Page 1 FIAT 500 2 0 1 4 O W N E R ’ S M A N U A L...
Page 2 WARNING! tured. FIAT is a registered trademark of Fiat Group Marketing & Driving after drinking can lead to an accident. Your Corporate Communication S. p. A. , used under license perceptions are less sharp, your reflexes are slower, and by Chrysler Group LLC.
Page 3: Introduction 3
TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .
Page 5: Table Of Contents
INTRODUCTION CONTENTS INTRODUCTION ......4 VEHICLE IDENTIFICATION NUMBER ..7 HOW TO USE THIS MANUAL ....5 VEHICLE MODIFICATIONS/ALTERATIONS .
Page 6: Introduction
- all essentials that are maintaining its validity traditional to our vehicles. • The range of additional services available to FIAT This Owner’s Manual has been prepared with the assis- Group Automobiles customers tance of service and engineering specialists to acquaint NOTE: After reviewing the owner information, it you with the operation and maintenance of your vehicle.
Page 7: How To Use This Manual
INTRODUCTION 5 HOW TO USE THIS MANUAL Consult the Table of Contents to determine which section contains the information you desire. Since the specification of your vehicle depends on the items of equipment ordered, certain descriptions and illustrations may differ from your vehicle’s equipment. The detailed index at the back of this Owner’s Manual contains a complete listing of all subjects.
Page 8 6 INTRODUCTION...
Page 9: Vehicle Identification Number
INTRODUCTION 7 WARNINGS AND CAUTIONS This Owners Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire Owners Manual, you may miss important information.
Page 10: Vehicle Modifications/Alterations
8 INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Stamped VIN Location NOTE: It is illegal to remove or alter the VIN.
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A WORD ABOUT YOUR KEYS ... . .11 Remote Key Unlock, Driver Door/All Doors 1st Press .......16 Ignition Key Removal .
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LIFTGATE ......24 Advanced Front Air Bag Features ...40 OCCUPANT RESTRAINTS .
Page 13: Things To Know Before Starting Your Vehicle 9
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 A WORD ABOUT YOUR KEYS The vehicle is supplied with a code card containing key code numbers to order duplicate keys, and the autho- The key fob contains the Remote Keyless Entry (RKE) rized dealer that sold you your new vehicle has the key transmitter with an integrated key.
Page 14 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Before exiting a vehicle, always apply the parking brake, shift the transmission into PARK and re- move the Key Fob from the ignition. When leaving the vehicle, always lock your vehicle. •...
Page 15: Locking Doors With A Key
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key-In-Ignition Reminder WARNING! (Continued) Opening the driver’s door when the key is in the ignition • Do not leave children or animals inside parked and the ignition switch position is OFF/LOCK, sounds a vehicles in hot weather.
Page 16: Replacement Keys
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: A key which has not been programmed is also Replacement Keys considered an invalid key, even if it is cut to fit the NOTE: Only keys that have been programmed to the ignition switch lock cylinder for that vehicle.
Page 17: General Information
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 General Information REMOTE KEYLESS ENTRY (RKE) — IF EQUIPPED The Sentry Key® system complies with FCC rules part 15 and with RSS-210 of Industry Canada. Operation is This system allows you to lock or unlock the doors and subject to the following conditions: liftgate from distances up to approximately 66 ft (20 m) using a hand-held Remote Keyless Entry (RKE) transmit-...
Page 18: To Unlock The Doors And Liftgate
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlock The Doors And Liftgate Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door or twice, within five seconds, to unlock all doors and the liftgate. The turn signal lights will flash to acknowledge the unlock signal.
Page 19: To Lock The Doors And Liftgate
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 To Lock The Doors And Liftgate The recommended replacement battery is CR2032. Press and release the LOCK button on the RKE transmit- 1. Press the mechanical key release button and release ter to lock all doors and the liftgate. The turn signal lights the mechanical key to access the battery case screw will flash and the horn will chirp to acknowledge the located on the side of the Key Fob.
Page 20 18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Rotate the screw located on the side of the Key Fob using a small screwdriver. Battery Case Removed 4. Refit the battery case inside the Key Fob and turn the screw to lock it into place. Key Fob Screw Location 3.
Page 21: General Information
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 General Information If your RKE transmitter fails to operate from a normal distance, check for these two conditions: This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the 1.
Page 22 20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • For personal security and safety in the event of a collision, lock the vehicle doors as you drive as well as when you park and leave the vehicle. • Before exiting a vehicle, always apply the parking brake, shift the transmission into PARK, and re- move the Key Fob from the ignition.
Page 23: Power Door Locks - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 Power Door Locks — If Equipped WARNING! (Continued) A power door lock switch is incorporated into the driver • Do not leave the Key Fob in or near the vehicle, or door handle. Push or pull the handle to lock or unlock the in a location accessible to children.
Page 24 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To change the setting proceed as follows: 1. Briefly press the MENU button to enter the MENU screen. 2. Press the UP or DOWN button to highlight “Autoclose”. Press the MENU button, use the UP or DOWN buttons to turn setting ON or OFF 3.
Page 25: Power Windows
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 POWER WINDOWS Power Window Switches There are single window controls located on the shifter bezel, below the climate controls, which operate the driver and passenger door windows. The window con- trols will operate when the ignition switch is in the ON/RUN position.
Page 26: Liftgate
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions.
Page 27: Occupant Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 OCCUPANT RESTRAINTS WARNING! Some of the most important safety features in your • Driving with the liftgate open can allow poisonous vehicle are the restraint systems: exhaust gases into your vehicle. You and your •...
Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • All seat belt systems (except the driver’s) include Here are some simple steps you can take to minimize the Automatic Locking Retractors (ALRs), which lock the risk of harm from a deploying air bag: seat belt webbing into position by extending the belt 1.
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 ride properly buckled up in the rear seat. Never allow 5. If the air bag system in this vehicle needs to be children to slide the shoulder belt behind them or under modified to accommodate a disabled person, contact their arm.
Page 30: Lap/Shoulder Belts
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE and cause a collision that includes you. This can happen WARNING! (Continued) far away from home or on your own street. • Being too close to the steering wheel or instrument Research has shown that seat belts save lives, and they panel during Advanced Front Air Bag deployment can reduce the seriousness of injuries in a collision.
Page 31 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 WARNING! WARNING! (Continued) • Wearing your belt in the wrong place could make • It is dangerous to ride in a cargo area, inside or your injuries in a collision much worse. You might outside of a vehicle.
Page 32 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. The seat belt latch plate is along side the pillar near the 3. When the belt is long enough to fit, insert the latch back of your seat. Grasp the latch plate and pull out plate into the buckle until you hear a “click.”...
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 WARNING! WARNING! (Continued) • A belt that is worn under your arm is dangerous. • A belt buckled into the wrong buckle will not Your body could strike the inside surfaces of the protect you properly.
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Position the lap belt across your thighs, below your WARNING! abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is •...
Page 35: Lap/Shoulder Belt Untwisting Procedure
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 6. To release the belt, push the red button on the buckle. Lap/Shoulder Belt Untwisting Procedure The belt will automatically retract to its stowed posi- Use the following procedure to untwist a twisted lap/ tion.
Page 36: Seat Belts In Passenger Seating Positions
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belts In Passenger Seating Positions If the passenger seating position is equipped with an ALR and is being used for normal usage: The seat belts in the passenger seating positions are equipped with Automatic Locking Retractors (ALR) Only pull the belt webbing out far enough to comfortably which are used to secure a child restraint system.
Page 37: Energy Management Feature
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 position that has a belt with this feature. Children 12 WARNING! years old and under should always be properly re- • The belt and retractor assembly must be replaced if strained in a vehicle with a rear seat. the seat belt assembly Automatic Locking Retractor How To Engage The Automatic Locking Mode (ALR) feature or any other seat belt function is not...
Page 38: Seat Belt Pretensioners
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Pretensioners Enhanced Seat Belt Use Reminder System (BeltAlert®) The seat belts for both front seating positions are equipped with pretensioning devices that are designed to BeltAlert® is a feature intended to remind the driver and remove slack from the seat belt in the event of a collision.
Page 39: Seat Belt Extender
WARNING! BeltAlert® can be enabled or disabled by your autho- Using a seat belt extender when not needed can rized dealer. FIAT Group Automobiles does not recom- increase the risk of injury in a collision. Only use mend deactivating BeltAlert®.
Page 40: Seat Belts And Pregnant Women
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belts And Pregnant Women addition, the vehicle is equipped with a Supplemental Driver Side Knee Air Bag mounted in the instrument We recommend that pregnant women use the seat belts panel below the steering column. throughout their pregnancy.
Page 41 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 NOTE: The Driver and Passenger Advanced Front Air This vehicle is equipped with Supplemental Side Air Bag Bags are certified to new Federal regulations for Ad- Inflatable Curtains (SABIC) to protect the driver, front, vanced Air Bags.
Page 42: Advanced Front Air Bag Features
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Front and Side Impact Sensors Air Bag System Components • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, Your vehicle may be equipped with the following air bag system components: and Seat Track Position Sensors •...
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Supplemental Seat-Mounted Side Air Bags (SAB) WARNING! (Continued) Supplemental Seat-Mounted Side Air Bags (SAB) provide • Do not put anything on or around the air bag enhanced protection to help protect an occupant during a covers or attempt to open them manually.
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE When the air bag deploys, it opens the seam between the front and side of the seat’s trim cover. Each air bag deploys independently; a left side impact deploys the left air bag only and a right-side impact deploys the right air bag only.
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 The system includes side impact sensors that are cali- WARNING! brated to deploy the Seat-Mounted Side Air Bags (SAB) • Your vehicle is equipped with left and right and SABIC during impacts that require air bag occupant protection.
Page 46: Air Bag Deployment Sensors And Controls
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Knee Impact Bolsters WARNING! (Continued) The Knee Impact Bolsters help protect the knees of the • Your vehicle is equipped with SABIC air bags, do driver and front passenger, and position the front occu- not have any accessory items installed which will pants for the best interaction with the Advanced Front alter the roof, including adding a sunroof to your...
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 ORC deploys the Advanced Front Air Bags, Supplemen- underrides, and angle offset collisions. On the other tal Driver Side Knee Air Bag, Supplemental Side Air Bag hand, depending on the type and location of impact, Inflatable Curtain (SABIC), Supplemental Seat-Mounted Advanced Front Air Bags may deploy in crashes with Side Air Bags (SAB), and front seat belt pretensioners, as...
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ON/RUN or START position. If the key is in the OFF/ noted that could affect the air bag system. The diagnos- LOCK position, or not in the ignition, the air bag system tics also record the nature of the malfunction.
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 quantity of non-toxic gas is generated to inflate the Advanced Front Air Bags, it signals the inflator units. A Advanced Front Air Bags. Different air bag inflation rates large quantity of non-toxic gas is generated to inflate the are possible, based on several factors, including the Supplemental Driver Side Knee Air Bag.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE between the occupant and the door. The SAB fully A quantity of non-toxic gas is generated to inflate the side inflates in about 10 milliseconds. The side air bag moves curtain air bag. The inflating side curtain air bag pushes at a very high speed and with such a high force that it the outside edge of the headliner out of the way and could injure you if you are not seated properly, or if items...
Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 • Turn on the interior lights, which remain on as long as Front And Side Impact Sensors the battery has power or until the ignition key is In front and side impacts, impact sensors can aid the removed.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Customer Action Customer Will See 1. Turn ignition OFF. (Turn Signal Switch Must be placed in Neutral State). 2. Turn ignition ON. Left Turn Light is OFF. Right Turn Light BLINKS. 3. Turn Right Turn Signal Switch ON. Right Turn Light is ON SOLID.
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 If a reset procedure step is not completed within 45 floor. They are not caused by contact with chemicals. seconds, then the turn signal lights will turn off and the They are not permanent and normally heal quickly. reset procedure must be performed again in order to be However, if you haven’t healed significantly within a successful.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Air Bag System WARNING! WARNING! Deployed air bags and seat belt pretensioners cannot protect you in another collision. Have the air bags, • Modifications to any part of the air bag system seat belt pretensioners, and the front seat belt retrac- could cause it to fail when you need it.
Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 Air Bag Warning Light WARNING! (Continued) • Do not attempt to modify any part of your air bag You will want to have the air bags ready to system. The air bag may inflate accidentally or may inflate for your protection in a collision.
Page 56: Event Data Recorder (Edr)
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If the speedometer, tachometer, or any engine The EDR in this vehicle is designed to record such data related gauges are not working, the Occupant Restraint Controller (ORC) may also be disabled. The air bags may •...
Page 57: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 NOTE: EDR data are recorded by your vehicle only if a that small children ride in proper restraint systems. This non-trivial crash situation occurs; no data are recorded by is the law, and you can be prosecuted for ignoring it. the EDR under normal driving conditions and no per- Children 12 years or younger should ride properly sonal data (e.g., name, gender, age, and crash location)
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: WARNING! • For additional information, refer In a collision, an unrestrained child can become a www.seatcheck.org or call 1–866–SEATCHECK. Cana- projectile inside the vehicle. The force required to dian residents should refer to Transport Canada’s hold even an infant on your lap could become so website for additional information: great that you could not hold the child, no matter...
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Infants and Children who are two years old or Either an Infant Carrier or a Convertible Toddlers younger and who have not reached the Child Restraint, facing rearward in the rear...
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants And Child Restraints WARNING! Safety experts recommend that children ride rearward- • Never place a rear facing infant seat in front of an facing in the vehicle until they are two years old or until air bag.
