Page 3 In the attached Warranty Booklet you will also find a description of the Services that Fiat offers to its customers, the Warranty Certificate and the detail of the terms and conditions for maintaining its validity.
Page 4 ELECTRICAL ACCESSORIES If, after buying the vehicle, you decide to add electrical accessories (with the risk of gradually draining the battery), visit a Fiat Dealership. They can calculate the overall electrical requirement and check that the vehicle's electrical system can support the required load.
Page 5 USE OF THE OWNER HANDBOOK OPERATING INSTRUCTIONS Each time direction instructions (left/right or forwards/backwards) about the vehicle are given, these must be intended as regarding an occupant in the driver's seat. Special cases not complying with this rule will be properly specified in the text. The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the image do not correspond to the actual arrangement of your vehicle.
Page 6 WARNINGS AND PRECAUTIONS While reading this Owner Handbook you will find a series of WARNINGS to prevent procedures that could damage your vehicle. There are also PRECAUTIONS that must be carefully followed to prevent incorrect use of the components of the vehicle, which could cause accidents or injuries.
Page 7 If after buying the vehicle, you decide to install electrical accessories that require a permanent electrical supply (e.g. radio, satellite anti-theft system, etc.) or accessories that in any case burden the electrical supply, contact a Fiat Dealership, whose personnel will check whether the vehicles's electrical system is able to withstand the load required, or whether it needs to be integrated with a more powerful battery.
Page 8 Due to a large number of accessories and replacement parts of different manufactures available in the market, it is not possible, not only for FCA Italy S.p.A. but also an authorised Fiat Dealership, to check whether the attachment or installation of such parts affects the overall safety of your vehicle.
Page 9 GRAPHICAL INDEX GETTING TO KNOW YOUR VEHICLE KNOWING THE INSTRUMENT PANEL SAFETY STARTING AND DRIVING IN AN EMERGENCY SERVICING AND MAINTENANCE TECHNICAL SPECIFICATIONS INDEX...
Page 11: Table Of Contents
GRAPHICAL INDEX HEADLIGHTS OUTSIDE REAR VIEW MIRRORS ENGINE Bulb types ..... 235 Adjustment ..... 40 Checking levels .
Page 12 REAR LIGHTS Bulb types ..... 235 Bulb replacement ....235 LOAD COMPARTMENT Cargo loads .
Page 13: Table Of Contents
AIR VENTS HEATER/CLIMATE CONTROL GLOVE COMPARTMENT Ventilators ..... . 56 Control panel ....58 Glove box .
Page 14: Table Of Contents
GETTING TO KNOW YOUR VEHICLE In-depth knowledge of your new vehicle KEYS ....13 starts here. IGNITION SWITCH ... .24 DOORS .
Page 15: Keys
Do not leave anywhere that is from your Fiat Dealership in the event exposed to direct sunlight, for example the original keys are lost. on the dashboard.
Page 16 Press the LOCK switch (1). All the key, take your vehicle and all the keys doors will be locked. The turn-signal to a Fiat Dealership. All the keys have to AGZ000576 lamps will blink once. When they are be re-registered in the immobilizer...
Page 17 NOTE Functions can be modified as NOTE The keyless entry system does Activating the operation confirmation stated below. Please consult a Fiat not operate in the following conditions: function (blinking of the turn-signal Dealership. The key is left in the ignition switch...
Page 18 Fiat mark facing AHA106809 Keyless operation key: up to 4 keys. you. If the Fiat mark is not facing you when you open the key case, the 2. With the Fiat mark facing you, insert switches may come out.
Page 19 This key is necessary for the keyless operation system. Please Coin type battery CR1620 locking and unlocking the doors, consult a Fiat Dealership. starting the engine and otherwise The keyless operation key uses an Keyless operation key operating the vehicle, so before locking ultra-weak electromagnetic wave.
Page 20 Fiat Dealership. Refer to NOTE Locking and unlocking operate the key is outside the vehicle. “Procedure for replacing the key only when you press a door switch that battery”.
Page 21 Dead Lock System, pressing the stated below. For further information, When you are carrying the keyless driver’s or front passenger’s door please contact a Fiat Dealership. operation key, if you press the driver’s lock/unlock switch (A) two times in or front passenger’s door lock/unlock...
Page 22 AG0010823 AHA105440 NOTE Only use the emergency key for 1 — Lock emergencies. If the keyless operation 2 — Unlock key battery wears out, replace it as Operation of the Dead Lock System quickly as possible so that you can use For vehicles equipped with the Dead the keyless operation key.
Page 23 3 seconds switch with one of the doors not completely closed. Keyless The battery of the keyless Replace the battery as soon as possible at a Fiat Blinks No sound operation operation key has worn out. Dealership. system...
Page 24 Keyless There is a fault in the keyless If the warning lamp illuminates, please contact a Fiat Illuminates No sound operation operation system.
Page 25 Illuminates No sounds immobilizer (Anti-theft starting engine again. If the warning is not cancelled, system system). contact a Fiat Dealership. Unlock the steering wheel lock following the Inner buzzer Steering wheel Blinks Steering wheel does not unlock. procedure of reference page. Refer to “Steering...
Page 26: Ignition Switch
You can dispose of them AG0004466 either in the correct containers as specified For vehicles equipped with A/T, when by law or by taking them to a Fiat removing the key, first set the selector Dealership, which will deal with their LOCK lever to the “P”...
Page 27 ENGINE SWITCH transponder inside the key sends must match the one registered in the (where provided) immobilizer computer. Refer to In order to prevent theft, the engine will “Electronic immobilizer (Anti-theft not start unless a pre-registered keyless starting system)”. operation key is used. (Engine Changing the operation mode immobilizer function) If you are carrying the keyless operation key, you can start...
Page 28 (e.g. an attempted theft), have it running, doing so will cause the battery to checked over by a Fiat Dealership before be discharged. driving again. 3) Do not turn the key to the “START”...
Page 29: Doors
11) 12) 13) operate the switch. Immediately contact your Fiat Dealership. NOTE To prevent the key from being 6) When the engine is not running, put the locked inside the vehicle, neither the operation mode in OFF.
Page 30 To lock without using the key To open or close the rear door Driver’s door with key (Club cab) Using the key on the driver’s door locks You can open or close the rear door or unlocks. while the front door is opened. 1.
Page 31 (C) to lock all of unexpected accident occurs. If you wish to activate or deactivate the doors. The turn-signal lamps will these functions, please contact a Fiat blink once. Dealership. 4. Press the switch again within 2 seconds. The turn-signal lamps will blink three times to show that the Dead Lock System has been set.
Page 32 System is set causes the turn-signal front passenger’s door lock/unlock lamps to blink three times, so it is switch (C) and automatic locking. For possible to confirm that the Dead Lock details, please contact a Fiat System is set. Dealership. AHA101862 Cancelling the system...
Page 33 Child protection helps prevent doors To close from being opened accidentally, Raise the rear gate and close with especially when small children are in the enough force to latch the assembly rear seat. securely into position. A lever is provided on each rear door. If the lever is set to the locked position, the rear door cannot be opened using the inside handle.
Page 34 If you open the rear door with following conditions, have the vehicle the front seat belt being worn, the inspected at a Fiat Dealership immediately. occupant of the front seat may be 1– The door does not lock automatically...
Page 35: Seats
SEATS Power type (where provided) 27) Before driving, make sure that the rear gate is securely closed. If the rear gate SEAT ADJUSTMENT opens while driving the vehicle, objects Adjust the driver’s seat so that you are stored in the cargo area could fall out onto comfortable and that you can reach the the road.
Page 36 Passenger’s seat (Single cab and Double cab) To access the onboard tool kit (Single cab): fold forward the seatback of the passenger’s seat. Refer to “Tools, jack and jack handle”. Pull the band and fold the seatback forward. To recline the seatback: pull the band and then learn backward to the desired position, and release the band.
Page 37 NOTE Do not climb or sit on the Securely retain the seat cushion by 37) It is extremely dangerous to ride in the armrest. Doing so could damage the hooking the retaining band (A) onto the cargo area of a vehicle. Also, the cargo armrest.
Page 38: Head Restraints
HEAD RESTRAINTS 43) The reclining mechanism of the front 11) Operate in the “HI” position for quick manual seat's seatback is spring loaded, heating. Once the seat is warm, set the 47) 48) 49) 50) 51) 52) causing it to fold the seatback forward heater switch to the “LO”...
Page 39 The head restraint height of the outer seat in the rear seat cannot be adjusted. To remove Lift the head restraint with the height adjusting knob (A) pushed in. To install Make sure that the head restraint is facing the correct direction, and then insert it into the seatback while pressing AHA103026 AHA103042...
Page 40: Adjustment
STEERING WHEEL 52) The shape and size of the head WARNING restraint differs according to the seat. STEERING WHEEL Always use the correct head restraint HEIGHT AND REACH provided for the seat and do not install the ADJUSTMENT head restraint in the wrong direction. 47) All adjustments must only be carried (Vehicles equipped with the reach out with the vehicle stationary and the...
Page 41: Steering Wheel Lock
To unlock illuminates. Immediately stop the vehicle in a safe place and contact a Fiat The following methods can be used to Dealership. unlock the steering wheel. Put the operation mode in ACC.
Page 42 HORN SWITCH REAR VIEW MIRRORS Press the steering wheel on or around WARNING the horn mark. INSIDE REAR VIEW Type 1 MIRROR 53) Any steering wheel position adjustment should only be carried out with the vehicle 56) 57) 58) 59) stationary and the engine turned off.
Page 43 NOTE Do not hang items on, or spray glass cleaner on the sensor (1), as reduced sensitivity could result. OUTSIDE REAR VIEW MIRRORS To adjust the mirror position 56) 57) 58) Manual outside rear view mirrors Adjust the mirror surface by hands as AA0022369 AA0001425 indicated by the arrows.
Page 44 AH3100434 AHA104935 AA0022398 1. Place the lever (A) to the same side For vehicles with mirror retractor NOTE Be careful not to get your hands as the mirror whose adjustment is switch trapped while a mirror is moving. desired. With the ignition switch or the operation NOTE If you move a mirror by hand or 2.
Page 45 AA0110220 Functions can be modified as stated below. Please consult a Fiat Dealership: NOTE The heater mirrors can be Automatically extend when the turned on automatically. For further driver’s door is closed, and then the information, we recommend you to following operation is performed.
