1000
-
VQC2000
-
VQC4000
For detailed specifications of solenoid valve and manifold, refer to the catalogs, instruction
manuals, technical data, etc. of each valve series.
24
01 )
Specification
Max. 8 stations
Max. 16 stations
)
Specification
02 only )
Max. 8 stations
Max. 16 stations
Max. 8 stations
02 only )
Inner diameter of applicable cylinder tube ( mm )
Tie-rod 40 50 63 80

Display

SI unit for SV series valves ( EX500-S
SI unit for VQC series valves ( EX500-Q
Common to EX500-S
100 125
Display
Power LED
Communication
LED
Power LED
Communication LED
Communication LED
Power LED
01/EX500-Q
Description
Lights on : Power to solenoid valves/output is supplied at the
specified voltage.
Lights off : Power to solenoid valves/output is not supplied at
the specified voltage. ( Voltage dropped to lower
than 20V. )
Lights on : Receiving data from GW
Lights off : No received data
01 )
)