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 remain in a forward-facing child seat with a harness for WARNING! as long as possible, up to the highest weight or height • Improper installation can lead to failure of an allowed by the child seat. infant or child restraint.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children Too Large For Booster Seats WARNING! (Continued) Children who are large enough to wear the shoulder belt • When your child restraint is not in use, secure it in comfortably, and whose legs are long enough to bend the vehicle with the seat belt or LATCH anchor- over the front of the seat when their back is against the ages, or remove it from the vehicle.
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 4. Is the lap part of the belt as low as possible, touching WARNING! the child’s thighs and not their stomach? Never allow a child to put the shoulder belt under an 5.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Recommendations For Attaching Child Restraints Use any attachment method shown with an “X” Below Combined LATCH – Weight of the LATCH – Restraint Type Lower Anchors Seat Belt + Top Child + Child Lower Anchors Seat Belt Only + Top Tether...
Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Lower Anchors And Tethers For Children (LATCH) Your vehicle is equipped with the child restraint anchor- Restraint System age system called LATCH, which stands for Lower Anchors and Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH- equipped child seats.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH Positions For Installing Child Restraints In This Vehicle • Lower Anchorage Symbol 2 anchorages per seating position • Top Tether Anchorage Symbol...
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 What is the weight limit (child’s weight 65 lbs (29.5 kg) Use the LATCH anchorage system un- + weight of the child restraint) for using til the combined weight of the child the LATCH anchorage system to attach and the child restraint is 65 lbs the child restraint?
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Can two child restraints be attached Never “share” a LATCH anchorage using a common lower LATCH an- with two or more child restraints. If chorage? the center position does not have dedi- cated LATCH lower anchorages, use the seat belt to install a child seat in the center position next to a child seat...
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback, below the anchorage sym- bols on the seatback. They are just visible when you lean into the rear seat to install the child restraint.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Locating The LATCH Anchorages Center Seat LATCH WARNING! There are tether strap anchorages behind each rear seating position located on the back of the This vehicle does not have a center seating position. seat.
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 2. Loosen the adjusters on the lower straps and on the 5. If the child restraint has a tether strap, connect it to the tether strap of the child seat so that you can more top tether anchorage.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Stow An Unused ALR Seatbelt WARNING! When using the LATCH attaching system to install a • Improper installation of a child restraint to the child restraint, stow all ALR seat belts that are not being LATCH anchorages can lead to failure of an infant used by other occupants or being used to secure child or child restraint.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Installing Child Restraints Using The Vehicle Seat Lap/Shoulder Belt Systems for Installing Child Belt Restraints in this Vehicle The seat belts in the passenger seating positions are equipped with a Switchable Automatic Locking Retractor (ALR) that is designed to keep the lap portion of the seat belt tight around the child restraint so that it is not necessary to use a locking clip.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE What is the weight limit (child’s Weight limit of the Child Restraint Always use the tether anchor when weight + weight of the child re- using the seat belt to install a for- straint) for using the Tether Anchor ward facing child restraint, up to with the seat belt to attach a forward...
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 Installing A Child Restraint With A Switchable 4. Pull on the webbing to make the lap portion tight Automatic Locking Retractor (ALR) against the child seat. 1. Place the child seat in the center of the seating 5.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 8. If the child restraint has a top tether strap and the better fit. If the rear seat can be moved forward and seating position has a top tether anchorage, connect rearward in the vehicle, you may wish to move it to its the tether strap to the anchorage and tighten the tether rear-most position to make room for the child seat.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 5. If the child restraint has a top tether strap and the facing out, away from the child restraint. Repeat steps 4 seating position has a top tether anchorage, connect to 6, above, to complete the installation of the child the tether strap to the anchorage and tighten the tether restraint.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat. If your vehicle is equipped with adjustable rear head restraints, raise the head restraint, and where possible, route the tether strap under the head restraint and between the two posts.
Page 79: Transporting Pets
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 ENGINE BREAK-IN RECOMMENDATIONS WARNING! A long break-in period is not required for the engine and • An incorrectly anchored tether strap could lead to drivetrain (transmission and axle) in your vehicle. increased head motion and possible injury to the Drive moderately during the first 300 miles (500 km).
Page 80: Safety Tips
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CAUTION! WARNING! • Do not leave children or animals inside parked Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result. vehicles in hot weather. Interior heat build-up may cause serious injury or death.
Page 81: Exhaust Gas
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 Exhaust Gas WARNING! (Continued) • If it is necessary to sit in a parked vehicle with the WARNING! engine running, adjust your heating or cooling Exhaust gases can injure or kill. They contain carbon controls to force outside air into the vehicle.
Page 82: Safety Checks You Should Make Inside The Vehicle
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Inside The not lit during starting, see your authorized dealer. If the Vehicle light stays on, flickers, or comes on while driving, have the system checked by an authorized dealer. Seat Belts Defroster Inspect the seat belt system periodically, checking for...
Page 83 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 WARNING! WARNING! (Continued) • Check mounting of mats on a regular basis. Always Pedals that cannot move freely can cause loss of properly reinstall and secure floor mats that have vehicle control and increase the risk of serious per- been removed for cleaning.
Page 84: Periodic Safety Checks You Should Make Outside
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside Door Latches The Vehicle Check for positive closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.
Page 85: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS POWER CONVERTIBLE TOP — IF EQUIPPED . .86 Heated Mirrors — If Equipped ... .92 Lowering The Power Top....86 Sun Visors .
Page 86 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE EZ Entry Feature ..... .103 Lane Change Assist ....112 Memory Feature .
Page 87 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 To Vary The Speed Setting ....121 Wind Buffeting ..... . .131 To Accelerate For Passing .
Page 88: Power Convertible Top - If Equipped
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER CONVERTIBLE TOP — IF EQUIPPED NOTE: The power top buttons will operate when the ignition switch is turned to the ACC/ ON/RUN position. On vehicles equipped with a power convertible top, the power convertible top switch is located on the overhead Lowering The Power Top console.
Page 89 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 NOTE: Rail lubrication is recommended every 2000 CAUTION! (Continued) cycles, or if scratching noises due to dust are present. • Use care when washing the vehicle, water pressure Refer to “Fluids, Lubes, and Genuine Part” in “Maintain- directed at the weather strip seals may cause water ing Your Vehicle”...
Page 90: Power Convertible Top Relearn Procedure
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Convertible Top Relearn Procedure 7. CONTINUE to hold the CLOSED button until the top begins to cycle fully open, then release the CLOSED If your power convertible top does not operate in the button.
Page 91: Wind Stop
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 Wind Stop The Wind Stop installs in the backseat area of the vehicle. The Wind Stop will not interfere with power top opera- tion. Therefore, it can remain installed when the top is up. MIRRORS Inside Day/Night Mirror The mirror can be adjusted up, down, left, and right for...
Page 92: Automatic Dimming Mirror - If Equipped
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light to the left of the button will illuminate to indicate when the dimming feature is activated.
Page 93: Power Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 Power Mirrors The power mirror controls consist of a mirror select switch and a four-way mirror control switch. To adjust a The power mirror controls are located on the driver’s mirror, press the mirror select switch to either the L (left) door trim panel.
Page 94: Folding Mirrors
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Spotter Mirror — If Equipped Folding Mirrors Some models are equipped with a driver’s side spotter The exterior mirrors are hinged to allow the mirror to mirror. The spotter mirror allows for a greater range of pivot forward or rearward to help avoid damage.
Page 95: Sun Visors
The sun visor can be Overview rotated downward or up against the door glass. Both sun Windows Mobile™-based FIAT BLUE&ME™ is a per- visors are equipped with courtesy mirrors. sonal telematic system enabling you to use communica- tion and entertainment applications expressly designed for use in the car.
Page 96: The Hands-Free Kit
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE you are not required to train the voice recognition system The Hands-Free Kit to recognize your voice. This implies that the system is The basic characteristic of this hands-free kit is voice nearly equally performing with different persons, i.e.: the recognition with Bluetooth®...
Page 97 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 your mobile phone manually and visually using the To get started with BLUE&ME™ hands-free kit with steering wheel controls and the instrument panel multi- voice recognition, you have to simply pair your function display. Bluetooth®...
Page 98 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • To interact with BLUE&ME™ you can use either the The hands-free kit enables the following operations: buttons on the steering wheel or voice commands. • Contact Calling By Voice — You can call a contact in With voice recognition, you can perform system func- your mobile phone phonebook using your voice.
Page 99 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 • Conference Call — You can call another contact while Message Reader you are engaged in a phone conversation (with The BLUE&ME™ message reader enables automatic Bluetooth® phones supporting this option). reading, through the car sound system, of the SMS texts •...
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • To delete individual messages or the entire inbox using Message reader functions are managed by the control buttons on the steering wheel or by the BLUE&ME™ the buttons on the steering wheel or voice commands. voice commands.
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 The media player enables the following operations: NOTE: • Digital Audio Playback — You can play all your • The media player does not support audio files com- digital audio files (.mp3, .wma, .wav, .aac) or play a pressed with other formats and DRM (Digital Rights customized playlist (.m3u or .wpl format).
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! WARNING! (Continued) • Keep the Owner’s Manual in the car: when kept in • Driving while distracted can result in loss of ve- the car, the Owner’s Manual will be a ready refer- hicle control, accident and injury.
Page 103: Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 SEATS Front Seats Forward/Rearward Adjustment Seats are a part of the Occupant Restraint System of the The adjusting bar is located at the front of the seats, near vehicle. the floor. WARNING! • It is dangerous to ride in a cargo area, inside or outside of a vehicle.
Page 104: Recline Adjustment
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE move forward and rearward on the seat to be sure that the seat adjusters have latched. WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death.
Page 105: Seat Height Adjustment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Seat Height Adjustment EZ Entry Feature The driver’s seat height can be raised or lowered by The driver and front passenger seats have an EZ entry using a lever, located on the outboard side of the seat. feature for rear seat passengers.
Page 106: Memory Feature
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lift the seatback upright and push the seat rearward to fore/aft (memory) position on the tracks. This results in its locked position once the rear passengers are seated. the seat back memory being set only – The track will then be locked forward of its last set fore/aft memory posi- Memory Feature tion.
Page 107: Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Head Restraints WARNING! Head restraints are designed to reduce the risk of injury • Persons who are unable to feel pain to the skin by restricting head movement in the event of a rear- because of advanced age, chronic illness, diabetes, impact.
Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reactive Head Restraints — Front Seats The front driver and passenger seats are equipped with Reactive Head Restraints. In the event of a rear impact the Reactive Head Restraints will automatically extend forward minimizing the gap between the back of the occupant’s head and the Reactive Head Restraint.
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 NOTE: The head restraints should only be removed by Restraints” in “Things To Know Before Starting Your qualified technicians, for service purposes only. If either Vehicle” for information on tether routing. of the head restraints require removal, see your autho- rized dealership.
Page 110: To Open And Close The Hood
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TO OPEN AND CLOSE THE HOOD 2. Rotate the safety catch under the front edge of the hood, near the center, and raise the hood. To open the hood, two latches must be released. 1.
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 WARNING! Be sure the hood is fully latched before driving your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision. Failure to follow this warning could result in serious injury or death.
Page 112: Lights
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Headlights Multifunction Lever Rotate the end of the multifunction lever up- The multifunction lever, located on the left side of the ward to the first detent for headlight operation. steering wheel, controls the operation of the headlights, headlight beam selection, passing light and turn signals.
Page 113: High Beams
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 NOTE: When the headlights are turned on, the Daytime Parking Lights Running Lights will be deactivated. To turn on the parking lights, remove the key High Beams or turn the ignition to OFF/LOCK position and turn on the headlights.
Page 114: Turn Signals
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn Signals NOTE: The indicators will automatically turn off when the turn has been completed and the steering wheel is Push the multifunction lever upward to signal a right returned to a straight position. turn or downward to signal a left turn.
Page 115: Interior Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Deactivation CAUTION! Pull the multifunction lever toward the steering wheel Before getting out of the vehicle be sure that the and hold it for more than two seconds. switch is in the center position or that the lights are Interior Lights off to avoid draining the battery.
Page 116: Front Fog Lights - If Equipped
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When the doors are unlocked with the Key Fob a 10 Front Fog Lights — If Equipped second timer is activated. The fog light switch is located on the center stack of the •...
Page 117: Windshield Wipers And Washers
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 WINDSHIELD WIPERS AND WASHERS The windshield wiper/washer lever is located on the right side of the steering column. NOTE: The windshield wipers/washers will only oper- ate with the ignition in the ON/RUN position. Front Windshield Wiper Operation There are five different modes of operation for the front windshield wipers.
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Intermittent Wiper Operation the lever is released. When the lever is released, the wipers will return to the off position and automatically Push the lever downward to the first detent. The wipers shut off. will operate intermittently.
Page 119: Rear Windshield Wiper
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 wiper/washer lever upward. The rear wiper will operate CAUTION! (Continued) in the same mode as the front windshield wipers, but at • In cold weather, always turn off the wiper switch half the frequency. When the transmission is shifted into and allow the wipers to return to the “Park”...
Page 120: Tilt Steering Column - If Equipped
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The windshield wipers/washers will only oper- ate with the ignition in the ON/RUN position. Rear Windshield Washer Operation Push the windshield wiper/washer lever toward the instrument panel to activate the rear washer. Push and hold the lever for more than a half second and the wipers will activate automatically for three cycles after the lever is released.
Page 121: Electronic Speed Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 The Electronic Speed Control buttons are located on the WARNING! right side of the steering wheel. Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle.
Page 122: To Activate
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: In order to ensure proper operation, the Elec- WARNING! tronic Speed Control system has been designed to shut down if multiple Speed Control functions are operated at Leaving the Electronic Speed Control system on the same time.