Page 46: Headlamps
EXTERNAL LIGHTS WARNING IMPORTANT COMBINATION HEADLAMPS AND DIPPER SWITCH 56) As the driver's exterior mirror is curved, 20) It is possible to retract and extend the it may slightly alter the perception of mirrors by hand. After retracting a mirror Headlamps distance of the reflected image.
Page 47 NOTE If the lamps do not turn on or off OFF— all lamps off further information, contact a Fiat Dealership. with the switch in the “AUTO” position, — position, tail, licence plate and manually operate the switch and we instrument panel lamps on...
Page 48 For further will also illuminate. SWITCH information, we recommend you to (where provided) consult a Fiat Dealership. Lamp monitor buzzer The angle of the headlamp beam varies If the following operation is performed, depending upon the load carried by the a buzzer will sound to remind the driver vehicle.
Page 49 Changing of the tone of a sounding buzzer as the turn-signal lamps flash. For further information, we recommend AA0061205 you to consult a Fiat Dealership. AHA101383 A — Turn-signals: when making a normal turn, use position (A). The lever will return automatically when cornering...
Page 50 FOG LAMP SWITCH NOTE Do not use fog lamps except in conditions of fog, otherwise excessive (where provided) lamp glare may temporarily blind Front fog lamp switch oncoming vehicle drivers. The front fog lamps can be operated Rear fog lamp switch while the headlamps or tail lamps are The rear fog lamp can be operated on.
Page 51 High intensity discharge headlamp type Do not need any adjustment. Halogen headlamp type Mask the headlamps according to the next procedure. Turn the headlamp off and wait until the headlamps got cold.According to the illustrations, prepare the sticker (A) to stick the headlamp surface of right and left.Seeing from the headlamp front, position (C) of the sticker and the central mark (B)
Page 52: Interior Lamps
INTERIOR LAMPS Rear 61) Daytime running lights cannot replace dipped beam headlights when driving at night or through tunnels. The use of daytime running lights is governed by the highway code of the country in which you are driving. Comply with legal requirements.
Page 53 NOTE The time until the lamp goes off (delayed off) can be adjusted. For Auto cut-out function: details, please consult a Fiat Dealership. if the lamp is left switched on with the ignition switch is in the “LOCK” or NOTE The auto cut-out function “ACC”...
Page 54: Operation
AA0069881 A — Fast B — Slow NOTE The speed-sensitive-operation function of the windscreen wipers can be deactivated. For further information, we recommend you to consult a Fiat Dealership. AA0068204 Misting function AJA104364 MIST — Misting function. The wipers Move the lever in the direction of the...
Page 55 (except put in the “AUTO” position when the NOTE Contact a Fiat Dealership when vehicle-speed sensitive). For further vehicle is stationary and the ambient replacing the windscreen or reinforcing temperature is about 0 °C or lower.
Page 56 Misting function Headlamp washer switch Move the lever in the direction of the The headlamp washer can be operated arrow and release, to operate the with the ignition switch or the operation wipers once. Use this function when mode in ON or ACC and the lamp you are driving in mist or drizzle.
Page 57 Do not use the wipers when the intervene. If operation is not restored, IMPORTANT glass is dry. They may scratch the glass contact a Fiat Dealership. 64) Streaks of water may cause surface and the blades wear out unnecessary blade movements.
Page 58: Ventilators
AIR CONDITIONING NOTE On vehicles with air conditioning, the cool air from the ventilators may SYSTEM appear as a mist. This is due to moist Ventilators air being suddenly cooled by the air conditioning. This will clear after a few moments.
Page 59 The mode selection and air flowing from the ventilators Face position Foot/Face position Foot position Foot/Demister position Demister position NOTE For vehicles with the Start&Stop system, the windows may start to fog up while the system is operating. If this occurs, press the demister switch to remove fog from the windows.
Page 60: Control Panel
Heater/Manual air Mode selection dial conditioning To change the position of air flowing The heater/air conditioning can only be from the ventilators, turn the mode used while the engine is running. selection dial (refer to “Mode selection”). Control panel AHA101497 Temperature control dial Turn the temperature control dial clockwise to make the air warmer.
Page 61 Air conditioning switch NOTE For maximum heat, set the Air selection lever blower speed at the 3rd position. To change the air selection, use the air Push the switch to turn the air selection lever. conditioning on, indicator lamp (A) will Cooling (Manual air conditioning) Outside air is introduced into come on.
Page 62 Demisting of the windscreen and NOTE To demist effectively, direct the door windows air flow from the side ventilators towards the door windows. Do not set the temperature control dial For ordinary demisting to the max. cool position. Cool air will blow against the window glasses and prevent demisting.
Page 63: System
AUTOMATIC CLIMATE CONTROL AIR CONDITIONER (where provided) The air conditioner can only be used while the engine is running. Automatic climate control system AH1100300 1. Temperature control switch 2. Air conditioning switch 3. MODE switch 4. Blower speed selection switch 5. Air selection switch 6.
Page 64 Automatic dual-zone climate control system AA1008694 1. Driver’s side temperature control switch (LHD vehicles) — Passenger’s side temperature control switch (RHD vehicles) 2. Air conditioning switch 3. Blower speed selection switch 4. MODE switch 5. Passenger’s side temperature control switch (LHD vehicles) —...
Page 65 Air conditioning control panel — Temperature control switch NOTE There is an interior air temperature sensor (A) in the illustrated Standard mode Press of the temperature position. Never place anything on top of control switch to the desired the sensor, since doing so will prevent it temperature.
Page 66 In dual mode, the For further information, we recommend contaminated use the recirculation driver’s side and the passenger’s side you to consult a Fiat Dealership. position. Switch to the outside position temperature can be set separately by periodically to increase ventilation so Refer to “Customising the air...
Page 67 Customising the air selection Customising the air conditioning switch Functions can be changed as desired, as stated below. Functions can be changed as desired, as stated below. Enable automatic air control — When Enable automatic air conditioning the AUTO switch is pressed, the air control —...
Page 68 OFF switch Demister switch Operating the system in automatic mode Press the switch to turn off the air When this switch is pressed, the mode conditioning system. changes to the mode. The indicator lamp (A) will come on. The selected mode is shown in the display (B) (refer to “Mode selection").
Page 69 1. Press the demister switch to change Using the system in manual mode 1. Set the air selection switch to the outside position. to the position. Blower speed and ventilator mode may be controlled manually by setting the 2. Set the MODE switch to the 2.
Page 70 poor lubrication of the compressor Too much cooling is not good for the Manual type internal parts and to maintain the air health. The inside air temperature conditioning in the best operating should only be 5 to 6 °C below the condition.
Page 71 NOTE The demister switch is not to Setting change method — Hold 24) When using the mode selection dial melt snow but to clear mist. Remove down the rear window demister switch between the positions, prevent snow before use of the demister switch. for about 10 seconds or more.
Page 72: Driver's Switches
WINDOW Type 2 If the switch for the driver’s window is MANUAL WINDOW fully pressed down/pulled up, the door CONTROL window automatically opens/closes completely. If you want to stop the window movement, operate the switch lightly in the reverse direction. Passenger’s switches The passenger’s switches can be used AHA105509...
Page 73 Safety mechanism (driver’s window NOTE If the battery terminals are Lock switch only) disconnected or the fuse for electric When this switch is operated, the window is replaced, the safety passenger’s switches cannot be used 74) 75) 76) mechanism will be cancelled and the to open or close the door windows and When the door window is automatically door window will not automatically...
Page 74: Catalytic Converter
CATALYTIC DIESEL 72) A child may tamper with the switch at CONVERTER PARTICULATE the risk of its hands or head being trapped FILTER (DPF) in the window. The exhaust gas scavenging devices 73) When driving with a child in the vehicle, used with catalytic converter are (where provided) please press the window lock switch to...
Page 75 Flashing of the DPF warning lamp trouble and DPF damage. indicates an abnormality in the DPF system. Have the system inspected by a Fiat Dealership. WARNING 78) The diesel particulate filter (DPF) AHA104948 reaches high temperatures during normal operation.
Page 76: Engine Compartment
ENGINE NOTE Only open the bonnet when the wipers are in the parked position. COMPARTMENT Failure to do so may cause damage to To open the bonnet, wiper arms or front 1. Pull the release lever towards you to windscreen. unlock the bonnet.
Page 77: Cargo Loads
CARGO AREA remember that the dynamic 82) For safety reasons, the bonnet must behaviour of the vehicle is affected by always be properly closed while the car is CARGO LOADS the transported weight: in particular, the travelling. Therefore, make sure that the 83) 84) bonnet is properly closed and that the lock stopping distances are longer,...
Page 78: Trailer Towing
Never exceed the maximum towable device mounted that meets all relevant loads on the vehicle may have major weight with brake and the maximum regulations in your area, consult a Fiat repercussions on fuel consumption. trailer-nose weight as listed in the Dealership.
Page 79 Towing bar mounting specifications NOTE The values under item 9 are Single Club Double applicable to unladen vehicles. The See the following table for fixing points value can also be varied depending on (A) for the towing bar. the tyre size, optional equipment and 30 mm 30 mm 30 mm...
Page 80: Interior Features
It is recommended a lower gear in sports mode on slopes or at low speed, taking care to keep the engine speed below the red zone. AHA106564 WARNING 89) Danger of Accident! A towing bar should be fitted according to Fiat AHA106548 Dealership guidelines.
Page 81 ASHTRAY (where provided) 32) 33) 34) 35) To use the movable ashtray, open the lid. AHA104805 A — Push all the way in. The cigarette lighter will automatically return to its original position with a “click” when ready. Pull it out for use. After use, insert the cigarette lighter to its original position in the socket.
Page 82 The digital clock indicates the time with pushed in. Pull it out and have the the ignition switch or the operation problem corrected at Fiat Dealership. mode is in ON or ACC. When the cigarette lighter socket is To set the time...
Page 83 Type 2 NOTE When using a commercially NOTE When the lamps are illuminated available USB connector cable with the lamp switch in the connected to the USB input terminal or or “AUTO” position (vehicles with commercially available HDMI connector automatic lamp control), the glove box cable connected to the HDMI input lamp illuminates, refer to “Combination terminal, if you hold up extra length of...
