Mounting/Wiring; Dimensions - SMC Networks EtherNet/IP EX500-GEN1 Instruction Manual

Dimensions ( unit : mm )
1. SI unit for SV series valves ( EX500-S
79.4
68.5
2. SI unit for VQC series valves
( EX500-Q 01 )
80.3
64.4
( EX500-Q 02 )
66
80.3
64.4
85.7
22
01 )
28.6
28
0
1
10.5
36
0
1
10.5
44

Mounting/Wiring

The mounting and removing methods of SI unit are as shown below.
Supply/exhaust block
assembly
SI Unit for SV Series Valves ( EX500-S
M3 10 : 2 pcs.
( Hexagon socket head cap
screw ( with spring washer ))
SI Unit for VQC Series Valves ( EX500-Q
NOTE
Holding with hand so that there will be no gap between SI unit and Air supply/exhaust
block assembly, tighten the bolts. Be sure to tighten each bolt by specified tightening
torque. ( Tightening torque : 0.6N m )
For branch wiring method, refer to subsection "Wiring" ( page 15 ) of section "EX500"
Note 1
in this manual. As the power to output devices such as solenoid valve is supplied by
branch wiring ( branch cable with M12 connector ), there is no need to supply power
individually.
For mounting/installation methods of solenoid valve, manifold, etc., refer to the
Note 2
catalogs, instruction manuals, technical data, etc. of each valve series.
When connecting general purpose output block only, refer to subsection "Mounting"
( page 34 ) of section "EX9 Series General Purpose Output Block" in this manual.
M3 30 : 4 pcs.
( Plus-minus slot
round head screw )
01 )
Supply/exhaust block
assembly
01 )
23