Page 123: To Resume Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 deactivate Electronic Speed Control without erasing the The speed increment shown is dependant on the speed of set speed memory. Pressing the ON/OFF button or U.S. (mph) or Metric (km/h) units: turning the ignition switch OFF erases the set speed U.S.
Page 124: To Accelerate For Passing
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • If the button is continually pressed, the set speed will To Decrease Speed continue to decrease until the button is released, then When the Electronic Speed Control is set, you can de- the new set speed will be established.
Page 125: Rear Park Assist - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 REAR PARK ASSIST — IF EQUIPPED WARNING! The Rear Park Assist system provides an audible indica- Electronic Speed Control can be dangerous where the tion of the distance between the rear fascia/bumper and system cannot maintain a constant speed.
Page 126: Rear Park Assist Sensors
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Park Assist Sensors Rear Park Assist Alerts The four Rear Park Assist sensors, located in the rear If an obstacle is behind the vehicle when REVERSE gear fascia/bumper, monitor the area behind the vehicle that is engaged, an audible alert is activated.
Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 Audible And Visual Signals Supplied By The Rear Park Assist System SIGNAL MEANING INDICATION Obstacle Distance An obstacle is present within the Audible signal (dashboard loud- sensors’ field of view speaker) • Sound pulses emitted at a rate that increases as the distance de- creases.
Page 128: Failure Indications
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE While audible signals are emitted, the audio system is not Refer to Electronic Vehicle Information Center (EVIC) in muted. “Understanding Your Instrument Panel” for further information. The audible signal is turned off immediately if the distance increases.
Page 129: Park Assist System Usage Precautions
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 jet/high pressure washing nozzles at least 4 in (10 cm) from not detect an obstacle behind the fascia/bumper, or it the sensors. Do not scratch or poke the sensors. Otherwise, could provide a false indication that an obstacle is you could damage the sensors.
Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! WARNING! • Rear Park Assist is only a parking aid and it is • Drivers must be careful when backing up even unable to recognize every obstacle, including small when using the Rear Park Assist system. Always obstacles.
Page 131: Power Sunroof - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 POWER SUNROOF — IF EQUIPPED WARNING! (Continued) The power sunroof roof switch is located in the overhead • Before using the Rear Park Assist System, it is console. strongly recommended that the ball mount and hitch ball assembly is disconnected from the ve- hicle when the vehicle is not used for towing.
Page 132: To Open
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Open WARNING! Press and hold the power sunroof switch rearward for • Never leave children alone in a vehicle, or with approximately one second and the sunroof will stop at access to an unlocked vehicle. Never leave the Key the vented position.
Page 133: Pinch Protect Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Pinch Protect Feature Emergency Operation This feature will detect an obstruction in the opening of In case of electrical failure the sunroof can be operated the sunroof during Express Close operation. If an ob- with the hex wrench that is located in the glove box.
Page 134: Sun Shade - If Equipped
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sun Shade — If Equipped ELECTRICAL POWER OUTLETS For vehicles equipped with either a power sunroof or a There is a standard 12 Volt (13 Amp) power outlet, fixed glass roof, there is a sun shade that can be open or located in the floor console, for added convenience.
Page 135 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 Power is available when the ignition switch is in the ON/RUN or START position. Insert the cigar lighter or accessory plug into the outlet for use. To preserve the heating element, do not hold the lighter in the heating position.
Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of outlet power from the vehicle’s battery, even when not in should be inserted into any 12 Volt outlet.
Page 137: Cigar Lighter - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 CIGAR LIGHTER — IF EQUIPPED CUPHOLDERS For the driver and front passenger, cupholders are lo- WARNING! cated on the floor console between the front seats. When the cigar lighter is in use it becomes very hot. To avoid serious injury, handle the cigar lighter with care.
Page 138: Storage
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For rear passengers, there are cupholders located on the STORAGE floor between the front driver and passenger seats. Glove Compartment The glove compartment is located on the right side of the instrument panel. Pull outward on the glove compart- ment latch to open the glove compartment.
Page 139: Cargo Area Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 CARGO AREA FEATURES The rear seatbacks have a fold down feature to allow increased cargo capacity. Push down the release button, located at the outboard top of the seatback and move the seatback to its folded- down position to provide a flat load floor cargo area.
Page 140: Rear Window Features
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE REAR WINDOW FEATURES Rear Window Defroster The rear window defroster button is located in the center of the instrument panel, below the radio. Press this button to turn on the rear window defroster. An indicator in the instrument cluster will illuminate when the rear window defroster is on.
Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 CAUTION! Failure to follow these cautions can cause damage to the heating elements: • Use care when washing the inside of the rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements.
Page 143 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS INSTRUMENT PANEL FEATURES ..143 Change Engine Oil Indicator System ..162 INSTRUMENT CLUSTER — POP, LOUNGE, Trip Computer ..... . .163 500C .
Page 144 142 UNDERSTANDING YOUR INSTRUMENT PANEL Technical Specifications ....180 Radio Operation ..... .206 Quick Guide .
Page 145: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 143 INSTRUMENT PANEL FEATURES 1 — Side Vent 7 — Passenger Air Bag 13 — Storage Compartment 2 — Multifunction Lever – Light Control 8 — Glove Compartment 14 — Shift Lever 3 — Instrument Cluster And Warning 9 —...
Page 146: Instrument Cluster - Pop, Lounge, 500C
144 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — POP, LOUNGE, 500C...
Page 147: Instrument Cluster - Sport
UNDERSTANDING YOUR INSTRUMENT PANEL 145 INSTRUMENT CLUSTER — SPORT...
Page 148: Instrument Cluster Descriptions
146 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 2. Rear Defrost Indicator 1. Glow Plug Light — If Equipped This indicator will illuminate when the rear win- dow defroster is on. The rear window defroster This vehicle will inhibit engine cranking when the automatically turns off after 20 minutes.
Page 149 UNDERSTANDING YOUR INSTRUMENT PANEL 147 3. Front Fog Light Indicator — If Equipped will illuminate and the EVIC will show how long the function remains active. For further information, refer to This indicator will illuminate when the front fog “Follow Me Home” in “Understanding The Features of lights are on.
Page 150 148 UNDERSTANDING YOUR INSTRUMENT PANEL 9. Air Bag Warning Light belt is unbuckled, a chime will sound. When driving, if the driver’s seat belt remains unbuckled, the Seat Belt This light will turn on for four seconds as a Reminder Light will illuminate and the chime will sound. bulb check when the ignition switch is first Refer to “Occupant Restraints”...
Page 151 UNDERSTANDING YOUR INSTRUMENT PANEL 149 13. Power Steering System Warning your vehicle may require towing. The light will come on when the ignition is first turned to ON/RUN and remain This light is used to manage the electrical on briefly as a bulb check. If the light does not come on warning of the EPS (Power Steering System).
Page 152 150 UNDERSTANDING YOUR INSTRUMENT PANEL one or more of your tires is significantly under-inflated. illuminated. This sequence will continue upon subse- Accordingly, when the low tire pressure telltale illumi- quent vehicle start-ups as long as the malfunction exists. nates, you should stop and check your tires as soon as When the malfunction indicator is illuminated, the sys- possible, and inflate them to the proper pressure.
Page 153 UNDERSTANDING YOUR INSTRUMENT PANEL 151 vehicle and shut off the engine as soon as possible. A CAUTION! (Continued) chime will sound for four minutes when this light turns equipped on your vehicle. Undesirable system opera- tion or sensor damage may result when using re- Do not operate the vehicle until the cause is corrected.
Page 154 152 UNDERSTANDING YOUR INSTRUMENT PANEL Certain conditions, such as a loose or missing gas cap, WARNING! poor fuel quality, etc., may illuminate the MIL after engine start. The vehicle should be serviced if the light A malfunctioning catalytic converter, as referenced stays on through several of your typical driving cycles.
Page 155 UNDERSTANDING YOUR INSTRUMENT PANEL 153 normal, turn the engine off immediately and call for Vehicles equipped with the Anti-Lock Brake System service. Refer to “If Your Engine Overheats” in “What To (ABS), are also equipped with Electronic Brake Force Do In Emergencies” for further information. Distribution (EBD).
Page 156 154 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: This light shows only that the parking brake is been detected in the ESC system. If this light remains on, applied. It does not show the degree of brake application. see your authorized dealer as soon as possible to have the problem diagnosed and corrected.
Page 157 Anti-Lock the vehicle. Contact a Fiat dealer if you still cannot start brakes. If the ABS light does not turn on when the the engine.
Page 158 156 UNDERSTANDING YOUR INSTRUMENT PANEL The gauge pointer will likely indicate a higher tempera- WARNING! ture when driving in hot weather, up mountain grades, or when towing a trailer. It should not be allowed to A hot engine cooling system is dangerous. You or exceed the upper limits of the normal operating range.
Page 159 UNDERSTANDING YOUR INSTRUMENT PANEL 157 as it was before the repair or service. If s/he cannot do so, 28. Fuel Gauge / Fuel Door Reminder then the odometer must be set at zero, and a sticker must The fuel door reminder indicates that the fuel filler door be placed in the door jamb stating what the mileage was is located on the right side of the vehicle.
Page 160: Electronic Vehicle Information Center (Evic)
158 UNDERSTANDING YOUR INSTRUMENT PANEL ELECTRONIC VEHICLE INFORMATION CENTER The EVIC consists of the following: (EVIC) • System Status The Electronic Vehicle Information Center (EVIC) fea- • Vehicle Information Warning Message Displays tures a driver-interactive display that is located in the •...
Page 161: Evic Displays
UNDERSTANDING YOUR INSTRUMENT PANEL 159 EVIC Displays Premium Instrument Cluster SPORT Instrument Cluster 1 — Ice Warning Indicator 6 — Message Display 2 — Temperature Indicator 7 — Coolant Temperature Gauge 1 — Temperature Indicator 6 — Message Display 3 — Fuel Level Gauge 8 —...
Page 162: Evic Control Buttons
160 UNDERSTANDING YOUR INSTRUMENT PANEL EVIC Control Buttons NOTE: When opening one of the front doors, the EVIC display will turn on the clock and the miles or kilometers Press the MENU button briefly to access the menu covered (for versions/markets, where provided) for a and/or go to next screen or to confirm the required menu few seconds.
Page 163 UNDERSTANDING YOUR INSTRUMENT PANEL 161 • Set Date Selecting An Option Of The Main Menu Without Submenu • See Radio 1. Briefly press the MENU button to select the main • Speed Display menu option to set. • Autoclose 2. Press the UP or DOWN button (by single •...
Page 164: Change Engine Oil Indicator System
162 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Briefly press the MENU button to select the displayed scheduled oil change interval. The engine oil change submenu option and to open the relevant setup menu. indicator system is duty cycle based, which means the engine oil change interval may fluctuate, dependent 4.
Page 165: Trip Computer
UNDERSTANDING YOUR INSTRUMENT PANEL 163 NOTE: If the indicator message illuminates when you New Trip start the vehicle, the oil change indicator system did not To reset: reset. If necessary, repeat this procedure. • Push and hold the TRIP button to reset the system Trip Computer manually.
Page 166: Trip Functions
164 UNDERSTANDING YOUR INSTRUMENT PANEL • Trip distance A Start Of Trip Procedure • Average consumption With the ignition on, push and hold the TRIP button for over one second to reset. • Instantaneous consumption Exit Trip • Average speed A To exit the Trip function, wait until all the values have •...
Page 167: Values Displayed
UNDERSTANDING YOUR INSTRUMENT PANEL 165 Values Displayed Average Consumption This value shows the approximate average consumption Range since the last reset. This indicates the distance which may be traveled with the fuel remaining in the tank, assuming that driving Instant Consumption conditions will not change.
Page 168: Personal Settings (Customer-Programmable Features)
166 UNDERSTANDING YOUR INSTRUMENT PANEL Personal Settings (Customer-Programmable 2. Briefly press the MENU button to go back to the menu Features) screen or press and hold the MENU (approximately one second) to go back to the main screen without Dimmer storing settings.
Page 169 UNDERSTANDING YOUR INSTRUMENT PANEL 167 3. When the function is activated (On), briefly press the To cancel the setting, proceed as follows: MENU button to display the presently set activation 1. Briefly press the MENU button. “On” will flash on the speed.
Page 170 168 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Press the UP or DOWN button to select Trip 2. Press the UP or DOWN button to navigate B data. Press the UP or DOWN buttons to the two sub-menu items. turn ON or OFF 3.
Page 171 UNDERSTANDING YOUR INSTRUMENT PANEL 169 NOTE: sub-menu screen, or press and hold the MENU button (approximately one second) to go back to the main screen • The setting will increase or decrease by one unit each without storing the settings. time the UP or DOWN button is pressed.
Page 172 170 UNDERSTANDING YOUR INSTRUMENT PANEL • Radio: tuned radio station frequency, automatic tuning 5. Briefly press the MENU button and “day” will flash on the display. activation or AutoSTore. • CD audio, CD MP3: track number. 6. Press the UP or DOWN button for setting.
Page 173 UNDERSTANDING YOUR INSTRUMENT PANEL 171 Speed Display Autoclose When this function is activated the cluster will display With this function active, the doors will automatically the vehicle speed (MPH or km/h). lock at when the vehicle’s speed exceeds 15 mph (24 km/h).
Page 174 172 UNDERSTANDING YOUR INSTRUMENT PANEL Units (Set Units) 5. Press the UP or DOWN button for setting. This function may be used to set the measurement unit in 6. Briefly press the MENU button to return to the three submenus: “Distance,” “Temperature” and “Fuel sub-menu.