Page 84 Upper box Sunglasses holder (where provided) To open the upper box, raise the lid. To open, push the lid. AHA101729 For the rear seat AHA101703 AHA114749 In order to use the cup holder, allow the armrest to drop down. Lower box To open the lower box, raise the upper NOTE The holder may not be able to box.
Page 85 NOTE Do not hang heavy luggage (more than about 4 kg) on the hook. Doing so could cause damage to the hook. ASSIST GRIP (where provided) These grips are to support the body by hand while seated in the vehicle. AHA106115 AHA101745 NOTE Do not store cup or drink can in...
Page 86: Fuel Selection
34) Put out matches and cigarettes before make the engine malfunction. For they are placed in the ashtray. details, please contact your Fiat 35) Always close the ashtray. If left open, Dealsership. other cigarette butts in the ashtray may be...
Page 87 Graphical expression for consumer 42) Do not use more than 7% information IMPORTANT concentration of fatty acid methyl esters Identifier for diesel-type fuels (bio diesel) by volume. Use of more than 7% concentration would adversely affect The symbol shown below helps you to the engine’s performance and durability.
Page 88: Filling The Fuel Tank
FILLING THE FUEL TANK 98) 99) 100) 101) 102) 103) 104) 105) 106) 107) 108) Fuel tank capacity: 75 litres. 1. Before filling with fuel, stop the engine. 2. The fuel tank filler is located on the rear left side of your vehicle. Type 1,2 1.
Page 89 105) If the fuel cap must be replaced, use only a Fiat genuine part. 106) Since the fuel system may be under pressure, remove the fuel cap slowly. This...
Page 90: Entering Or Leaving The Vehicle
ENTERING OR LEAVING THE VEHICLE AHA113612 110) WARNING 110) To avoid slipping and damaging the painted surface, do not step on the cover of side step (A).
Page 91 KNOWING THE INSTRUMENT PANEL This section of the booklet gives you all INSTRUMENTS ....90 the information you need to MULTI INFORMATION DISPLAY ..90 understand, interpret and use the INDICATOR AND WARNING LAMPS.98 instrument panel correctly.
Page 92: Instruments
INSTRUMENTS MULTI INFORMATION DISPLAY IMPORTANT Always stop the vehicle in a safe place before operating. The following 43) When driving, watch the tachometer to information is included on the multi make sure that the engine speed indication information display: odometer, does not rise into the red zone (excessive tripmeter, average fuel consumption engine r/min).
Page 93 INFORMATION DISPLAY Each time you lightly press the multi information display switch (A), the display switches in the following order. AH1100371 1. Odometer 2. Tripmeter A 3. Tripmeter B 4. Meter illumination control 5. Driving range display 6. Average fuel consumption display 7.
Page 94 Odometer range falls below approximately 50 km (30 miles), “---” is displayed. The odometer indicates the distance travelled NOTE The driving range is determined based on the fuel consumption data. Tripmeter This may vary depending on the driving The tripmeter indicates the distance conditions and habits.
Page 95 NOTE When the ignition switch or the For information on how to change the 111) average fuel consumption display operation mode is ON again, the Engine coolant temperature display setting, refer to “Changing the function accumulated time will be reset. This indicates the engine coolant settings”.
Page 96 NOTE If fuel is added with the ignition Service reminder 2. This informs you that a periodic switch or the operation mode is ON, inspection is due. Please consult a Fiat Displays the approximate time until the the fuel gauge may incorrectly indicate Dealership.
Page 97 If you accidentally reset the display, When the engine switch or the AHA101354 consult a Fiat Dealership. operation mode is in the following conditions, the average fuel Changing the function settings 113) 114) consumption display is automatically The “Average fuel consumption reset...
Page 98 longer. For vehicles equipped with the Changing the temperature unit keyless operation system: the operation The display unit for outside temperature mode is in ACC or OFF for about can be switched. 4 hours or longer. 1. When you lightly press the multi information display switch a few times, IMPORTANT The average fuel the information display switches to the...
Page 99 IMPORTANT 44) Do not drive with an extremely low fuel level, running out of fuel could cause damage to the fuel system. 45) The customer is responsible for making sure that periodic inspection and maintenance are performed. Inspections and maintenance must be performed to prevent accidents and malfunctions.
Page 100: Indicator And Warning Lamps
INDICATOR AND WARNING LAMPS AH1100948 1. Front fog lamp indicator lamp* 2. Turn-signal indicator lamps/Hazard warning indicator lamps 3. High-beam indicator lamp 4. Start&Stop indicator lamp* 5. Lane departure warning (LDW) standby indicator lamp (green)* — Lane departure warning (LDW) lamp (amber)* 6. Position lamp indicator lamp* 7. Lane departure warning (LDW) system ON indicator lamp* 8. Rear fog lamp indicator lamp 9.
Page 101 Indicator lamps Indicator lamps What it means Turn-signal indicator lamps/Hazard warning indicator lamps These indicator lamps blink in the following situations. When the turn-signal lever is moved to activate a turn-signal lamp. Refer to “Turn-signal lever”. When the hazard warning flasher switch is pressed to activate the hazard warning lamps. Refer to “Hazard warning flasher switch”.
Page 102 Indicator lamps What it means Position lamp indicator lamp* This indicator lamp illuminates while the position lamps are on. Diesel preheat indicator lamp This indicator lamp shows the glow plug preheat condition. Except for vehicles equipped with the keyless operation system: When the ignition switch is turned to the “ON” position, the lamp illuminates. As the glow plug becomes hot, the lamp goes out and the engine can be started.
Page 103 Indicator lamps What it means ESC indicator lamp ESC OFF indicator lamp The indicator lamps should illuminate when the ignition switch is turned to the “ON” position or the operation mode is put in ON, and should go off after a few seconds. If the indicator lamps stay on or do not illuminate when the ignition switch is turned to the “ON”...
Page 104 Warning lamps Warning lamps What it means Brake warning lamp This lamp illuminates when the ignition switch is turned to the “ON” position or the operation mode is put in ON, and goes off after a few seconds. Always make sure that the lamp goes off before driving. With the ignition switch or the operation mode in ON, the brake warning lamp illuminates under the following conditions: When the parking brake has been applied.
Page 105 Warning lamps What it means Charge warning lamp This lamp illuminates when the ignition switch is turned to the “ON” position or the operation mode is put in ON, and goes off after the engine has started. Oil pressure warning lamp This lamp illuminates when the ignition switch is turned to the “ON”...
Page 106 Warning lamps What it means SRS warning lamp There is a supplemental restraint system (“SRS”) warning lamp on the instrument panel. The system checks itself every time the ignition switch is turned to the “ON” position or the operation mode is put in ON.
Page 107 If the engine starts, the vehicle can control function will be suspended to driving at high speeds or applying the be used as normal, but a Fiat Dealership brakes suddenly. Furthermore, immediately must be contacted as soon as possible.
Page 108 60) Any of the following indicates that the is running, avoid driving at high speeds and ABS is not functioning and only the have the system inspected by a Fiat standard brake system is working. (The Dealership as soon as possible. Accelerator...
Page 109 SAFETY The chapter that you are about to read SEAT BELTS ....108 is very important: it describes the safety SBR SYSTEM ....110 systems with which the car is equipped PRETENSIONERS AND FORCE and provides instructions on how to...
Page 110: Seat Belts
If button on the buckle. problems occur, we recommend you to have the seat belts inspected by a Fiat Dealership as soon as possible. AHZ101489 NOTE You can check if the belt locks...
Page 111 When the seatback webbing and for cracked or deformed is reclined, there is greater risk that the a Fiat Dealership. Incorrect repair or metallic parts. Replace the belt passenger will slide under the belt, replacement could reduce the assembly if defective.
Page 112: Sbr System
SBR SYSTEM 66) Do not insert any foreign objects NOTE If the seat belt subsequently (pieces of plastic, paper clips, buttons, etc.) Seat belt reminder in the buckle or retractor mechanism remains unfastened, the warning lamp For the driver and the front fig.
Page 113 Adjustable seat belt anchor (front “ON” position or the operation mode is put in ON while a seat belt is not seats of Club cab and Double cab) fastened, the warning lamp comes on The seat belt anchor height can be for approximately 30 seconds to remind adjusted.
Page 114 71) If you need to scrap the vehicle, please 133) The pretensioner may be used only consult a Fiat Dealership. It is important to Except for vehicles equipped with the once. After it is triggered, have it replaced do so because unexpected activation of keyless operation system: the ignition at a Fiat Dealership.
Page 115: Child Restraint
Contact a Fiat according to the size of the child. This Dealership should intervention be is required by law in most countries.
Page 116 Accident statistics indicate that the child restraint system. children of all sizes and ages are safer RESTRAINT SYSTEM SHOULD BE 138) Fiat recommends fitting the child when properly restrained in the rear seat INSTALLED IN THE REAR SEAT restraint system according to the rather than in the front seat (Club cab and instructions, which must be included.
Page 117 144) Incorrect fitting of the child restraint 149) Do not move the front or rear seat if a 156) When the child restraint system is not system may result in an inefficient child is seated on it or on the dedicated in use, keep your child restraint system child restraint system.
Page 118 SUITABILITY FOR ISOFIX AND OTHER SEATING POSITIONS Suitability for ISOFIX positions Double cab Size class and ISOFIX positions Recommended Child Restraint UN-R44 Approval Mass Group Fixture Rear Outboard Systems Number — — ISO/L1 Carrycoat — — ISO/L2 0 — Up to 10 kg —...
Page 119 Size class and ISOFIX positions Recommended Child Restraint UN-R44 Approval Mass Group Fixture Rear Outboard Systems Number G 0/1 S ISOFIX (Child restraint system for East area) : MZ314390E G 0/1 S ISOFIX (Child restraint system for ISO/R2 Central- South area) : MZ314390CS G 0/1 S E4-04443718 ISOFIX (Child restraint system for North...
Page 120 Important note: Front passenger seat is NOT suitable for rearward facing child restraint system when the passenger airbag is active. It is suitable for universal child restraint system when the airbag has been disabled (refer to “Supplemental restraint system — Airbag”).
Page 121 Suitability for various seating positions SINGLE CAB Seating Position Mass Group Recommended Child Restraint Systems UN-R44 Approval No. Front Passenger 0 — Up to 10 kg — — 0+ — Up to 13 kg — E1-04301146 G 0/1 S ISOFIX (Child restraint system for East area): MZ314390E G 0/1 S ISOFIX (Child restraint system for E4-03443416...