Page 175 UNDERSTANDING YOUR INSTRUMENT PANEL 173 3. When accessing the “Temperature” submenu: briefly To set the required language, proceed as follows: press the MENU button. Either “°F” or “°C” will 1. Briefly press the MENU button. Press the UP appear on the display (according to the previous DOWN button to highlight Language.
Page 176 Button Volume (Button Volume Adjustment) Indication) This function may be used to adjust the volume of the This function will only be displayed after a FIAT Group beep accompanying the buttons. MENU, UP Automobiles dealership has deactivated the S.B.R. sys-...
Page 177 UNDERSTANDING YOUR INSTRUMENT PANEL 175 Daytime Running Lamps (DRL) GSI (Gear Shift Indicator) This function may be used to activate / deactivate the This function may be used to set the Gear Shift Indicator Daytime Running Lamps. in two submenus: “Fuel Econ On” and “Fuel Econ Off.” •...
Page 178 176 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Press the UP or DOWN button for setting. Proceed as follows to switch this function on or off: 5. Briefly press the MENU button to return to the 1. Briefly press the MENU button. Press the UP sub-menu.
Page 179 UNDERSTANDING YOUR INSTRUMENT PANEL 177 Tire Pressure Entry (RKE) transmitter UNLOCK button. When Unlock Drivers Door is selected, you must press the RKE trans- This function will be used to display the tire pressures mitter UNLOCK button twice to unlock the passenger individually for all four tires by location.
Page 180: Sales Code (Rab) Radio
178 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE (RAB) RADIO If the radio has BLUE&ME™, refer to the appropriate “BLUE&ME™ User’s Manual” for further information. The instructions for use are given below and we recom- mend you to read them carefully. Suggestions Road Safety Please, learn how to use all different radio functions (e.g.
Page 181 UNDERSTANDING YOUR INSTRUMENT PANEL 179 • Clean every CD thoroughly removing any finger WARNING! marks or dust using a soft cloth. Hold CDs by the outside and clean them from the middle outwards. Having the volume turned up high can cause the driver to not be able to hear important traffic sounds, •...
Page 182: Technical Specifications
180 UNDERSTANDING YOUR INSTRUMENT PANEL • The use of original CD media is required for the best • The CD player is capable of reading most compression quality audio production. Correct operation is not systems currently in use, following the development of guaranteed when CD-R/RW media are used that were these systems, the reading of all compression formats not correctly burned and/or with a maximum capacity...
Page 183: Quick Guide
UNDERSTANDING YOUR INSTRUMENT PANEL 181 • Antenna on the car roof. With Alpine Premium Audio system (if equipped): • Two 165 mm diameter midwoofer speakers. • Radio with CD/MP3 player. • Two 11 mm tweeter speakers in the front pillars. With BEATS Premium Audio system (if equipped): •...
Page 184 182 UNDERSTANDING YOUR INSTRUMENT PANEL BUTTON GENERAL FUNCTIONS MODE (Mute/Pause Button) Volume activation/deactivation Short button press (Mute/Pause) AUDIO Audio adjustments: low tones Menu activation: short button press (BASS), high tones (TREBLE), left/ Adjustment type selection: press right balance (BALANCE), front/ Adjustment of values: press rear balance (FADER) (Information Button)
Page 185 UNDERSTANDING YOUR INSTRUMENT PANEL 183 BUTTON RADIO FUNCTIONS MODE Radio Station Search: Automatic search: press buttons • Automatic Search (long press for fast for- • Manual Search ward) Manual search: press buttons (long press for fast forward) 1 2 3 4 5 Current radio station storing Long button press for memory pre- set 1 to 5 respectively...
Page 186: General Information
184 UNDERSTANDING YOUR INSTRUMENT PANEL General Information CD Section • Track selection (forward/backward) The radio offers the following functions: • Fast forward/rewind through tracks Radio Section • PLL tuning with FM/AM bands • CD Display function: display of track number and on mp3 discs (song title, artist) and time elapsed since •...
Page 187: Functions And Adjustments
UNDERSTANDING YOUR INSTRUMENT PANEL 185 • Separate bass/treble tone adjustment CD/MP3 Section • MP3-Info function (ID3-TAG) • Right/left channel balancing • Folder selection (previous/next) • Front/rear fader • Track selection (forward/backward) Functions And Adjustments • Fast forward/rewind through tracks Turning The Car Radio On •...
Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL Selecting The Radio Functions Press the button again to deactivate the MUTE function. The volume will gradually increase until it By pressing the TUNER button briefly and repeatedly, reaches the previously set level. the following audio sources can be selected cyclically: When the volume level is changed using the dedicated •...
Page 189 UNDERSTANDING YOUR INSTRUMENT PANEL 187 • EQUALIZER — If equipped (activation and selection Use the buttons to scroll through the Menu functions. To change the setting of the selected func- of factory equalization adjustments) tion, use the buttons. • USER EQUALIZER — If equipped (customized equal- The current status of the selected function appears on the ization adjustment) display.
Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL Balance Adjustment Fader Adjustment Proceed as follows: Proceed as follows: 1. Press AUDIO button. 1. Press AUDIO button. 2. Press the button to set “Balance” in the 2. Press the button to set “Fader” in the AUDIO menu.
Page 191 UNDERSTANDING YOUR INSTRUMENT PANEL 189 Loudness Function — If Equipped To activate the equalizer, use the AUDIO button or to select one of the adjustments: The Loudness function improves the volume of the • “EQ User” (adjustment of 7 equalizer bands that can sound while listening at low volumes, increasing the bass and treble.
Page 192 190 UNDERSTANDING YOUR INSTRUMENT PANEL User EQ Settings Function — If Equipped Menu To set a personalized equalizer adjustment: MENU Button Functions 1. Press AUDIO button. Press the MENU button briefly to activate the Menu function. 2. Use the buttons to set EQ function. Use the buttons to scroll through the menu 3.
Page 193 UNDERSTANDING YOUR INSTRUMENT PANEL 191 • SiriusXM Telephone Number • High: function activated (high sensitivity) • System Reset On Volume Limit • Speed Volume This function makes it possible to activate/deactivate the maximum volume limit when turning the radio on. •...
Page 194 192 UNDERSTANDING YOUR INSTRUMENT PANEL • “On volume limit: off” – The radio will come on at the • “Radio off: 00 min” — The radio turns off in connec- same volume as before it was switched off. The tion with the ignition key; the radio is turned auto- volume level can be between 0 and 40.
Page 195: Radio
UNDERSTANDING YOUR INSTRUMENT PANEL 193 Radio Each time the button is pressed the following bands are selected cyclically: (Tuner) Introduction • AM, FM or SAT (if equipped) When the car radio is turned on, the last function that was selected before turning it off (Radio, CD, CD MP3, Each band is highlighted by the corresponding wordings AUX) is activated.
Page 196: Siriusxm Satellite Radio - If Equipped
194 UNDERSTANDING YOUR INSTRUMENT PANEL By pressing the preset button for more than 2 seconds, the desired direction. If the button is pressed the tuned station will be stored. Pressing the A-B-C longer, the fast search starts and then stops when the button will change between the preset memory group in button is released.
Page 197 UNDERSTANDING YOUR INSTRUMENT PANEL 195 weather. All of this with crystal clear, coast-to-coast that program type. Pressing buttons will tune coverage. Everything worth listening to is now on Siri- to only the stations in that program type. usXM. A one-year SiriusXM Satellite Radio subscription Pressing the buttons until All is displayed is included.
Page 198 SIRIUS information to order a new radio (even if the CAUTION! SIRIUS subscription has lapsed). The ESN number con- tains 12 digits. Neither SIRIUS nor FIAT is responsible for any errors in accuracies in the SIRIUS data services or its use in vehicles.
Page 199: Cd Player
UNDERSTANDING YOUR INSTRUMENT PANEL 197 The following are instructions for retrieving the Elec- CD Player tronic Serial Number (ESN) from FIAT 500 NAFTA model Introduction radios: This chapter describes the operation of the CD player To retrieve the ESN of SIRIUS Satellite Receiver Module only.
Page 200 198 UNDERSTANDING YOUR INSTRUMENT PANEL It is advisable to use original CDs to ensure optimal Press the button with the radio turned on, to playing. If CD-R/RWs are used, we recommend using activate the motorized CD ejection system. After ejec- good quality media that are burned at the slowest speed tion, the last audio source listened to before playing possible.
Page 201 UNDERSTANDING YOUR INSTRUMENT PANEL 199 A CD which cannot be read will not be ejected until these If the track has been played for more than 3 seconds, functions are over. At the end, with the CD mode pressing the button, starts the track again from the activated, the display will show the wording “CD Disc beginning.
Page 202: Cd Mp3 Player
200 UNDERSTANDING YOUR INSTRUMENT PANEL CD MP3 Player The specifications and operating conditions for playing MP3 files are the following: Introduction • The CD-ROMs used should be burned in accordance This chapter describes the operation of the CD MP3 with ISO standard 9660. player.
Page 203 UNDERSTANDING YOUR INSTRUMENT PANEL 201 Selecting MP3 Sessions With Hybrid Discs When one of the ID3-TAG pieces of information is chosen to be displayed (Title, Artist, Album) and this informa- If a hybrid disc is inserted (Mixed Mode, Enhanced, tion has not been recorded for the track played, the text CD-Extra) also containing MP3 files, the radio automati- UNKNOWN will be displayed for that field.
Page 204: Troubleshooting
202 UNDERSTANDING YOUR INSTRUMENT PANEL Structure Of The Folders Troubleshooting The radio with MP3 player: General • Recognizes only the folders that effectively contain Sound Volume Low MP3 format files. The Fader function should be adjusted to the values “F” •...
Page 205 UNDERSTANDING YOUR INSTRUMENT PANEL 203 Source Can Not Be Selected The Duration Of The Mp3 Tracks Is Not Correctly Displayed: Nothing has been loaded. Load the CD or the MP3 CD to In some cases (due to the recording mode) the duration of be listened to.
Page 206: Ipod®/Usb/Media Player Control - If
204 UNDERSTANDING YOUR INSTRUMENT PANEL iPod®/USB/MEDIA PLAYER CONTROL — IF EQUIPPED This feature allows an iPod® or external USB device to be plugged into the USB port, located in the glove compart- ment. USB/AUX Port 1 — iPod® Or External USB Device Holder 2 —...
Page 207: Steering Wheel Audio Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 205 STEERING WHEEL AUDIO CONTROLS The right-hand control is a rocker-type switch with a pushbutton in the center and controls the volume and The remote sound system controls are located on the rear mode of the sound system. Pressing the top of the rocker surface of the steering wheel.
Page 208: Radio Operation
206 UNDERSTANDING YOUR INSTRUMENT PANEL Radio Operation Operating Instructions — Hands-Free Phone (If Equipped) Pressing the top of the switch will “Seek” up for the next listenable station and pressing the bottom of the switch Refer to the appropriate Blue&Me™ User’s Manual for will “Seek”...
Page 209: Radio Operation And Mobile Phones
UNDERSTANDING YOUR INSTRUMENT PANEL 207 5. Store the disc in its case after playing. RADIO OPERATION AND MOBILE PHONES Under certain conditions, the mobile phone being on in 6. Do not expose the disc to direct sunlight. your vehicle can cause erratic or noisy performance from 7.
Page 210: Manual Heating And Air Conditioning
208 UNDERSTANDING YOUR INSTRUMENT PANEL Manual Heating And Air Conditioning 1. Temperature Control Rotate this control to regulate the temperature of the air inside the passenger compartment. Rotating the dial to the left into the blue area of the scale indicates cooler temperatures, while rotating to the right into the red area indicates warmer temperatures.
Page 211 UNDERSTANDING YOUR INSTRUMENT PANEL 209 • Panel NOTE: Air is directed through the outlets in the instru- • Continuous use of the Recirculation mode may make ment panel. These outlets can be adjusted to direct the inside air stuffy and window fogging may occur. airflow.
Page 212: Automatic Temperature Control (Atc) - If Equipped
210 UNDERSTANDING YOUR INSTRUMENT PANEL to the windshield. This setting is good for maintaining MAX A/C comfort while reducing moisture on the windshield. For maximum cooling, use the A/C and recirculation • Defrost modes at the same time. Air is directed through the windshield and side ECONOMY MODE window demister outlets.
Page 213 UNDERSTANDING YOUR INSTRUMENT PANEL 211 2. A/C Button Press and release to change the current Air Conditioning (A/C) setting. Performing this function will cause the ATC to switch into manual mode. 3. Temperature Control Up Button Provides temperature up control. Push the button for warmer temperature settings.
Page 214 212 UNDERSTANDING YOUR INSTRUMENT PANEL reducing moisture on the windshield. Performing this NOTE: The center instrument panel outlets can be aimed function will cause the ATC to switch into manual mode. so that they are directed toward the rear seat passengers for maximum airflow to the rear.
Page 215 UNDERSTANDING YOUR INSTRUMENT PANEL 213 NOTE: 3. When the system is set up for your comfort level, it is not necessary to change the settings. You will experi- • When in Defrost mode, the Recirculation button will ence the greatest efficiency by simply allowing the flash if pressed.
Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL To provide you with maximum comfort in the Automatic Blower Control mode during cold start-ups, the blower fan will remain There are 12 fixed blower speeds. Use on low until the engine warms up. The blower will the blower control up or down buttons increase in speed and transition into AUTO mode.
Page 217 UNDERSTANDING YOUR INSTRUMENT PANEL 215 • Panel Mode • Mix Mode Air comes from the outlets in the instrument Air comes from the floor, defrost and side window panel. Each of these outlets can be individually demister outlets. This mode works best in cold or adjusted to direct the flow of air.