Page 122 Suitability for various seating positions CLUB CAB Seating Position Recommended Child Restraint Mass Group UN-R44 Approval No. Front Passenger Systems Activated Deactivated Airbag Airbag 0 — Up to 10 kg — — 0+ — Up to 13 kg U, L BABY-SAFE plus: MZ314393 E1-04301146 G 0/1 S ISOFIX (Child restraint...
Page 123 Seating Position Mass Group Recommended Child Restraint Systems UN-R44 Approval No. Rear Outboard 0 — Up to 10 kg — — 0+ — Up to 13 kg BABY-SAFE plus: MZ314393 E1-04301146 G 0/1 S ISOFIX (Child restraint system for East area): MZ314390E G 0/1 S ISOFIX (Child restraint system for E4-03443416 1 —...
Page 124 Suitability for various seating positions DOUBLE CAB Seating Position Recommended Child Restraint Mass Group UN-R44 Approval No. Front Passenger Systems Activated Deactivated Airbag Airbag 0 — Up to 10 kg — — 0+ — Up to 13 kg U, L BABY-SAFE plus: MZ314393 E1-04301146 G 0/1 S ISOFIX (Child restraint...
Page 125 Seating Position Rear Recommended Child Restraint Mass Group Rear Centre UN-R44 Approval No. Outboard Systems 0 — Up to 10 kg — — 0+ — Up to U, L U, L BABY-SAFE plus: MZ314393 E1-04301146 13 kg G 0/1 S ISOFIX (Child restraint system for East area): MZ314390E G 0/1 S ISOFIX (Child restraint system E4-03443416...
Page 126 Installing a child Tether anchorage location restraint system to the There are 2 child restraint anchorage lower anchorage points on the vertical panel, located (ISOFIX child restraint behind the rear seat. mountings) and tether These are for securing a child seat anchorage (Double cab) tether strap to each of the 2 rear seating positions in your vehicle.
Page 127 AHA106434 AHA106636 AHA106610 A. Connector 7. Put your hand in the opening of the 5. Tip the armrest forward. Open the B. Lower anchorage two fasteners, attach the tether strap two fasteners (D) that’s located in the hook (E) to the tether anchorage (F), space where the armrest are stowed.
Page 128 To remove Remove the child restraint system in IMPORTANT accordance with the instructions provided by the child restraint system’s manufacturer. 73) When attaching a child restraint system to the rear seat, adjust the front seat to Installing a child restraint system to prevent the front seatbacks from touching a 3-point type seat belt (with the child's feet and child restraint system.
Page 129: Driver Airbag
SUPPLEMENTAL The SRS side airbags (if so equipped) are designed to supplement properly RESTRAINT SYSTEM worn seat belts and provide the driver AIRBAG and front passenger with protection The information for SRS airbags against chest injuries in certain includes important information moderate-to-severe side impact concerning the driver’s and front collisions.
Page 130 Only when the ignition switch or the operation mode is under the following conditions, the airbags will operate. Except for vehicles equipped with the keyless operation system: the ignition switch is in the “ON” or “START” position. Vehicles equipped with the keyless operation system: the operation mode is in ON.
Page 131: Glove Box
indicator will stay on to show that the The front passenger’s airbag is now front passenger’s airbag is not deactivated and will not deploy until operational. When the front passenger’s switched on again. airbag ON-OFF switch is turned ON, Driver’s and front passenger’s the OFF indicator goes off, and the ON airbag system indicator comes on for approximately...
Page 132 Driver’s knee airbag system (where Your seat belts will help keep you a safe provided) distance from the steering wheel and instrument panel during the initial The driver’s knee airbag is located stages of airbag deployment. The initial under the steering wheel. The driver’s stage of airbag inflation is the most knee airbag is designed to deploy at the forceful, and can possibly cause serious...
Page 133 AHA103143 AHA103156 AHA103169 1. When colliding with a utility pole, 1. Rear end collisions 2. Side 1. Collision with an elevated collisions 3. Vehicle rolls onto its side median/island or kerb 2. Vehicle travels tree or other narrow object. 2. Vehicle or roof slides under the rear body of a truck over a deep hole/pothole 3.
Page 134 Curtain airbag system (where provided) 185) 186) The curtain airbags are contained in the front pillars and roof side rail. The curtain airbag is designed to inflate only on the side of the vehicle that is impacted, even with no passenger in the front seat or rear seat.
Page 135 Deployment of side airbags and Therefore, for your safety and the safety curtain airbags* of all occupants, be sure to always properly wear your seat belts. The side airbags and curtain airbags ARE DESIGNED TO The side airbags and curtain DEPLOY when...
Page 136 Fiat Dealership injured. Airbags inflate very fast, and with 187) 188) 189) 190) 191) 192) 193) 194) 195) great force.
Page 137 We recommend Therefore, always deactivate the passenger you to have the system inspected by a Fiat Dealership. side airbag when a rearward facing child restraint system is installed on the front 177) Do not apply stickers or other objects passenger seat.
Page 138 Fiat Dealership. the door, in order to reduce risk of serious 196) We recommend any maintenance or front passenger.
Page 139 If the brake pedal is depressed is stored, you should have the SRS same time. suddenly, the brakes will be applied inspected by a Fiat Dealership. with more force than usual. NOTE Activating condition for the emergency brake system > It activates...
Page 140 In this situation, simply hold the brake Anti-lock brake system (ABS) pedal down firmly. Do not pump the (where provided) brake, which will result in reduced The anti-lock brake system (ABS) helps braking performance. prevent the wheels from locking up An operation noise is emitted from the when braking.
Page 141 When the ignition switch is set to the NOTE The electronic stability control function does not operate when the “ON” position or the operation mode is drive mode-selector is in the “4L” put in ON. position (Easy select 4WD), “4LLc” When the vehicle is driven for a while position (Super select 4WD II).
Page 142 NOTE If you continue to press the 203) To prevent failure of the ABS, be sure 211) Do not over-rely on the ESC. Even the “ESC OFF” switch after the electronic all 4 wheels and tyres are the same size ESC cannot prevent the natural laws of stability control function is turned off, and the same type.
Page 143 If this happens, have your than “P” or “N”. NOTE When reversing on an uphill vehicle inspected at a Fiat Dealership. slope, place the selector lever or The vehicle is completely stationary, gearshift lever into the “R” position.
Page 144 Fiat Dealership. WARNING 81) Do not stop the engine while the vehicle is moving. Stopping the engine...
Page 145: Starting And Driving
STARTING AND DRIVING Let’s get to the "heart" of the vehicle: ECONOMICAL DRIVING..144 seeing how you can exploit all of its DRIVING, ALCOHOL AND DRUGS .145 potential to the full. SAFE DRIVING TECHNIQUES ..145 RUNNING-IN We’ll look at how to drive it safely in any RECOMMENDATIONS .
Page 146 ECONOMICAL City traffic Cold engine starting DRIVING Frequent starting and stopping increases Starting of a cold engine consumes the average fuel consumption. Use roads more fuel. Unnecessary fuel For economical driving, there are some with smooth traffic flow whenever consumption is also caused by keeping technical requirements that have to be possible.
Page 147 DRIVING, ALCOHOL SAFE DRIVING Make sure that infants and small AND DRUGS TECHNIQUES children are properly restrained in accordance with the laws and Drunk driving is one of the most Driving safety and protection against regulations, and for maximum frequent causes of accidents. injury cannot be fully ensured.
Page 148 RUNNING-IN RECOMMENDATIONS During the running-in period for the first 1,000 km, it is advisable to drive your new vehicle using the following precautions as a guideline to aid long life as well as future economy and performance. Do not race the engine at high speeds. Avoid rapid starting, accelerating, braking and prolonged high-speed running.
Page 149 Vehicles with A/T Shift point Speed limit Vehicles with Vehicles with Easy select 4WD Vehicles with Super select 4WD II 2H, 4H 2H, 4H, 4HLc 4LLc 1st gear 15 km/h 15 km/h 5 km/h 20 km/h 5 km/h 2nd gear 35 km/h 35 km/h 15 km/h...
Page 150: Parking Brake
PARKING BRAKE To release IMPORTANT To park, fully apply the parking brake sufficiently to hold the vehicle. To apply 86) When you intend to apply the parking brake, firmly press the brake pedal to bring the vehicle to a complete stop before pulling the parking brake lever.
Page 151 PARKING On vehicles equipped with A/T, apply the parking brake and place the WARNING To park the vehicle, stop the engine, selector lever into the “P” (PARK) fully engage the parking brake and then position. If necessary, apply chocks to move the gearshift lever to 1st or “R”...
Page 152: Starting And Stopping The
STARTING AND Starting the engine NOTE If the engine is cold, the diesel preheat indicator lamp is on for a longer STOPPING THE Except for vehicles equipped with time. ENGINE the keyless operation system NOTE When the engine has not been 1.
Page 153 go out, indicating that preheating is uphill) or “R” (Reverse) (on a downhill) For vehicles equipped with the keyless operation system completed. The engine will start. position. For vehicles equipped with A/T, place the selector lever in the “P” 1. Fasten the seat belt. NOTE If the engine is cold, the diesel (PARK) position, and stop the engine.
Page 154 Fuel injection amount learning NOTE Remove the object or additional process key from the keyless operation key IMPORTANT before inserting the key into the key To keep exhaust emissions and engine slot. The vehicle may not be able to noise low, the engine very occasionally 89) In some cases, when the engine receive the registered ID code from the performs a learning process for the fuel...
Page 155: Turbocharger Operation
TURBOCHARGER 98) It is advisable not to demand maximum OPERATION performance from your vehicle (e.g. IMPORTANT excessive acceleration, long distances at (where provided) high speeds, excessively intense braking, etc.) during the initial period of use. Turbocharger 100) Do not run the engine at high speeds 99) A quick burst on the accelerator before (for example, by revving it or by 100) 101)
Page 156 START&STOP SYSTEM The Start&Stop system automatically stops and restarts the engine without operating the ignition switch or engine switch when the vehicle is stopped, such as at a traffic light or in a traffic jam, to reduce exhaust gases, increase fuel efficiency.
Page 157 After the engine restarts Check engine warning lamp is NOTE If the windows become fogged up each time the engine is stopped, we automatically, the vehicle speed has not illuminated or the indicator lamp is recommend you to deactivate the exceeded approximately 5 km/h.
Page 158 “N” (Neutral) position. If the indicator lamp blinks, the Start&Stop system is malfunctioning and will not operate. We recommend you to consult a Fiat Dealership.
Page 159: Manual Transmission
MANUAL 104) In the following cases, the engine will TRANSMISSION restart automatically even if the engine was stopped by the Start&Stop system. Pay The shift pattern is shown on the careful attention, otherwise an unexpected gearshift lever knob. To start off, accident might occur when the engine depress the clutch pedal all the way restarts: vehicle speed is 3 km/h or higher...
Page 160 2WD models Vehicles with Super select 4WD II 107) Do not coast in the “N” (Neutral) position. 108) Do not use the gearshift lever as a Shift point Speed limit Speed limit hand rest, because this can result in Shift point premature wear of the transmission shift 1st gear 30 km/h...
Page 161: Automatic Transmission
Immediately The selector lever (A) has 2 gates; the have your vehicle checked by a Fiat main gate (B) and the manual gate (C). Dealership. If you need to move the vehicle, shift the selector lever as follows.
Page 162 For LHD vehicles 1. Make sure the parking brake is fully applied. 2. Stop the engine if it is running. 3. Insert a straight blade (or minus) screwdriver with a cloth over its tip into the notch (A) of the cover. Pry gently as shown to remove the cover.
Page 163 In sports mode, gear shifts can be Selector lever positions made rapidly simply by moving the “P” PARK selector lever backward and forward. This position locks the transmission to For vehicles equipped with the shift prevent the vehicle from moving. The paddles, shift paddles at the steering engine can be started in this position.
Page 164 vehicle speeds. When this happens, a NOTE “A” indicator does blink only the buzzer sounds to indicate that a condition that the A/T positional switch is broken. It does not indicate in normal downshift is not going to take place. driving condition.
Page 165 Immediately service brake. For longer waiting “P” (PARK) or “R” (REVERSE) position or have your vehicle checked by a Fiat periods with the engine running, place you will lose engine braking. Dealership as soon as possible.
Page 166 In addition, the 2WD/4WD Have the vehicle inspected by a Fiat accident. operation indicator lamp and the Dealership as soon as possible.
Page 167 Drive mode-selector position and Drive mode-selector operation 2WD/4WD operation indicator lamp The drive mode is shown on the drive mode selector. Drive mode Indicator Driving selector lamp conditions position When Rear- driving on wheel dry paved drive road. When driving on 4-wheel rough, sand drive...
Page 168 Procedure To shift from Vehicles with manual transmission Vehicles with automatic transmission The drive mode-selector can be operated while the The drive mode-selector can be operated while the vehicle is either moving or stationary. When the vehicle is either moving or stationary. When the vehicle is not in motion, shift the selector lever to vehicle is not in motion, shift the gearshift lever to the “N”...
Page 169 “2H” <-> “4H” 2WD/4WD operation indicator lamp When the drive mode selector is set and low-range indicator lamp between 2H <–> 4H, the 2WD/4WD operation indicator lamp blinks while Selector the selection is in process. Take the Indicator lamp position following precautions when the indicator lamp is blinking.
Page 170 “4H” <-> “4L” The 2WD/4WD operation indicator release the accelerator pedal. Next, lamp will blink during shifting process hold down the clutch pedal (with manual transmission) or place the from “4H” to “4L” or vice versa, as the Selector transfer passes through the neutral selector lever in the “N”...
Page 171 The basic operation indicator lamp and low-range lamp continue to blink, have the vehicle position for indicator lamp indicates the drive checked by a Fiat Dealership as soon as Fulltime Super select mode-selector setting state. Refer to possible. 4WD II. When “2WD/4WD operation indicator lamp...
Page 172 Drive mode-selector operation The drive mode is shown on the drive mode selector knob. AHA103648 Turn the drive mode-selector Turn the drive mode-selector while holding it down The drive mode-selector should be positioned in accordance with the following operating conditions:...
Page 173 To shift from Procedure for vehicles with Manual Transmission The drive mode-selector can be operated while the vehicle is either moving or stationary. When the vehicle is not in motion, shift the gearshift lever to the “N” 2H or 4HLc (Neutral) position before operating the drive mode-selector.
Page 174 2WD/4WD operation indicator lamp Switching between 2H and 4H Switching between 4H and 4HLc and low-range indicator lamp Drive Drive mode Indicator lamp mode-selector Indicator lamp selector position position AHA104951 Drive mode switching in progress A. Front wheel lamp B. Centre differential lock lamp Drive mode C.
Page 175 Switching between 4HL and 4LLc NOTE The front and the rear wheel Blink lamps will blink during shifting process Illuminate from “4HLc” to “4LLc” or vice versa, as Drive Remain off the transfer passes through the neutral mode position. Be sure to operate the drive Indicator lamp selector NOTE When the drive mode-selector is...
Page 176: Rear Differential Lock
Restart the engine. The lamp should resume normal operation. If (A). the lamps continue to blink, have the 4. To deactivate the rear differential vehicle checked by a Fiat Dealership as lock, press the rear differential lock soon as possible. switch (B).
Page 177 Rear differential lock Operation indicator lamp state of rear Easy Super differential select select lock 4WD II Rear differential lock deactivated AHA106072 AHA104980 Switching in 137) progress The rear differential lock does not operate when the drive mode-selector is in “2H” position (Easy select 4WD), “2H”...
Page 178 The ESC and ABS functions are If the vehicle speed is 12 km/h or lower, When driving on rocky roads suspended while the rear differential turn the steering wheel from side to When the vehicle is unable to move lock is activated. ESC indicator lamp, side until the indicator lamp illuminates because one of the wheels is ESC OFF indicator lamp and ABS...
Page 179 The vehicle is unable to make a turn and 230) 231) the vehicle checked by a Fiat Dealership as may go straight ahead. soon as possible.
Page 180: Wheel Drive Operation
4 WHEEL DRIVE Driving on dry paved road and 139) Use the rear differential lock only as an highway OPERATION emergency measure when the vehicle is Select “2H” position (Easy select 4WD), stuck and cannot be freed with the drive By selecting 4-wheel drive, both axles “2H”...
Page 181 NOTE Avoid sudden braking, after such use. NOTE Fiat is not responsible to the acceleration, and turning; such operator for any damage or injury Climbing sharp grades operations could result in the vehicle caused or liability incurred by the Set the drive mode-selector to “4L”...
Page 182 A/T acceleration, and sharp turning; such oil cooler. operations could cause skidding and spinouts. After crossing a stream, be sure to have the following items inspected at a Fiat Dealership and take the necessary measures:...
Page 183 HANDLING OF If towing is necessary, we recommend WARNING 4 WHEEL DRIVE you to have it done by a Fiat Dealership or a commercial tow truck service. In VEHICLES the following cases, transport the 232) When attempting to rock your vehicle...
Page 184: Braking System
BRAKING SYSTEM IMPORTANT All the parts of the brake system are critical to safety. We recommend you to have the vehicle checked at regular 146) Always use tyres of the same size, intervals according to the service same type, and same brand which have no booklet.
Page 185: Cruise Control
CRUISE CONTROL A film of water can be formed on the brake discs or brake drums and WARNING (where provided) prevent normal braking after driving in heavy rain or through large puddles, or Cruise control is an automatic speed after the vehicle is washed. If this control system that keeps a set speed.
Page 186 A — CRUISE CONTROL ON/OFF Cruise control switches Type 1 switch Type 1 Used to turn on and off the cruise control. B — SET - switch Used to reduce the set speed and to set the desired speed. C — RES + switch Used to increase the set speed and to return to the original set speed.
Page 187 Type 2 Type 1 AHA112846 AHA108441 AA0110637 2. Accelerate or decelerate to your desired speed, then push down and NOTE When you release the SET - Type 2 release the SET - switch (B) when the switch (B), the vehicle speed will be set. indicator lamp is illuminated.
Page 188 Accelerator pedal To decrease the set speed Type 2 While driving at the set speed, use the There are 2 ways to decrease the set accelerator pedal to reach your desired speed. speed and then push down the SET - SET - switch switch (B) and release the switch Push down and hold the SET - switch...
Page 189 Type 1 Type 2 To temporarily increase the speed Depress the accelerator pedal as you would normally. When you release the pedal, you will return to your set speed. AHA108496 AA0110653 To deactivate Type 2 The set speed driving can be AA0001395 deactivated as follows: Press the CRUISE CONTROL...
Page 190 241) If the device is faulty, turn ring nut A to O, check the condition of the fuse and ways. contact a Fiat Dealership. When you depress the clutch pedal 242) When travelling with the device active, (on vehicles with M/T).
Page 191 “LIMIT” and the Speed Limiter’s cruise control and have your vehicle symbol, if you decrease the set speed inspected by a Fiat Dealership. and vehicle speed is more than set speed, control state “LIMIT” and the Speed Limiter’s symbol blinking starts AA0113771 but beep alert is delayed.
Page 192 Type 2 Speed Limiter information on the To start up multi information display area First of all, press the ON/OFF switch in The Speed Limiter information is order to power up the Speed Limiter displayed on the multi information when the ignition switch in the “ON”, display area in the combination meter.
Page 193 And, control state “LIMIT” is displayed Type 1 Type 1 in the combination meter. The set speed is displayed in the combination meter. And, control state “LIMIT” is displayed in the combination meter. AA0113797 AA0113784 Type 2 Type 2 AHA105017 To increase the set speed By using the RES + switch Push up the RES + switch continuously.
Page 194 Type 1 Type 2 By using the CANCEL switch, the accelerator pedal and the SET - switch Press the CANCEL switch (D) to deactivate the Speed Limiter. Control state “LIMIT” is disappeared and change control state “LIMIT OFF” in the combination meter. Type 1 AHA110578 AA0113814...
Page 195 By using the CANCEL switch, the Type 2 To decrease the set speed service brake and the SET - switch By using the SET - switch Press the CANCEL switch (D) to Push down the SET - switch (B). deactivate the Speed Limiter. Control Then the set speed displayed in the state “LIMIT”...