Page 218 216 UNDERSTANDING YOUR INSTRUMENT PANEL Air Conditioning (A/C) Recirculation Control The Air Conditioning (A/C) button allows the operator to manually activate or deactivate the air conditioning When outside air contains smoke, odors, or high system. When in A/C mode with the ATC set to a cool humidity, or if rapid cooling is desired, you may temperature, dehumidified air flows through the air wish to recirculate interior air by pressing the RECIRCU-...
Page 219: Operating Tips
UNDERSTANDING YOUR INSTRUMENT PANEL 217 NOTE: In cold weather, use of Recirculation mode may will clear the fog. Adjust the temperature control, air lead to excessive window fogging. The recirculation direction, and blower speed to maintain comfort. feature may be unavailable (indicator light shall blink) if As the temperature gets colder, it may be necessary to conditions exist that could create fogging on the inside of direct air onto the windshield.
Page 220 218 UNDERSTANDING YOUR INSTRUMENT PANEL Summer Operation Vacation Storage Anytime you store your vehicle, or keep it out of service NOTE: In some cases during high temperature opera- (i.e., vacation) for two weeks or more, run the air tion, the air conditioning system performance may be conditioning system at idle for about five minutes in the reduced.
Page 221: Starting And Operating
STARTING AND OPERATING CONTENTS STARTING PROCEDURES ....223 Five-Speed Manual Transmission...226 Manual Transmission — If Equipped ..223 Recommended Shift Speeds .
Page 222 220 STARTING AND OPERATING AUTOSTICK® ......238 BRAKE SYSTEM ..... . .248 Operation .
Page 223 STARTING AND OPERATING 221 TIRES — GENERAL INFORMATION ..268 TIRE ROTATION RECOMMENDATIONS ..281 Tire Pressure ......268 TIRE PRESSURE MONITORING SYSTEM (TPMS) .
Page 224 222 STARTING AND OPERATING Materials Added To Fuel ....295 Loose Fuel Filler Cap Message ... .298 Fuel System Cautions.
Page 225: Starting Procedures
STARTING AND OPERATING 223 STARTING PROCEDURES Manual Transmission — If Equipped Before starting your vehicle, adjust your seat, adjust both Apply the parking brake, place the shift lever in NEU- inside and outside mirrors, and fasten your seat belts. TRAL, and press the clutch pedal before starting the vehicle.
Page 226: Cold Weather Operation
224 STARTING AND OPERATING Turn the ignition switch to the AVV/ACC (START) CAUTION! position and release it when the engine starts. If the engine fails to start within 10 seconds, turn the ignition Use of the recommended oil and adhering to the switch to the STOP (OFF/LOCK) position, wait 10 to 15 prescribed oil change intervals is important to pre- seconds, then repeat the “Normal Starting”...
Page 227: If Engine Fails To Start
STARTING AND OPERATING 225 3. If the engine fails to start within 10 seconds, cycle the CAUTION! ignition to the STOP (OFF/LOCK) position, wait five • Do not attempt to push or tow your vehicle to get it seconds to allow the starter to cool, then repeat the Extended Park Starting procedure.
Page 228: Turbocharger "Cool Down
226 STARTING AND OPERATING Turbocharger “Cool Down” This vehicle is equipped with an after-run pump to cool the turbocharger after the engine is shut off. Depending on the type of driving and the amount of cargo, the pump will run for up to 10 minutes after the engine has been shut off to circulate coolant through the turbocharger.
Page 229: Recommended Shift Speeds
STARTING AND OPERATING 227 Use each gear in numerical order; do not skip a gear. Be stop spinning. Should an unwanted clash noise be pro- sure the transmission is in first gear, not third, when duced, the pause length should be increased. starting from a standing position.
Page 230: Downshifting
228 STARTING AND OPERATING Manual Transmission Recommended Shift Speeds Units In mph (km/h) 1 to 2 2 to 3 3 to 4 4 to 5 Engine Size Acceleration Rate 1.4L/1.4L Turbo Accel Engine (23) (37) (47) (61) Cruise (19) (29) (40) (52) Downshifting...
Page 231: Automatic Transmission
STARTING AND OPERATING 229 To maintain a safe speed and prolong brake life, shift CAUTION! (Continued) down to second or first gear when descending a steep • Before shifting into any gear, make sure your foot grade. is firmly pressing the brake pedal. When turning a corner or driving up a steep grade, downshift early so that the engine will not be overbur- NOTE: You must press and hold the brake pedal while...
Page 232: Key Ignition Park Interlock
230 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Unintended movement of a vehicle could injure • Never leave children alone in a vehicle, or with those in or near the vehicle. As with all vehicles, access to an unlocked vehicle. Allowing children to you should never exit a vehicle while the engine is be in a vehicle unattended is dangerous for a running.
Page 233: Brake/Transmission Shift Interlock System
STARTING AND OPERATING 231 OFF (key removal) position. The key can only be re- The electronically-controlled transmission provides a moved from the ignition when the ignition is in the precise shift schedule. The transmission electronics are LOCK/OFF position, and once removed, the transmis- self-calibrating;...
Page 234: Gear Ranges
232 STARTING AND OPERATING Only shift from DRIVE to PARK or REVERSE when the NOTE: If the shift lever cannot be moved to the PARK, accelerator pedal is released and the vehicle is stopped. REVERSE, or NEUTRAL position (when pushed for- Be sure to keep your foot on the brake pedal when ward) it is probably in the AutoStick®...
Page 235 STARTING AND OPERATING 233 PARK (P) WARNING! This range supplements the parking brake by locking the • Never use the PARK position as a substitute for the transmission. The engine can be started in this range. parking brake. Always apply the parking brake Never attempt to use PARK while the vehicle is in fully when parked to guard against vehicle move- motion.
Page 236 234 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Unintended movement of a vehicle could injure • Never leave children alone in a vehicle, or with those in or near the vehicle. As with all vehicles, access to an unlocked vehicle. Allowing children to you should never exit a vehicle while the engine is be in a vehicle unattended is dangerous for a running.
Page 237 STARTING AND OPERATING 235 • Look at the transmission gear position display and CAUTION! verify that it indicates the PARK position. • Before moving the shift lever out of PARK, you • With brake pedal released, verify that the shift lever must turn the ignition switch from the LOCK/OFF will not move out of PARK.
Page 238 236 STARTING AND OPERATING DRIVE (D) WARNING! This range should be used for most city and highway Do not coast in NEUTRAL and never turn off the driving. It provides the smoothest upshifts and down- ignition to coast down a hill. These are unsafe shifts, and the best fuel economy.
Page 239 STARTING AND OPERATING 237 range of torque converter clutch engagement. This is In the event of a momentary problem, the transmission done to prevent transmission damage due to overheat- can be reset to regain all forward gears by performing the ing.
Page 240: Autostick
238 STARTING AND OPERATING If the transmission cannot be reset, authorized dealer forward (-) triggers a downshift, and rearward (+) an service is required. upshift. The current gear is displayed in the instrument cluster. AUTOSTICK® NOTE: In AutoStick® mode, the transmission will only AutoStick®...
Page 241: Driving On Slippery Surfaces
STARTING AND OPERATING 239 in snow or icy conditions. To select second or third AutoStick® position at any time without taking your foot gear after the vehicle is brought to a stop, tap the shift off the accelerator pedal. lever rearward (+) once or twice. WARNING! •...
Page 242: Traction
240 STARTING AND OPERATING 2. Slow down if the road has standing water or puddles. WARNING! 3. Replace the tires when tread wear indicators first Rapid acceleration on slippery surfaces is dangerous. become visible. Unequal traction can cause sudden pulling of the 4.
Page 243: Flowing/Rising Water
STARTING AND OPERATING 241 Flowing/Rising Water WARNING! • Driving through standing water limits your vehi- WARNING! cle’s traction capabilities. Do not exceed 5 mph Do not drive on or across a road or path where water (8 km/h) when driving through standing water. is flowing and/or rising (as in storm run-off).
Page 244 242 STARTING AND OPERATING CAUTION! CAUTION! (Continued) • Driving through standing water may cause damage • Always check the depth of the standing water to your vehicle’s drivetrain components. Always before driving through it. Never drive through inspect your vehicle’s fluids (i.e., engine oil, trans- standing water that is deeper than the bottom of mission, axle, etc.) for signs of contamination (i.e., the tire rims mounted on the vehicle.
Page 245: Power Steering
STARTING AND OPERATING 243 POWER STEERING If the Steering icon is displayed and the “POWER STEER- ING SYSTEM OVER TEMP” message is displayed on the The electric power steering system will give you good EVIC screen, they indicate that extreme steering maneu- vehicle response and increased ease of maneuverability vers may have occurred which caused an over tempera- in tight spaces.
Page 246: Parking Brake
244 STARTING AND OPERATING NOTE: • Even if the power steering assistance is no longer operational, it is still possible to steer the vehicle. Under these conditions there will be a substantial increase in steering effort, especially at low speeds and during parking maneuvers.
Page 247 STARTING AND OPERATING 245 When parking on a hill, it is important to turn the front WARNING! (Continued) wheels toward the curb on a downhill grade and away • Do not leave the Key Fob in or near the vehicle or from the curb on an uphill grade.
Page 248: Sport Mode
246 STARTING AND OPERATING CAUTION! If the Brake Warning Light remains on with the parking brake released, a brake system malfunction is indicated. Have the brake system serviced by an authorized dealer immediately. SPORT MODE Manual Transmission — If Equipped The Sport mode increases steering feedback to the driver with slight increases in effort and throttle pedal-to-engine SPORT Button...
Page 249: Automatic Transmission - If Equipped
STARTING AND OPERATING 247 Automatic Transmission — If Equipped The Sport mode increases steering feedback to the driver with slight increase in effort and changes the transmis- sion shift schedules for more aggressive shifting. This driving mode is useful while driving on twisty roads where more steering precision is desired in spirited cornering.
Page 250: Brake System
248 STARTING AND OPERATING BRAKE SYSTEM ELECTRONIC BRAKE CONTROL SYSTEM In the event power assist is lost for any reason (for Your vehicle is equipped with a advanced electronic example; repeated brake applications with the engine brake control system that includes the Anti-Lock Brake off), the brakes will still function.
Page 251 STARTING AND OPERATING 249 The ABS includes an amber ABS Warning Light. When WARNING! (Continued) the light is illuminated, the ABS is not functioning. The • The ABS cannot prevent collisions, including those system reverts to standard non-anti-lock brakes. Turning resulting from excessive speed in turns, following the ignition Off and On again may reset the ABS if the another vehicle too closely, or hydroplaning.
Page 252: Brake Assist System (Bas)
250 STARTING AND OPERATING Brake Assist System (BAS) WARNING! The BAS is designed to optimize the vehicle’s braking • The Brake Assist System (BAS) cannot prevent the capability during emergency braking maneuvers. The natural laws of physics from acting on the vehicle, system detects an emergency braking situation by sens- nor can it increase the traction afforded by prevail- ing the rate and amount of brake application and then...
Page 253: Hill Start Assist (Hsa)
STARTING AND OPERATING 251 stability. A feature of the TCS system, Brake Limited system will release brake pressure in proportion to the Differential (BLD), functions similar to a limited slip amount of throttle applied as the vehicle starts to move in differential and controls the wheel spin across a driven the intended direction of travel.
Page 254: Electronic Stability Control (Esc)
252 STARTING AND OPERATING Electronic Stability Control (ESC) WARNING! This system enhances directional control and stability of There may be situations on minor hills with a loaded the vehicle under various driving conditions. ESC cor- vehicle, or while pulling a trailer, when the system rects for oversteering or understeering of the vehicle by will not activate and slight rolling may occur.
Page 255 STARTING AND OPERATING 253 ESC Off Switch (Automatic Transmission) ESC Off Switch (Manual Transmission) NOTE: The ESC Off switch is located left of the steering column (Manual Transmission Only).
Page 256 254 STARTING AND OPERATING ESC Operating Modes WARNING! The ESC system has two available operating modes. The Electronic Stability Control (ESC) cannot pre- Full On vent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by This is the normal operating mode for ESC.
Page 257: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
STARTING AND OPERATING 255 To turn ESC on again, momentarily press the switch WARNING! again. This will restore the normal ESC On mode of • When in “Partial Off” mode, the TCS functionality operation. of ESC, (except for the limited slip feature de- NOTE: To improve the vehicle’s traction when driving scribed in the TCS section), has been disabled and with snow chains, or starting off in deep snow, sand or...
Page 258 256 STARTING AND OPERATING on continuously with the engine running, a malfunction NOTE: has been detected in the ESC system. If this light remains • The ESC Activation/Malfunction Indicator Light and on after several ignition cycles, and the vehicle has been the ESC OFF Indicator Light come on momentarily driven several miles (kilometers) at speeds greater than each time the ignition switch is turned ON.
Page 259: Tire Safety Information
STARTING AND OPERATING 257 TIRE SAFETY INFORMATION NOTE: • P (Passenger) - Metric tire sizing is based on U.S. Tire Markings design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. •...
Page 260 258 STARTING AND OPERATING • Temporary spare tires are designed for temporary • High flotation tire sizing is based on U.S. design emergency use only. Temporary high pressure com- standards and it begins with the tire diameter molded pact spare tires have the letter “T” or “S” molded into into the sidewall.
Page 261 STARTING AND OPERATING 259 EXAMPLE: R = Construction code – R means radial construction – D means diagonal or bias construction 15 = Rim diameter in inches (in) Service Description: 95 = Load Index – A numerical code associated with the maximum load a tire can carry H = Speed Symbol –...
Page 262: Tire Identification Number (Tin)
260 STARTING AND OPERATING EXAMPLE: Load Identification: ..blank..= Absence of any text on the sidewall of the tire indicates a Standard Load (SL) tire Extra Load (XL) = Extra load (or reinforced) tire Light Load (LL) = Light load tire C, D, E, F, G = Load range associated with the maximum load a tire can carry at a specified pressure Maximum Load –...
Page 263 STARTING AND OPERATING 261 EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation – This symbol certifies that the tire is in compliance with the U.S. Department of Transportation tire safety standards and is approved for highway use MA = Code representing the tire manufacturing location (two digits) L9 = Code representing the tire size (two digits) ABCD = Code used by the tire manufacturer (one to four digits)
Page 264: Tire Terminology And Definitions
262 STARTING AND OPERATING Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold tire inflation pressure is defined as the tire pressure after Cold Tire Inflation Pressure the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 265: Tire Loading And Tire Pressure
STARTING AND OPERATING 263 Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door. B-Pillar Location For Tire And Loading Information Placard...
Page 266 264 STARTING AND OPERATING Tire And Loading Information Placard 3. Tire size designed for your vehicle. 4. Cold tire inflation pressures for the front, rear, and spare tires. Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading...
Page 267 STARTING AND OPERATING 265 To determine the maximum loading conditions of your 4. The resulting figure equals the available amount of vehicle, locate the statement “The combined weight of cargo and luggage load capacity. For example, if occupants and cargo should never exceed XXX lbs or “XXX”...
Page 268 266 STARTING AND OPERATING NOTE: • If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. The follow- ing table shows examples on how to calculate total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations and num- ber and size of occupants.
Page 269 STARTING AND OPERATING 267...
Page 270: Tires - General Information
268 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 271: Tire Inflation Pressures
STARTING AND OPERATING 269 Ride Comfort And Vehicle Stability WARNING! (Continued) Proper tire inflation contributes to a comfortable ride. • Unequal tire pressures from one side of the vehicle Over-inflation produces a jarring and uncomfortable to the other can cause the vehicle to drift to the ride.
Page 272 270 STARTING AND OPERATING At least once a month: mile (1.6 km) after a three hour period. The cold tire inflation pressure must not exceed the maximum infla- • Check and adjust tire pressure with a good quality tion pressure molded into the tire sidewall. pocket-type pressure gauge.
Page 273: Tire Pressures For High Speed Operation
STARTING AND OPERATING 271 Tire Pressures For High Speed Operation Radial Ply Tires The manufacturer advocates driving at safe speeds and WARNING! within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high Combining radial ply tires with other types of tires speeds, maintaining correct tire inflation pressure is very on your vehicle will cause your vehicle to handle...
Page 274: Tire Types
272 STARTING AND OPERATING Consult an authorized tire dealer for tire repairs and Summer Or Three Season Tires — If Equipped additional information. Summer tires provide traction in both wet and dry Damaged Run Flat tires, or Run Flat tires that have conditions, and are not intended to be driven in snow or experienced a loss of pressure should be replaced imme- on ice.
Page 275: Run Flat Tires - If Equipped
STARTING AND OPERATING 273 If you need snow tires, select tires equivalent in size and Run Flat Tires — If Equipped type to the original equipment tires. Use snow tires only Run Flat tires allow you the capability to drive 50 miles in sets of four;...
Page 276: Spare Tires - If Equipped
274 STARTING AND OPERATING Spare Tires — If Equipped rotation for your vehicle. If your vehicle has this option, refer to an authorized tire dealer for the recommended NOTE: For vehicles equipped with TIREFIT instead of a tire rotation pattern. spare tire, please refer to “TIREFIT KIT”...
Page 277 STARTING AND OPERATING 275 Do not install a wheel cover or attempt to mount a front or rear axle of your vehicle, but it is not. This spare conventional tire on the compact spare wheel, since the tire may have limited tread life. When the tread is worn wheel is designed specifically for the compact spare tire.
Page 278: Tire Spinning
276 STARTING AND OPERATING Refer to “Freeing A Stuck Vehicle” in “What To Do In WARNING! Emergencies” for further information. Limited-use spares are for emergency use only. In- WARNING! stallation of this limited-use spare tire affects vehicle handling. With this tire, do not drive more than the Fast spinning tires can be dangerous.
Page 279: Life Of Tire
STARTING AND OPERATING 277 tread wear indicators, the tire should be replaced. Refer to “Replacement Tires” in this section for further infor- mation. Life Of Tire The service life of a tire is dependent upon varying factors including, but not limited to: •...
Page 280: Replacement Tires
278 STARTING AND OPERATING Information placard or the Vehicle Certification Label for WARNING! the size designation of your tire. The Load Index and Speed Symbol for your tire will be found on the original Tires and the spare tire should be replaced after six equipment tire sidewall.
Page 281: Tire Chains (Traction Devices)
STARTING AND OPERATING 279 WARNING! WARNING! (Continued) • Failure to equip your vehicle with tires having • Do not use a tire, wheel size or rating other than adequate speed capability can result in sudden tire that specified for your vehicle. Some combinations failure and loss of vehicle control.
Page 282 280 STARTING AND OPERATING • Install on Front Tires. CAUTION! (Continued) • Due to limited clearance, a 185/55R15 tire with a • Because of restricted traction device clearance be- Security Chain Company (SCC) Super Z6 low profile tween tires and other suspension components, it is traction device or equivalent is recommended.
Page 283: Tire Rotation Recommendations
STARTING AND OPERATING 281 These effects can be reduced by timely rotation of tires. CAUTION! (Continued) The benefits of rotation are especially worthwhile with • Observe the traction device manufacturer’s instruc- aggressive tread designs such as those on all season type tions on the method of installation, operating tires.
Page 284: Tire Pressure Monitoring System (Tpms)
282 STARTING AND OPERATING The tire pressure will vary with temperature by about 1 psi (7 kPa) for every 12° F (6.5° C). This means that when the outside temperature decreases, the tire pressure will decrease. Tire pressure should always be set based on cold inflation tire pressure.
Page 285 STARTING AND OPERATING 283 The TPMS will continue to warn the driver of low tire For example, your vehicle may have a recommended pressure as long as the condition exists, and will not turn cold (parked for more than three hours) tire pressure of off until the tire pressure is at or above the recommended 30 psi (207 kPa).
Page 286 284 STARTING AND OPERATING CAUTION! CAUTION! (Continued) • After inspecting or adjusting the tire pressure, • The TPMS has been optimized for the original always reinstall the valve stem cap. This will equipment tires and wheels. TPMS pressures and prevent moisture and dirt from entering the valve warnings have been established for the tire size stem, which could damage the Tire Pressure Moni- equipped on your vehicle.
Page 287: Base System
STARTING AND OPERATING 285 Under-inflation also reduces fuel efficiency and tire The TPMS uses wireless technology with wheel rim tread life, and may affect the vehicle’s handling and mounted electronic sensors to monitor tire pressure lev- stopping ability. els. Sensors, mounted to each wheel as part of the valve stem, transmit tire pressure readings to the Receiver •...
Page 288 286 STARTING AND OPERATING xxx.x psi” text message will display when one or more of turn off when the fault condition no longer exists. A the four active road tire pressures are low. Should this system fault can occur with any of the following sce- occur, you should stop as soon as possible, check the narios: inflation pressure of each tire on your vehicle, and inflate...
Page 289: Enhanced System - If Equipped
STARTING AND OPERATING 287 2. If you install the compact spare tire in place of a road warning limit in any of the four active road tires. The tire that has a pressure below the low-pressure warn- vehicle may need to be driven for up to 20 minutes ing limit, upon the next ignition key cycle, a chime will above 15 mph (24 km/h) in order for the TPMS to sound and the Tire Pressure Monitoring Telltale Light...
Page 290 288 STARTING AND OPERATING The TPMS consists of the following components: • Receiver module • Four Tire Pressure Monitoring Sensors • Various Tire Pressure Monitoring System messages, which display in the Electronic Vehicle Information Center (EVIC) • Tire Pressure Monitoring Telltale Light Tire Pressure Monitoring Low Pressure Warnings The “Tire Pressure Monitoring Telltale Light”...
Page 291 STARTING AND OPERATING 289 to be driven for up to 20 minutes above 15 mph (24 km/h) in order for the TPMS to receive this informa- tion. TPMS Warning When a system fault is detected, the “Tire Pressure Monitoring Telltale Light” will flash on and off for 75 seconds and then remain on solid.
Page 292 290 STARTING AND OPERATING A system fault can occur due to any of the following: shown. This indicates that the pressure values are still being received from the TPM sensors but they may not be 1. Signal interference due to electronic devices or driving located in the correct vehicle position.
Page 293: General Information
STARTING AND OPERATING 291 Telltale Light” will flash on and off for 75 seconds and driven for up to 20 minutes above 15 mph (24 km/h) in then remain on solid. In addition, the EVIC will order for the TPMS to receive this information. display a “Service TPM System”...
Page 294: Fuel Requirements - 1.4L Engine
292 STARTING AND OPERATING FUEL REQUIREMENTS — 1.4L Engine FUEL REQUIREMENTS — 1.4L Turbo This engine is designed to meet all emis- This engine is designed to meet all emis- sion regulations and provide satisfactory sion regulations and provide satisfactory fuel economy and performance when us- fuel economy and performance when us- ing high-quality unleaded regular gaso-...
Page 295: Reformulated Gasoline
STARTING AND OPERATING 293 Reformulated Gasoline CAUTION! Many areas of the country require the use of cleaner Do not use gasoline containing Methanol or E-85 burning gasoline referred to as “Reformulated Gasoline.” Ethanol. Use of these blends may result in starting Reformulated gasoline contain oxygenates and are spe- and drivability problems and may damage critical cifically blended to reduce vehicle emissions and im-...
Page 296: Mmt In Gasoline
294 STARTING AND OPERATING If a Non-FFV vehicle is inadvertently fueled with E-85 MMT In Gasoline fuel, the engine will have some or all of these symptoms: Methylcyclopentadienyl Manganese Tricarbonyl (MMT) • Operate in a lean mode. is a manganese-containing metallic additive that is blended into some gasoline to increase octane.
Page 297: Materials Added To Fuel
STARTING AND OPERATING 295 Materials Added To Fuel CAUTION! (Continued) All gasoline sold in the United States is required to • An out-of-tune engine or certain fuel or ignition contain effective detergent additives. Use of additional malfunctions can cause the catalytic converter to detergents or other additives is not needed under normal overheat.
Page 298: Carbon Monoxide Warnings
296 STARTING AND OPERATING Carbon Monoxide Warnings WARNING! (Continued) • Guard against carbon monoxide with proper main- WARNING! tenance. Have the exhaust system inspected every Carbon monoxide (CO) in exhaust gases is deadly. time the vehicle is raised. Have any abnormal Follow the precautions below to prevent carbon conditions repaired promptly.
Page 299: Adding Fuel
STARTING AND OPERATING 297 ADDING FUEL CAUTION! Fuel Filler Cap (Gas Cap) • Damage to the fuel system or emission control The gas cap is located on the passenger side of the system could result from using an improper fuel vehicle.
Page 300: Loose Fuel Filler Cap Message
298 STARTING AND OPERATING Loose Fuel Filler Cap Message WARNING! (Continued) After fuel has been added, the vehicle diagnostic system • Never add fuel when the engine is running. It may can determine if the fuel filler cap is possibly loose, cause the MIL to turn on and could cause a fire.
Page 301: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING 299 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Ground Manual Transmission Automatic Transmission Flat Tow NONE Transmission in NEU- NOT ALLOWED TRAL Dolly Tow Front Rear NOT ALLOWED NOT ALLOWED On Trailer This vehicle may be towed on a flatbed or vehicle trailer...
Page 302 300 STARTING AND OPERATING CAUTION! CAUTION! DO NOT flat tow any vehicle equipped with an Towing this vehicle in violation of the above require- automatic transmission. Damage to the drivetrain ments can cause severe transmission damage. Dam- will result. If these vehicles require towing, make age from improper towing is not covered under the sure all drive wheels are OFF the ground.
Page 303: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS HAZARD WARNING FLASHERS ...303 JACKING AND TIRE CHANGING — IF EQUIPPED ......316 IF YOUR ENGINE OVERHEATS .
Page 304 302 WHAT TO DO IN EMERGENCIES Jump-Starting Procedure ....331 Automatic Transmission ....337 FREEING A STUCK VEHICLE .
Page 305: Hazard Warning Flashers
WHAT TO DO IN EMERGENCIES 303 HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located on the In any of the following situations, you can reduce the instrument panel below the radio. potential for overheating by taking the appropriate ac- tion.
Page 306: Tirefit Kit - If Equipped
304 WHAT TO DO IN EMERGENCIES CAUTION! WARNING! (Continued) to cool. Never try to open a cooling system pressure Driving with a hot cooling system could damage cap when the radiator or coolant bottle is hot. your vehicle. If the pointer rises to the H (red) mark, the instrument cluster will sound a chime.
Page 307: Tirefit Storage
WHAT TO DO IN EMERGENCIES 305 TIREFIT Storage TIREFIT Kit Components And Operation The TIREFIT kit is located under the front driver’s seat. TIREFIT Components 1 — Sealant Bottle 5 — Mode Select Knob TIREFIT Kit Location 2 — Deflation Button 6 —...
Page 308: Tirefit Usage Precautions
306 WHAT TO DO IN EMERGENCIES Using The Mode Select Knob And Hoses Using The Power Button Your TIREFIT kit is equipped with the following symbols Push and release the Power Button (4) once to to indicate the air or sealant mode. turn On the TIREFIT kit.