Page 196 Stop using the Speed speed. Limiter and turn off the Speed Limiter. Have your vehicle inspected by a Fiat Put on an accelerator pedal to the Dealership. AA0113784 pedal stroke end (over a detent that...
Page 197: Lane Departure Warning
LANE DEPARTURE Type 1 WARNING IMPORTANT (where provided) 153) Because the system does not use By recognizing through a camera (A) service brake (hydraulic brake), the vehicle the lane in which your vehicle is speed may exceed the set speed on the running, LDW gives you warning when downhill.
Page 198 How to operate LDW Standby state The indication changes as follows In the standby mode, the system is depending on the state of the system. capable of recognizing the lane in which your vehicle is positioned and issuing Turning on the system audible warning when your vehicle goes When you set the ignition switch or out of the lane.
Page 199 (amber) illuminates. System problem warning of attention to the traffic and road If this happens, please contact a Fiat conditions and for controlling the trajectory If a problem occurs with the system, a of the car safely.
Page 200 when passing a road section where the 156) The system may not be able to detect number of lanes increases/decreases or IMPORTANT the lane correctly in the following multiple lanes are crossing each other; conditions. If required, set the LDW switch when the lane is marked by double or to “OFF.”: when driving on a road whose otherwise special lines;...
Page 201: Rear View Camera
REAR VIEW CAMERA 157) Follow the instructions given below to keep your LDW in good operating (where provided) conditions: always keep the windscreen The rear view camera is a system that clean; avoid applying a strong shock or shows the view behind the vehicle on a pressure to the LDW camera.
Page 202 the Multi Communication System NOTE It is not possible to fully see Short transverse lines (1 to 3) (MCS), the Smartphone Link Display obstacles when the lens is dirty. If the indicate distance from the rear bumper. Audio or the DISPLAY AUDIO. When lens becomes contaminated by water you move the gearshift lever or the droplets, snow, mud, or oil, wipe off the...
Page 203 When there is a downward slope behind the vehicle The reference lines are displayed farther than the actual distance. Therefore when there is an obstacle on the downward slope, it appears closer than its actual position. AHA104720 A. Actual objects B.
Page 204 Example: On the screen the point B 252) The rear view camera is an assistance 160) Due to the number of people in the appears the nearest, then the point C system that enables the driver to check for vehicle, the fuel quantity, the weight and obstacles behind the vehicle.
Page 205: In An Emergency
FUSIBLE LINKS ... . .227 to search the nearest Fiat Dealership. FUSES ....227...
Page 206 ERA GLONASS NOTE Depending on the level of impact or the angle of the collision, the (where provided) system may not operate. ERA-GLONASS is a system designed Manual Report: when you open the to reduce the severity of accidents. The cover (C) and press the SOS switch (D).
Page 207 The system check is in process operation possible failure in the system. In this case, 10 seconds) 10 seconds) mode to immediately have the system inspected at a Fiat “ON” Dealership After approx. Extinguishes Extinguishes The system works normally —...
Page 208 Test Mode Within approximately 20 seconds after Test of the ERA-GLONASS system the mode is changed to the test mode, equipment of the vehicle You can check if the system is in the press the SOS switch for one of the normal standby state by the following 1 —...
Page 209 If the speakers 254) In the country or area where is no Have the system inspected by a Fiat need to be replaced due to a failure etc. available emergency call centre of the Dealership.
Page 210: If The Vehicle Breaks Down
IF THE VEHICLE Single cab, Double cab A band for securing a warning triangle is installed left under the rear seat. BREAKS DOWN The wall behind the seat is provided with a band for securing a first-aid kit If the vehicle breaks down on the road, and a warning triangle fig.
Page 211: Emergency Starting
EMERGENCY STARTING WARNING 267) 268) 269) 270) 271) 272) 273) 274) 275) 276) 277) 278) 279) 280) 281) 282) 283) 267) To start the engine using jumper If the engine cannot be started because cables from another vehicle, perform the the battery is weak or dead, the battery correct procedures according to the from another vehicle can be used with...
Page 212: Engine Overheating
If the cooling fan is not turning: stop the may explode. If freezing has occurred, the AHA102087 engine immediately and contact a Fiat battery should be checked by skilled personnel to make sure that the internal dealership for assistance.
Page 213: Bleeding The Fuel System
BLEEDING THE FUEL TOOLS, JACK AND 162) SYSTEM JACK HANDLE 6. Examine the radiator hoses for coolant leakage and the drive belt for The fuel system should be bled to Storage looseness or damage. If there is remove air as described below if the The storage location of the tools, jack anything wrong with the cooling system fuel supply is exhausted during travel.
Page 214 Type 2 Double cab Tools Type 1 Type 1 AHA104065 AHA102120 AHA104094 A — Tools B — Jack handle A. Tool (wheel nut wrench) Single cab, Double cab 1. Wheel nut wrench C — Jack B. Jack handle Club cab C.
Page 215 Jack The jack is used only for the purpose of changing a tyre when a tyre is punctured. NOTE The jack is maintenance-free. NOTE The jack is in conformity with EC law as approximated by the Machinery Directive 2006/42/EC. NOTE The EC declaration of conformity is attached to the section “Declaration AHA104111 AHA104140...
Page 216 Club cab The tools are stored under the floor on the left-hand side of the rear seat. The jack, and jack handle are stored under the floor on the right-hand side of the rear seat. 1. Raise the seat cushion. Refer to “Folding up the seat cushion (Club cab)”.
Page 217 To use the jack handle (Club cab) 1. While pressing the snap pin (A) on the handle that has a black marking, withdraw and remove the inner handle (B). AHA104195 AHA104140 3. Remove the securing nut (E), and 5. Reverse the removing procedure then take out the jack (F).
Page 218: How To Change A Tyre
3. While pressing the snap pin (F) on HOW TO CHANGE A the assembled handle (E), insert the TYRE whitemarked handle (G) until it is locked by snap pin as illustrated. 163) 164) Before changing a tyre, first stop your vehicle in a safe, flat location.
Page 219 4. Insert the wheel nut wrench (E) To remove the spare wheel NOTE Put the spare wheel under the through the end of the jack handle hole vehicle body near the flat tyre. This 1. Set the jack handle. (Club cab) (Refer (F), and then turn it anticlockwise to makes it safer if the jack slips out of to “To use the jack handle (Club cab)”.
Page 220 Use the jacking point closest to the tyre NOTE When jacking up the rear of the 5. Move the jack handle up and down you wish to change. vehicle, turn the tip of the jack so that to raise the ram until just before the jack the grooved portion (C) properly meets contacts the jacking point of the the designated point.
Page 221 Type 2: On vehicles with aluminium wheels Temporarily tighten the wheel nuts by hand until the flange parts of the wheel nuts make light contact with the wheel and the wheel is not loose. AHA105772 AHZ100596 308) 166) NOTE If all 4 aluminium wheels are changed to steel wheels.
Page 222 If the jack is difficult to remove by hand, To store the spare wheel 10. Tighten the nuts crisscross in 2 or insert the jack handle (M) into the 3 steps until each nut has been 1. Install the hanger disc (A) in the bracket (N).
Page 223 NOTE Confirm that the hanger disc is 292) Have the wheel repaired and refitted 297) Set the jack only at the positions securely fitted in the wheel disc hole as soon as possible. Do not apply grease shown here. If the jack is set at a wrong when the wheel is just lifted off the position, it could dent your vehicle or the to the bolt threads before fitting: they could...
Page 224 313) If the steering wheel vibrates when its shape may prevent it from being fitted driving after changing the tyre, we correctly. Consult an authorised Fiat recommend you to have the tyres checked Dealership before using wheels that you for balance.
Page 225 Place the gearshift lever in the “N” If towing is necessary, we recommend (Neutral) position (manual transmission) you to have it done by a Fiat Dealership or the selector lever in the “N” or a commercial tow truck service. In...
Page 226 On vehicles with automatic If your vehicle tows another vehicle transmission, turn the ignition switch to (vehicles with rear towing hook the “ON” position. [For vehicles with the only) keyless operation system] On vehicles 324) 325) 326) 327) 328) 329) with manual transmission, put the The rear towing hook is located as operation mode in ACC or ON.
Page 227 322) When going down a long slope, the brakes may overheat, reducing IMPORTANT effectiveness. Have your vehicle transport by a tow truck. 323) The person in the vehicle being towed 169) This vehicle must not be towed by a must pay attention to the brake lamps of tow truck using sling lift type equipment the towing vehicle and make sure the rope (Type A) as illustrated fig.
Page 228 After driving flooded roads, be sure to loss of control. Avoid high-speed operation, sudden have an inspection at a Fiat Dealership 177) On vehicles with super select 4WD II, acceleration, abrupt brake application and take the necessary measures or when you are going to tow another vehicle, and sharp cornering.
Page 229 FUSIBLE LINKS FUSES Accumulation of ice on the braking system can cause the wheels to lock. The fusible links will melt to prevent a Fuse block location Pull away from a standstill slowly after fire if a large current attempts to flow To prevent damage to the electrical confirming safety around the vehicle.
Page 230 Fuse load capacity The fuse capacity and the names of electrical systems protected by the fuses are indicated on the inside of the fuse lid (LHD vehicles), the back side of the glove box (RHD vehicles) and inside of the fuse block cover (inside of the engine compartment).
Page 231 Passenger compartment fuse location table AA0103837 Electrical system Capacity Tail lamp (left) 7.5 A Cigarette lighter 15 A Ignition coil 10 A Starter motor 7.5 A Sunroof 20 A Accessory socket 15 A...
Page 232 Electrical system Capacity Tail lamp (right) 7.5 A Outside rear view mirrors 7.5 A Engine control unit 7.5 A Control unit 7.5 A Rear fog lamp 10 A Central door lock 15 A Room lamp 15 A Rear window wiper 15 A Gauge 10 A...
Page 233 Engine compartment fuse location table AA3008441 Electrical system Capacities SBF1 Fuse (+B) 30 A* SBF2 Anti-lock braking system 30 A* SBF3 Ignition switch 40 A* SBF4 Electric window control 30 A* — — DC-DC (AUDIO) 30 A...
Page 234 Electrical system Capacities Headlamp low beam (left) 15 A Headlamp low beam (right) 15 A Headlamp high beam (left) 10 A Headlamp high beam (right) 10 A Horn 10 A Front fog lamps 15 A Daytime running lamps 10 A Radiator fan motor 20 A 20 A...
Page 235 Electrical system Capacities Engine 20 A — — Spare fuse 20 A Spare fuse 30 A *: Fusible link Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications. The table above shows the main equipment corresponding to each fuse. The fuse block does not contain spare 7.5 A, 10 A or 15 A fuses.
Page 236 (airbag system, braking system), power unit systems (engine system, AA0109871 transmission system) or steering system blows, contact a Fiat Dealership. 3. Referring to the fuse load capacity table, check the fuse pertaining to the problem. IMPORTANT...
Page 237: Bulb Types
1. Position lamps: 5 W (W5W) recommend you to consult a specialist. turn-signal lamp (on fender). Check with 2. Front turn-signal lamps: 21 W a Fiat Dealership when the lamp need Be careful not to scratch the vehicle (PY21W/P21W) to be repaired or replaced.
Page 238 Rear The following lamps uses LEDs rather than bulbs. For repair and replacement, contact a Fiat dealership. Side turn-signal lamps (on outside rear view mirror) Position lamps (Vehicles with high intensity discharge headlamps) Daytime running lamps (Vehicles with high intensity discharge headlamps)
Page 239 Position lamps 1. When replacing the bulb on the left side of the vehicle, remove the clip (A) holding down the washer tank spout and move the spout towards the rear of the vehicle. AHZ100974 AHA102784 2. Disconnect the connector (A). 4.
Page 240 Front turn-signal lamps 2. Turn the bulb socket anticlockwise to remove it. And remove the bulb from Except for vehicles with high the socket by turning it anticlockwise intensity discharge headlamps while pressing in. 1. When replacing the bulb on the left side of the vehicle, remove the clip (A) holding down the washer tank spout and move the spout towards the rear of...
Page 241 AHA102667 AHZ101056 AA0103202 2. Remove the 3 screws (B) and 3. Turn the socket anticlockwise to 5. To install the bulb, perform the remove the lamp unit. remove it. removal steps in reverse Rear combination lamps 1. Open the rear gate (refer to “Rear gate”).
Page 242 5. To install the bulb, perform the NOTE Wrap a piece of cloth around the removal steps in reverse. tip of the screwdriver in order to avoid scratching the lens and the body. When mounting the lamp unit, align the pins (F) and clip (G) on the lamp unit 2.
Page 243 NOTE When installing the lens, align Front room & map lamps* the 2 tabs on the lens with the holes on 1. Insert a straight blade (or minus) the vehicle side. screwdriver into the notch of the lens and pry gently to remove it. Remove the bulb from the lamp holder.
Page 244 345) Do not install commercially available LED-type bulbs. Commercially available Have the glove box lamp bulb replaced LED-type bulbs could adversely affect the at a Fiat dealership. operation of the vehicle, such as by preventing the lamps and other vehicle AHA104645 equipment from operating properly.
Page 245 SERVICING AND MAINTENANCE Correct maintenance permits the SERVICE PRECAUTIONS ..244 performance of the car to be SCHEDULED SERVICING PLAN . .245 maintained over time, as well as limited PERIODIC CHECKS ..250 running costs and safeguarding the DEMANDING VEHICLE USE .
Page 246: Service Precautions
350) Do not smoke, cause sparks or allow periodic inspection and maintenance open flames around fuel or battery. The fumes are flammable. performed by a Fiat dealership. 351) Be extremely cautious when working In the event a malfunction or a problem around the battery. It contains poisonous is discovered, we recommend you to and corrosive sulphuric acid.
Page 247 SCHEDULED SERVICING PLAN DIESEL ENGINE 4N15 Thousand of miles 12,5 37,5 62,5 87,5 Thousands of kilometers or Years Check tyre conditions/wear and adjust ● ● ● ● ● ● ● ● ● ● pressure, if necessary Check operation of lighting system (headlights, direction indicators, hazard ●...
Page 248 Thousand of miles 12,5 37,5 62,5 87,5 Thousands of kilometers or Years Perform the "Small Injection Quantity ● ● ● ● ● ● ● ● ● ● Learning” procedure Lubricate the appropriate points of the ● ● ● ● ● ●...
Page 249 Thousand of miles 12,5 37,5 62,5 87,5 Thousands of kilometers or Years Visually inspect conditions and wear of front ● ● ● ● ● ● ● ● ● ● disc brake pads and operation of pad wear indicator Visually inspect condition and wear of the ●...
Page 250 Thousand of miles 12,5 37,5 62,5 87,5 Thousands of kilometers or Years Visually inspect conditions and check the ● ● ● ● ● ● ● ● ● ● tension of the accessory drive belts Visually check for any fluid leaks from the ●...
Page 251 Thousand of miles 12,5 37,5 62,5 87,5 Thousands of kilometers or Years Replace the passenger compartment air ● ● ● ● ● ● ● ● ● ● cleaner / pollen filter (where provided)
Page 252 PERIODIC CHECKS DEMANDING VEHICLE USE Before long journeys, check and, if necessary, restore: If the vehicle is mostly used in one of engine coolant level; the following conditions: brake fluid level; towing a trailer or caravan; windscreen washer fluid level; dusty roads;...
Page 253: Checking Levels
CHECKING LEVELS VANODIESEL3231 1. Engine coolant reservoir 2. Brake fluid reservoir 3. Clutch fluid reservoir (where provided) 4. Engine oil cap 5. Engine oil level gauge 6. Power steering fluid reservoir 7. Washer fluid reservoir 8. Battery A — RHD versions 354) 355) WARNING 354) Never smoke when performing operations in the engine compartment.
Page 254: Engine Oil
CATALYTIC ENGINE OIL 5. Reinsert the dipstick as far as it goes. CONVERTER To check and refill engine oil 6. Remove the dipstick and read the oil 356) 357) level, which should always be within the The exhaust gas scavenging devices A —...
Page 255 ENGINE COOLANT Protect the environment On vehicle with DPF, the engine oil It is illegal to pollute drains, water will be increased due to a few of the To check the coolant level courses and soil. Use authorized waste fuel gets mixed in the engine oil when A transparent coolant reserve tank (A) is collection facilities, including civic the DPF regenerates to burn away the...
Page 256 Use the recommended coolant by Fiat necessary. or equivalent (similar high quality ethylene glycol based non-silicate,...
Page 257 WASHER FLUID BRAKE FLUID WARNING Open the washer fluid reservoir cap and To check the fluid level check the level of washer fluid with the Check the brake fluid level in the dipstick. If the level is low, replenish the reservoir.
Page 258: Clutch Fluid
A rapid fluid loss indicates a leak in the 185) 186) 187) thoroughly. Call a doctor immediately if swallowed. clutch system which should be immediately inspected by a Fiat Dealership. WARNING IMPORTANT 365) Prevent power steering fluid from 185) Keep the reservoir tank cap closed to...
Page 259: Power Steering Fluid
DO NOT ALLOW To check the fluid level after only a short period of time, have the PETROLEUM- BASED FLUID TO system checked for leaks at a Fiat Check the fluid level in the reservoir CONTACT, MIX WITH, OR OTHERWISE Dealership.
Page 260 BATTERY Check the electrolyte level at least once NOTE Loosen the nut (B), and then every four weeks, depending on the disconnect the battery cable from the operating conditions. If the battery is positive (+) terminal. The condition of the battery is very not used, it will discharge by itself with important for quick starting of the time.
Page 261 (-) terminal 188) Incorrect assembly of electrical and first. electronic devices may cause severe damage to your vehicle. Contact a Fiat WARNING Dealership if you want to install accessories IMPORTANT after purchasing the vehicle (alarms, radiophone, etc.): they will suggest the...
Page 262: Blade Replacement
WIPER BLADE REPLACEMENT IMPORTANT 383) 196) Do not operate the windscreen wiper 196) with the blades lifted from the windscreen. 1. Lift the wiper arm off the windscreen. 2. Pull the wiper blade until its stopper (A) disengages from the hook (B). Then, WARNING pull the wiper blade further to remove it.
Page 263 GENERAL VEHICLE CARE MAINTENANCE PRECAUTIONS IMPORTANT Fuel, engine coolant, oil and 384) exhaust gas leakage 5) Detergents pollute the environment. Only 197) Look under the body of your vehicle to wash your vehicle in areas equipped to check for fuel, engine coolant, oil and collect and treat wastewater from this type exhaust gas leaks.
Page 264 CLEANING THE NOTE Do not use synthetic fiber or dry NOTE If genuine leather is wet with cloth. They can cause discolouring or water or is washed in water, wipe off INTERIOR OF YOUR water as quickly as possible with a dry, damaging the surface.
Page 265 CLEANING THE vehicle, carefully clean the joints and 386) Never use flammable products, such flanges of the doors, bonnet and other EXTERIOR OF YOUR as petrol ether or rectified petrol to clean sections where dirt is likely to remain. VEHICLE the inside of the car.
Page 266: Wheels
Polishing Window glass If salt and other chemicals are used on the roads in your area, clean the engine The vehicle should only be polished if The window glass can normally be compartment at least every three the paintwork has become stained or cleaned using only a sponge and water.
Page 267 Versions with stickers or wrapping Exterior plastic parts must be cleaned in the same way as the rest of To correctly clean and wash the stickers IMPORTANT and/or wrapping parts, proceed as the vehicle. follows: Where possible, do not park under Avoid washing with rollers and/or 199) Avoid washing with rollers and/or trees: the resinous substances that...
Page 268 203) Never spray or splash water on the 206) Using an automatic car wash, pay 213) Contact with seawater and road electrical components in the engine attention to the following items, referring to deicer can cause corrosion. Rinse off such compartment.
Page 269 TYRES 387) Tyre size UP TO 3 PASSENGERS MAX. LOAD OR TRAILER TOWING Front Rear Front Rear 2.4 bar 2.4 bar 2.4 bar 4.5 bar 205R16C 110/108R 8PR (240 kPa) (240 kPa) (240 kPa) (450 kPa) {35 psi} {35 psi} {35 psi} {65 psi} 2.0 bar...
Page 270 The use of worn tyres can be very 391) Consult your authorised Fiat dealer to dangerous because of the greater 217) 218) determine the cause of irregular tread chance of skidding or hydroplaning.
Page 271 Contact a Fiat Dealership before putting 388) Remember that the road holding NOTE If flange nuts are used on your qualities of your vehicle also depend on the on snow traction device (tyre chains).