Page 309 WHAT TO DO IN EMERGENCIES 307 the vehicle or tire and wheel components. Once the sealant dries, it can easily be peeled off and properly discarded. • For optimum performance, make sure the valve stem on the wheel is free of debris before connecting the TIREFIT kit.
Page 310 308 WHAT TO DO IN EMERGENCIES WARNING! WARNING! (Continued) • Keep TIREFIT away from open flames or heat • Do not attempt to seal a tire on the side of the source. vehicle closest to traffic. Pull far enough off the •...
Page 311: Sealing A Tire With Tirefit
WHAT TO DO IN EMERGENCIES 309 kit when injecting the sealant into the deflated tire and WARNING! (Continued) running the air pump. Move the vehicle as necessary • TIREFIT Sealant solution contains latex. In case of to place the valve stem in this position before proceed- an allergic reaction or rash, consult a physician ing.
Page 312 310 WHAT TO DO IN EMERGENCIES 4. Remove the cap from the valve stem and then screw NOTE: Sealant may leak out through the puncture in the the fitting at the end of the Sealant Hose (6) onto the tire. valve stem.
Page 313 WHAT TO DO IN EMERGENCIES 311 NOTE: If the Mode Select Knob (5) is on Air Mode and latch pillar (recommended pressure). Check the tire the pump is operating, air will dispense from the Air pressure by looking at the Pressure Gauge (3). Pump Hose (7) only, not the Sealant Hose (6).
Page 314 312 WHAT TO DO IN EMERGENCIES 3. Immediately disconnect the Sealant Hose (6) from the (D) Drive Vehicle: valve stem, reinstall the cap on the fitting at the end of Immediately after injecting sealant and inflating the tire, the hose, and place the TIREFIT kit in the vehicle drive the vehicle 5 miles (8 km) or 10 minutes to ensure storage location.
Page 315 WHAT TO DO IN EMERGENCIES 313 1. Push in the Mode Select Knob (5) and turn to the Air If the tire pressure is 19 psi (1.3 Bar) or higher: Mode position. 1. Press the Power Button (4) to turn on TIREFIT and 2.
Page 316: Wheel And Tire Torque Specifications
314 WHAT TO DO IN EMERGENCIES 5. Replace the Sealant Bottle (1) and Sealant Hose (6) 5. Position the new Sealant Bottle (1) in the housing so assembly at your authorized dealer as soon as pos- that the Sealant Hose (6) aligns with the hose slot in sible.
Page 317: Torque Specifications
WHAT TO DO IN EMERGENCIES 315 Torque Specifications Lug Nut/Bolt Torque **Lug Nut/ Lug Nut/ Bolt Size Bolt Socket Size 66 Ft-Lbs (90 N·m) M12 x 1.25 17 mm Steel Wheels Only 75 Ft-Lbs (100 N·m) Aluminum Wheels Only **Use only Chrysler recommended lug nuts/bolts and clean or remove any dirt or oil before tightening.
Page 318: Jacking And Tire Changing - If Equipped
316 WHAT TO DO IN EMERGENCIES WARNING! To avoid the risk of forcing the vehicle off the jack, do not tighten the lug nuts fully until the vehicle has been lowered. Failure to follow this warning may result in personal injury. JACKING AND TIRE CHANGING —...
Page 319: Jack Location
WHAT TO DO IN EMERGENCIES 317 Jack Location WARNING! (Continued) The jack and jack wrench tool are stowed in a bag under • Being under a jacked-up vehicle is dangerous. The the front driver’s seat. vehicle could slip off the jack and fall on you. You could be crushed.
Page 320: Spare Tire Removal
318 WHAT TO DO IN EMERGENCIES Spare Tire Removal 2. Fit the wrench tool over the drive nut. Use the wrench to rotate the nut counterclockwise until the spare is on The spare tire is stowed to the underbody below the the ground with enough slack in the cable to allow you cargo area.
Page 321 WHAT TO DO IN EMERGENCIES 319 3. Pull the spare tire out from under the vehicle. CAUTION! The winch mechanism is designed for use with the jack wrench tool only. Use of an air wrench or other power tools is not recommended and they can dam- age the winch.
Page 322: Preparations For Jacking
320 WHAT TO DO IN EMERGENCIES 4. Tilt the retainer at the end of the cable and pull it Preparations For Jacking through the center of the wheel. 1. Park the vehicle on a firm level surface, avoiding ice or slippery areas.
Page 323: Jacking Instructions
WHAT TO DO IN EMERGENCIES 321 6. Block both the front and rear of the wheel diagonally WARNING! (Continued) opposite of the jacking position. For • Turn on the Hazard Warning flashers. example, if changing the right front • Block the wheel diagonally opposite the wheel to tire, block the left rear wheel.
Page 324 322 WHAT TO DO IN EMERGENCIES NOTE: Refer to the “Compact Spare Tire” section of the WARNING! (Continued) “Tires-General Information” under “Starting And Oper- • If working on or near a roadway, be extremely ating” for information about the spare tire, it’s use, and careful of motor traffic.
Page 325 WHAT TO DO IN EMERGENCIES 323 2. Remove center cap. 3. Loosen, but do not remove, the wheel bolts by turning them to the left one turn while the wheel is still on the ground. NOTE: There are front and rear jacking locations on each side of the body (as indicated by the triangular lift point symbol on the sill molding).
Page 326 324 WHAT TO DO IN EMERGENCIES Rear Jacking Location Jack Location Do not raise the vehicle until you are sure the jack is WARNING! securely engaged. 4. Turn the jack screw to the left until the jack can be Raising the vehicle higher than necessary can make placed under the jacking location.
Page 327 WHAT TO DO IN EMERGENCIES 325 5. Using the swivel wrench, raise the vehicle by turning CAUTION! the jack screw to the right. Raise the vehicle only until the tire just clears the surface and enough clearance is Be sure to mount the spare tire with the valve stem obtained to install the spare tire.
Page 328: Road Tire Installation
326 WHAT TO DO IN EMERGENCIES 9. Finish tightening the wheel bolts. Push down on the 11. Place the deflated (flat) tire in the cargo area. Have wrench while at the end of the handle for increased the tire repaired or replaced as soon as possible. leverage.
Page 329 WHAT TO DO IN EMERGENCIES 327 3. Install the four wheel bolts with the cone shaped end of the nut toward the wheel. Lightly tighten the wheel bolts. WARNING! To avoid the risk of forcing the vehicle off the jack, do not tighten the wheel bolts fully until the vehicle has been lowered.
Page 330: Spare Tire Stowage
328 WHAT TO DO IN EMERGENCIES 6. After 25 miles (40 km) check the wheel bolt torque 4. Finish tightening the wheel bolts. Push down on the wrench while at the end of the handle for increased with a torque wrench to ensure that all wheel bolts are leverage.
Page 331: Jump-Starting Procedure
WHAT TO DO IN EMERGENCIES 329 JUMP-STARTING PROCEDURE WARNING! If your vehicle has a discharged battery, it can be jump- Do not attempt jump-starting if the battery is frozen. started using a set of jumper cables and a battery in It could rupture or explode and cause personal injury.
Page 332: Preparations For Jump-Start
330 WHAT TO DO IN EMERGENCIES Preparations For Jump-Start WARNING! The battery in your vehicle is located between the left • Take care to avoid the radiator cooling fan when- front headlight assembly and the left front wheel splash ever the hood is raised. It can start anytime the shield.
Page 333: Jump-Starting Procedure
WHAT TO DO IN EMERGENCIES 331 3. Remove the protective cover over the positive (+) CAUTION! battery post. To remove the cover, press the locking tab and pull upward on the cover. Failure to follow these procedures could result in damage to the charging system of the booster vehicle 4.
Page 334 332 WHAT TO DO IN EMERGENCIES 6. Once the engine is started, remove the jumper cables WARNING! in the reverse sequence: Do not connect the jumper cable to the negative (-) Disconnecting The Jumper Cables post of the discharged battery. The resulting electri- 1.
Page 335: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES 333 pressing the accelerator. Use the least amount of accel- CAUTION! erator pedal pressure that will maintain the rocking motion, without spinning the wheels, or racing the Accessories plugged into the vehicle power outlets engine. draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.).
Page 336: Shift Lever Override
334 WHAT TO DO IN EMERGENCIES NOTE: Press the ESC Off switch, to place the Electronic WARNING! Stability Control (ESC) system in Partial Off mode, before rocking the vehicle. Refer to “Electronic Brake Fast spinning tires can be dangerous. Forces gener- Control”...
Page 337 WHAT TO DO IN EMERGENCIES 335 3. Remove the shift lever override access cover (located 4. Press and maintain firm pressure on the brake pedal. on the right side of the shift lever housing) by prying 5. Insert a small screwdriver or similar tool into the at the bottom edge of the cover.
Page 338: Towing A Disabled Vehicle
336 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial wrecker service. Towing Condition Wheels OFF The AUTOMATIC TRANS- MANUAL TRANSMIS- Ground MISSION SION Flat Tow NONE NOT ALLOWED If transmission is oper- able: •...
Page 339: Automatic Transmission
WHAT TO DO IN EMERGENCIES 337 Proper towing or lifting equipment is required to prevent CAUTION! (Continued) damage to your vehicle. Use only tow bars and other • Towing this vehicle in violation of the above re- equipment designed for this purpose, following equip- quirements can cause severe transmission damage.
Page 340: Manual Transmission
338 WHAT TO DO IN EMERGENCIES CAUTION! CAUTION! • DO NOT flat tow any vehicle equipped with an Towing this vehicle in violation of the above require- automatic transmission. Damage to the drivetrain ments can cause severe engine and/or transmission will result.
Page 341 WHAT TO DO IN EMERGENCIES 339 • Turn on the interior lights, which remain on as long as In order to move your vehicle to the side of the road you the battery has power or until the ignition key is must follow the system reset procedure.
Page 342 340 WHAT TO DO IN EMERGENCIES If a reset procedure step is not completed within 45 5. Turn Right Turn Signal Right Turn Light is ON seconds, then the turn signal lights will turn off and the Switch ON. SOLID. Left Turn Light reset procedure must be performed again in order to be BLINKS.
Page 343 MAINTAINING YOUR VEHICLE CONTENTS ENGINE COMPARTMENT — 1.4L ..343 Engine Air Cleaner Filter ....352 ENGINE COMPARTMENT — 1.4L TURBO ..344 Maintenance-Free Battery .
Page 344 342 MAINTAINING YOUR VEHICLE Automatic Transmission — If Equipped ..373 Front Turn Signal, Parking And Daytime Running Lamps ......391 Appearance Care And Protection From Corrosion .
Page 345: Engine Compartment - 1.4L
MAINTAINING YOUR VEHICLE 343 ENGINE COMPARTMENT — 1.4L 1 — Engine Coolant Reservoir 5 — Battery 2 — Engine Oil Dipstick 6 — Air Cleaner Filter 3 — Brake Fluid Reservoir 7 — Engine Oil Fill 4 — Front Distribution Unit (Fuses) 8 —...
Page 346: Engine Compartment - 1.4L Turbo
344 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 1.4L TURBO 1 — Engine Coolant Reservoir 5 — Battery 2 — Engine Oil Dipstick 6 — Engine Oil Fill 3 — Brake Fluid Reservoir 7 — Washer Fluid Reservoir 4 — Front Distribution Unit (Fuses)
Page 347: Onboard Diagnostic System - Obd Ii
MAINTAINING YOUR VEHICLE 345 ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors further damage to the emission control system. It the performance of the emissions, engine, and automatic could also affect fuel economy and driveability.
Page 348 346 MAINTAINING YOUR VEHICLE Indicator Light (MIL)” is functioning and is not on when 2. As soon as you cycle the ignition switch to the ON the engine is running, and that the OBD II system is position, you will see the MIL symbol come on as part ready for testing.
Page 349: Replacement Parts
MAINTAINING YOUR VEHICLE 347 you may need to do nothing more than drive your DEALER SERVICE vehicle as you normally would in order for your OBD II Your authorized dealer has the qualified service person- system to update. A recheck with the above test routine nel, special tools, and equipment to perform all service may then indicate that the system is now ready.
Page 350: Maintenance Procedures
348 MAINTAINING YOUR VEHICLE MAINTENANCE PROCEDURES CAUTION! (Continued) The pages that follow contain the required maintenance • Your vehicle has been built with improved fluids services determined by the engineers who designed your that protect the performance and durability of your vehicle.
Page 351 MAINTAINING YOUR VEHICLE 349 fully warmed engine is shut off. Do not check oil level CAUTION! (Continued) before starting the engine after it has sat overnight. temperature. This loss of oil pressure and increased Checking engine oil level when the engine is cold will oil temperature could damage your engine.
Page 352 350 MAINTAINING YOUR VEHICLE Engine Oil Selection — 1.4L Turbo Engine CAUTION! For best performance and maximum protection under all Do not use chemical flushes in your engine oil as the types of operating conditions, the manufacturer only chemicals can damage your engine. Such damage is recommends engine oils that are API Certified and meet not covered by the New Vehicle Limited Warranty.
Page 353 MAINTAINING YOUR VEHICLE 351 The engine oil filler cap also shows the recommended Synthetic Engine Oils engine oil viscosity for your engine. For information on You may use synthetic engine oils provided the recom- engine oil filler cap location, refer to “Engine Compart- mended oil quality requirements are met, and the recom- ment”...
Page 354: Engine Oil Filter
352 MAINTAINING YOUR VEHICLE station or governmental agency for advice on how and WARNING! where used oil and oil filters can be safely discarded in your area. The air induction system (air cleaner, hoses, etc.) can provide a measure of protection in the case of engine Engine Oil Filter backfire.