Page 272 (Tyre chains). correctly. Consult a Fiat dealership before 224) Drive cautiously and do not exceed using wheels that you have. 50 km/h. Remember that preventing accidents is not the purpose of snow traction device (tyre chains).
Page 273 TECHNICAL SPECIFICATIONS Everything you may find useful for VEHICLE LABELING ..272 understanding how your vehicle is ENGINE SPECIFICATIONS ..274 made and works is contained in this VEHICLE DIMENSIONS .
Page 274 VEHICLE LABELING Vehicle Identification Number (VIN) The vehicle identification number is stamped as shown in the illustration. AHA113380 AA0117333 Vehicle Information code plate Please use this number when ordering replacement parts. The vehicle information code plate is located as shown in the illustration. 1.
Page 275 Engine model/number Engine model and engine number are stamped on the engine cylinder block as shown in the illustrations. AHA101426...
Page 276: Engine Specifications
ENGINE SPECIFICATIONS 2.4 150 cv Diesel Engine (4N15) Engine model 4N15 Engine type Euro 5 — Euro 6 No. of cylinders 4 in line Total displacement 2,442 cc Bore 86.0 mm Stroke 105.1 mm Camshaft Double overhead Mixture preparation Electronic direct injection Maximum output (EEC net) 113 kW/ 3,500 r/min Maximum torque (EEC net)
Page 277 2.4 180 cv 4WD Diesel Engine (4N15) Engine model 4N15 Engine type Euro 5 — Euro 6 No. of cylinders 4 in line Total displacement 2,442 cc Bore 86.0 mm Stroke 105.1 mm Camshaft Double overhead Mixture preparation Electronic direct injection Maximum output (EEC net) 133 kW/ 3,500 r/min Maximum torque (EEC net)
Page 278 VEHICLE DIMENSIONS Club Cab AH5101927...
Page 279 Reference Length Front track 1,520 mm (*1) Overall width 1,785 mm, 1,815 mm Front overhang 865 mm Wheel base 3,000 mm Without rear bumper 1,330 mm Rear overhang With rear bumper 1,410 mm Without rear bumper 5,195 mm Overall length With rear bumper 5,275 mm (*1)
Page 280 Double Cab AH5102328...
Page 281 Reference Length Front track 1,520 mm Overall width 1,785 mm, 1,815 mm Front overhang 865 mm Wheel base 3,000 mm Without rear bumper 1,340 mm Rear overhang With rear bumper 1,420 mm Without rear bumper 5,205 mm Overall length With rear bumper 5,285 mm Ground clearance (unladen) 200 mm, 205 mm...
Page 282 Single Cab AH5101914...
Page 283 Reference Length Front track 1,520 mm Overall width 1,785 mm Front overhang 865 mm Wheel base 3,000 mm Without rear bumper 1,215 mm Rear overhang With rear bumper 1,295 mm Without rear bumper 5,080 mm Overall length With rear bumper 5,160 mm Ground clearance (unladen) 200 mm...
Page 284: Vehicle Performance
VEHICLE PERFORMANCE Single cab Maximum speed 169 km/h Club cab Vehicles without wide fender Vehicles with wide fender Maximum speed 169 km/h 179 km/h Double cab Vehicles with wide fender Vehicles without wide fender 173 km/h 174 km/h Maximum speed 169 km/h 179 km/h 177 km/h...
Page 285: Vehicle Weights
VEHICLE WEIGHTS Single Cab Reference Weight Without optional parts 1.790 kg Kerb weight With full optional parts 1.835 kg Maximum gross vehicle weight 2.850 kg Front 1.260 kg Maximum axle weight Rear 1.840 kg With brake 3.000 kg Maximum towable weight Without brake 750 kg Maximum trailer-nose weight...
Page 286 Club Cab Vehicles with Vehicles without wide fender wide fender Without optional 1,820 kg 1,805 kg 1,840 kg parts Kerb weight With full optional 1,910 kg 1,895 kg 1,930 kg parts Maximum gross vehicle weight 2,850 kg Front 1,260 kg Maximum axle weight Rrear 1,840 kg...
Page 287 Double Cab 2WD Hi-Rider Without optional parts 1,765 kg Kerb weight With full optional parts 1,850 kg Maximum gross vehicle weight 2,800 kg Front 1,260 kg Maximum axle weight Rear 1,840 kg With brake 2,700 kg Maximum towable weight Without brake 750 kg Maximum trailer-nose weight 110 kg...
Page 288 Diesel engine 2.4 (4N15) Vehicles without wide Vehicles with wide fender fender 1,870 kg 1,875 kg 1,860 kg Without optional parts (*2) (*2) (*1) 1,840 kg 1,855 kg 1,855 kg Kerb weight 1,955 kg 1,960 kg 1,950 kg (*1) With full optional parts 1,950 kg (*2) (*1)
Page 289 Diesel engine 2.4 (4N15) Vehicles without wide Vehicles with wide fender fender 1,875 kg Without optional parts 1,870 kg 1,860 kg (*2) 1,855 kg Kerb weight 1,955 kg With full optional parts 1,960 kg 1,950 kg (*2) 1,955 kg 2,910 kg Maximum gross vehicle weight 2,900 kg 2,910 kg...
Page 290: Electrical System
NOTE The vehicles equipped with Start&Stop have a dedicated Start&Stop battery type. Use of a different battery could cause the battery to run down quickly or Start&Stop system not to operate normally. Please contact a Fiat Dealership when replacing the battery.
Page 291: Tyres And Wheels
TYRES AND WHEELS Tyre size Tyres 205R16C 8PR 110/108R 245/70R16 111S RF 245/65R17 111S Size 16x6J, 16x6JJ 16x7J, 16x7JJ 17x7 1/2J Wheel Offset 38 mm NOTE Contact a Fiat Dealership for details on the combination used on your vehicle.
Page 292: Refill Capacities
REFILL CAPACITIES VANODIESEL3231EM A — RHD vehicles Quantity Lubricants Engine coolant PARAFLU UP Contractual Technical Reference 7.7 litres (Includes 0.65 litre in the reserve tank) N° F101.M01 (1) DOT4 Brake fluid As required TUTELA TOP 4/S Contractual Technical Reference N° F005.F15...
Page 293 Quantity Lubricants DOT4 Clutch fluid As required TUTELA TOP 4/S Contractual Technical Reference N° F005.F15 Oil pan 8.0 litres SELENIA MULTIPOWER C3 Contractual Technical Engine oil Oil filter 0.3 litres Reference N° F129.F11 Oil cooler 0.1 litres TUTELA GI/Z Contractual Technical Reference Power Steering As required N°F001.A16...
Page 294 0.743 t HFC-134a equivalent conditioning) 1,430 (2) Contains fluorinated greenhouse gases NOTE For the Automatic transmission fluid, use only the Fiat Genuine products. Use of a different fluid could damage the transmission. Quantity Lubricants TUTELA TRANSMISSION GEARSYNTH Z3 Manual transmission oil 2.2 litres...
Page 295 FLUIDS AND LUBRICANTS Product specifications Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of the Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission specifications. Lubricant quality is crucial for engine operation and duration.
Page 296 Original Fluids and Lubricant Characteristics Specification Application Lubricants TUTELA TRANSMISSION GI/PA Automatic transmission Synthetic lubricant ATF 9.55550-AV 6 Contractual Technical fluid Reference N°F001.A16 TUTELA TRANSMISSION Synthetic lubricant SAE GEARSYNTH Z3 Manual transmission and 9.55550-MZ 9 75W-80 API GL-3 Contractual Technical transfer oil for 5M/T Reference N°F001.A16 TUTELA TRANSMISSION...
Page 297 Original Fluids and Lubricant Characteristics Specification Application Lubricants PARAFLU UP Contractual Protective agent for CUNA NC 956-16 9.55523 Technical Reference Engine Coolant radiators ASTM D 3306 or MS.90032 N° F101.M01 Mixture of spirits and PETRONAS DURANCE SC To be used diluted or surfactants.
Page 298 FUEL CONSUMPTION / CO EMISSION COMBINED USE Fuel consumption Euro 5 engine Transmission CO2 (g/km) (L/100km) With Start&Stop 6M/T 2WD Hi-Rider Without Start&Stop 5A/T With Start&Stop 6M/T 6M/T (**) (**) Without Start&Stop 5A/T (**) (**) (*) Vehicles for Russia (**)Vehicles for Ukraina...
Page 299 COMBINED USE Fuel consumption Euro 6 engine Transmission CO2 (g/km) (L/100km) With Start&Stop 6M/T 2WD Hi-Rider Without Start&Stop 5A/T With Start&Stop 6M/T (**) (**) 6M/T (***) (***) Without Start&Stop (**) (**) 5A/T (***) (***) (*) Vehicles for Turkey (**) Vehicles for Russia (***) Vehicles for Ukraine NOTE: The results given do not express or imply any guarantee of the fuel consumption of the particular vehicle.
Page 302 MAINTAIN YOUR VEHICLE IN TIP TOP CONDITIONS WITH Mopar Vehicle Protection offers a series of service contracts that are designed to give all our customers the pleasure of driving their vehicle without any hitch's and concerns. Our product portfolio consists of a wide and flexible range of extended warranty and maintenance plans endorsed by FCA.
Page 303 NOTE...
Page 309 INDEX luids and Lubricants ..293 Cleaning the interior of your vehicle .262 Clutch fluid ....256 Fog lamp switch ....48 Wheel drive operation .
Page 310 Keyless operation system ..17 afe driving techniques ..145 ools, jack and jack handle ..211 Keys .....13 safety systems .
Page 311 At Fiat Service authorised workshops you can find technicians directly trained by us, offering quality and professionalism for all service operations. Fiat workshops are always close to you for the regular servicing operations, season checks and practical recommendations by our experts.
Page 312 The data contained in this publication is intended merely as a guide. FCA Italy S.p.A. reserves the right to modify the models and versions described in this booklet at any time for technical and commercial reasons. If you have any further questions please consult your FIAT dealer. Printed in recycled paper without chlorine.

This manual is also suitable for:

Fullback double cab Fullback club cab

Fiat Fullback Single cab Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Fiat Fullback Single cab

Summary of Contents for Fiat Fullback Single cab

This manual is also suitable for:

Table of Contents