Page 355: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 353 Maintenance-Free Battery WARNING! (Continued) Your vehicle is equipped with a maintenance-free battery. • Battery gas is flammable and explosive. Keep You will never have to add water, nor is periodic main- flame or sparks away from the battery. Do not use tenance required.
Page 356: Air Conditioner Maintenance
354 MAINTAINING YOUR VEHICLE the condenser fins and a performance test. Drive belt tension CAUTION! should also be checked at this time. • It is essential when replacing the cables on the WARNING! battery that the positive cable is attached to the positive post and the negative cable is attached to •...
Page 357 MAINTAINING YOUR VEHICLE 355 Refrigerant Recovery And Recycling HFO 1234yf CAUTION! — If Equipped Do not use chemical flushes in your air conditioning HFO 1234yf Air Conditioning Refrigerant is a hydro- system as the chemicals can damage your air condi- fluorocarbon (HFC) that is endorsed by the Environmen- tioning components.
Page 358 356 MAINTAINING YOUR VEHICLE The A/C air filter is located in the fresh air inlet on the 2. Pull the console closeout cover rearward to disengage lower right of center console. Perform the following the front retaining tab and remove the cover. procedure to replace the filter: 1.
Page 359 MAINTAINING YOUR VEHICLE 357 Air Filter Cover Screw Locations A/C Air Filter 4. Remove the A/C air filter by pulling it straight out of 5. Install the A/C air filter with the air filter position the housing. Take note of the air filter position indica- indicators pointing in the same direction as removal.
Page 360: Body Lubrication
358 MAINTAINING YOUR VEHICLE should be wiped clean to remove dust and grit; after CAUTION! lubricating excess oil and grease should be removed. Particular attention should also be given to hood latching The A/C air filter is identified with an arrow to components to ensure proper function.
Page 361 MAINTAINING YOUR VEHICLE 359 Operation of the wipers on dry glass for long periods Rear Wiper Blade Removal/Installation may cause deterioration of the wiper blades. Always use 1. Lift the pivot cap on the rear wiper arm upward, this washer fluid when using the wipers to remove salt or dirt will allow the rear wiper blade to be raised off of the from a dry windshield or rear window.
Page 362 360 MAINTAINING YOUR VEHICLE NOTE: The rear wiper arm cannot be raised fully up- ward unless the pivot cap is raised first. 2. Lift the rear wiper arm upward to raise the wiper blade off of the liftgate glass. 3. Grab the bottom of the wiper blade and rotate it forward to unsnap the blade pivot pin from the wiper blade holder.
Page 363: Adding Washer Fluid
MAINTAINING YOUR VEHICLE 361 4. Install the wiper blade pivot pin into the wiper blade WARNING! holder at the end of the wiper arm, and firmly press the wiper blade until it snaps into place. Commercially available windshield washer solvents are flammable.
Page 364 362 MAINTAINING YOUR VEHICLE exhaust system inspected each time the vehicle is raised CAUTION! for lubrication or oil change. Replace as required. • The catalytic converter requires the use of un- WARNING! leaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emissions control •...
Page 365 MAINTAINING YOUR VEHICLE 363 Under normal operating conditions, the catalytic con- To minimize the possibility of catalytic converter dam- verter will not require maintenance. However, it is im- age: portant to keep the engine properly tuned to assure • Do not shut off the engine or interrupt the ignition, proper catalyst operation and prevent possible catalyst when the transmission is in gear and the vehicle is in damage.
Page 366: Cooling System
364 MAINTAINING YOUR VEHICLE Cooling System Coolant Checks Check engine coolant (antifreeze) protection every 12 WARNING! months (before the onset of freezing weather, where applicable). If the engine coolant (antifreeze) is dirty or • When working near the radiator cooling fan, dis- rusty in appearance, the system should be drained, connect the fan motor lead or turn the ignition flushed and refilled with fresh engine coolant (anti-...
Page 367 MAINTAINING YOUR VEHICLE 365 Cooling System — Drain, Flush And Refill CAUTION! If the engine coolant (antifreeze) is dirty or contains • Mixing of engine coolant (antifreeze) other than visible sediment, have an authorized dealer clean and specified Organic Additive Technology (OAT) en- flush with OAT coolant (antifreeze) (conforming to MS- gine coolant (antifreeze), may result in engine 12106).
Page 368 366 MAINTAINING YOUR VEHICLE you use the same engine coolant (OAT coolant conform- CAUTION! (Continued) ing to MS-12106) throughout the life of your vehicle. • Do not use water alone or alcohol-based engine Please review these recommendations for using Organic coolant (antifreeze) products.
Page 369 MAINTAINING YOUR VEHICLE 367 (antifreeze) solution. The use of lower quality water have a authorized dealer drain, flush, and refill with will reduce the amount of corrosion protection in the OAT coolant (conforming to MS-12106) as soon as engine cooling system. possible.
Page 370 368 MAINTAINING YOUR VEHICLE rules for your community. To prevent ingestion by ani- WARNING! mals or children, do not store ethylene glycol-based • The warning words “DO NOT OPEN HOT” on the engine coolant in open containers or allow it to remain in puddles on the ground.
Page 371 MAINTAINING YOUR VEHICLE 369 When additional engine coolant (antifreeze) is needed to needs to be added, the contents of the coolant expansion maintain the proper level, it should be added to the bottle must also be protected against freezing. coolant bottle. Do not overfill. •...
Page 372: Brake System
370 MAINTAINING YOUR VEHICLE • Do not change the thermostat for Summer or Winter WARNING! (Continued) operation. If replacement is ever necessary, install high brake temperatures, excessive lining wear, and ONLY the correct type thermostat. Other designs may possible brake damage. Riding the brakes may also result in unsatisfactory engine coolant (antifreeze) reduce braking capacity in an emergency.
Page 373 MAINTAINING YOUR VEHICLE 371 NOTE: If your vehicle is equipped with a manual trans- WARNING! mission, the brake fluid reservoir supplies fluid to both • Use only manufacturer’s recommended brake the brake system and the clutch release system. The two systems are separated in the reservoir, and a leak in one fluid.
Page 374 372 MAINTAINING YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) • To avoid contamination from foreign matter or • Do not allow petroleum-based fluid to contaminate moisture, use only new brake fluid or fluid that has the brake fluid. Brake seal components could be been in a tightly closed container.
Page 375: Manual Transmission - If Equipped
MAINTAINING YOUR VEHICLE 373 Manual Transmission — If Equipped NOTE: If contaminated with water, the fluid should be changed immediately. Lubricant Selection Automatic Transmission — If Equipped Use only the manufacturers recommended transmission fluid. Refer to “Fluids, Lubricants, and Genuine Parts” in Selection Of Lubricant “Maintaining Your Vehicle”...
Page 376 374 MAINTAINING YOUR VEHICLE CAUTION! CAUTION! Using a transmission fluid other than the manufac- Do not use chemical flushes in your transmission as turer’s recommended fluid may cause deterioration the chemicals can damage your transmission compo- in transmission shift quality and/or torque converter nents.
Page 377: Appearance Care And Protection From Corrosion
MAINTAINING YOUR VEHICLE 375 passable in snow and ice and those that are sprayed on CAUTION! trees and road surfaces during other seasons are highly corrosive to the metal in your vehicle. Outside parking, If a transmission fluid leak occurs, visit your autho- which exposes your vehicle to airborne contaminants, rized dealer immediately.
Page 378 376 MAINTAINING YOUR VEHICLE • Insects, tree sap and tar. CAUTION! • Salt in the air near seacoast localities. • Do not use abrasive or strong cleaning materials • Atmospheric fallout/industrial pollutants. such as steel wool or scouring powder that will scratch metal and painted surfaces.
Page 379 MAINTAINING YOUR VEHICLE 377 • If you detect any stone chips or scratches in the paint, Wheel And Wheel Trim Care touch them up immediately. The cost of such repairs is • All wheels and wheel trim, especially aluminum and considered the responsibility of the owner.
Page 380 378 MAINTAINING YOUR VEHICLE • For tough stains, apply MOPAR® Total Clean, or a CAUTION! mild soap solution to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue. Do not use scouring pads, steel wool, a bristle brush, or metal polishes.
Page 381 MAINTAINING YOUR VEHICLE 379 Your leather upholstery can be best preserved by regular CAUTION! cleaning with a damp soft cloth. Small particles of dirt can act as an abrasive and damage the leather upholstery Do not use Alcohol and Alcohol-based and/or Keton and should be removed promptly with a damp cloth.
Page 382 380 MAINTAINING YOUR VEHICLE Glass Surfaces Instrument Panel Bezels All glass surfaces should be cleaned on a regular basis CAUTION! with MOPAR® Glass Cleaner, or any commercial household-type glass cleaner. Never use an abrasive type When installing hanging air fresheners in your ve- cleaner.
Page 383: Convertible Top Care - If Equipped
MAINTAINING YOUR VEHICLE 381 Seat Belt Maintenance WARNING! (Continued) Do not bleach, dye or clean the belts with chemical assemblies must be replaced after a collision if they solvents or abrasive cleaners. This will weaken the fabric. have been damaged (i.e., bent retractor, torn web- Sun damage can also weaken the fabric.
Page 384 382 MAINTAINING YOUR VEHICLE Washing CAUTION! (Continued) Hand washing is highly recommended. Automatic car • Remove any standing water from the top and dry washing equipment can damage the top material. If you the surface before opening it. Operating the top, must use an automatic car wash, soft cloth systems are opening a door or lowering a window while the top preferred.
Page 385: Fuses
MAINTAINING YOUR VEHICLE 383 FUSES CAUTION! WARNING! Never use an abrasive type cleaner or bleaches. Cleaners should not contain silicones, organic sol- • When replacing a blown fuse, always use an ap- vents, petroleum distillates, or plasticizers. Always propriate replacement fuse with the same amp wait until the top is thoroughly dry before lowering rating as the original fuse.
Page 386: Interior Fuses
384 MAINTAINING YOUR VEHICLE Interior Fuses WARNING! (Continued) The interior fuse panel is part of the Body Control • If a general protection fuse for safety systems (air Module (BCM) and is located on the driver’s side under bag system, braking system), power unit systems the instrument panel.
Page 387 MAINTAINING YOUR VEHICLE 385 Cavity Vehicle Fuse Number Mini Fuse Description 7.5 Amp Brown Right Low Beam 5 Amp Tan Front and Rear Ceiling Lights Trunk and Door Courtesy Lights 5 Amp Tan Instrument Panel Node 20 Amp Yellow Central Door Locking 10 Amp Red Diagnostic Socket, Car Radio, Climate Control System...
Page 388: Underhood Fuses
386 MAINTAINING YOUR VEHICLE Cavity Vehicle Fuse Number Mini Fuse Description 5 Amp Tan Ignition, Climate Control 20 Amp Yellow Driver Power Window Underhood Fuses The Front Distribution Unit is located on the right side of the engine compartment, next to the battery. To access the fuses, press the release tabs and remove the cover.
Page 389 MAINTAINING YOUR VEHICLE 387 Cavity Maxi Fuse Mini Fuse Description 60 Amp Blue Body Controller 20 Amp Yellow Audio Amplifier 20 Amp Yellow Ignition Switch 40 Amp Orange Anti-Lock Brake Pump 70 Amp Tan Electric Power Steering 20 Amp Yellow Radiator Fan - Single Speed 30 Amp Green Radiator Fan - Low Speed...
Page 390 388 MAINTAINING YOUR VEHICLE Cavity Maxi Fuse Mini Fuse Description 7.5 Amp Brown Transmission 25 Amp White Powertrain (Multiair – If Equipped) 15 Amp Blue Powertrain 15 Amp Blue Powertrain 5 Amp Tan Powertrain (Multiair – If Equipped) 7.5 Amp Brown Air Conditioning 15 Amp Blue Heated Seats –...
Page 391: Vehicle Storage
MAINTAINING YOUR VEHICLE 389 Cavity Maxi Fuse Mini Fuse Description 30 Amp Green (ATO) Rear Defroster 5 Amp Tan Rear Defroster 5 Amp Tan Heated Mirrors – If Equipped • Anytime you store your vehicle, or keep it out of VEHICLE STORAGE service (e.g., vacation) for two weeks or more, run the If you are leaving your vehicle dormant for more than 21...
Page 392: Replacement Bulbs
390 MAINTAINING YOUR VEHICLE REPLACEMENT BULBS Bulb Number Side Direction Lamps WY5W Interior Bulbs Rear Turn Signal Lamps PY21W Bulb Number Rear Side Marker Lamps Overhead Lamp Rear Tail and Stop P21/5W Courtesy Lamp Lamps Rear Backup Lamps W16W Exterior Bulbs Center High Mounted Bulb Number Stop Lamp...
Page 393: Bulb Replacement
MAINTAINING YOUR VEHICLE 391 BULB REPLACEMENT Front Turn Signal, Parking And Daytime Running Lamps NOTE: Lens fogging can occur under certain atmo- spheric conditions. This will usually clear as atmospheric 1. Turn the steering wheel completely to the left or right. conditions change to allow the condensation to change 2.
Page 394: Front Fog Lamps
392 MAINTAINING YOUR VEHICLE 3. Remove the plastic cap from the back of the lamp 3. Pull the bulb from the socket and insert the replace- housing. ment bulb. 4. Rotate bulb/socket counter-clockwise. 4. Install the bulb and socket assembly into the housing, and rotate the socket clockwise to lock it in place.
Page 395: Center High Mounted Stop Lamp (Chmsl)
MAINTAINING YOUR VEHICLE 393 6. Replace lamps as required and reinstall lamp. Center High Mounted Stop Lamp (CHMSL) 1. Remove the two guard caps and the two fastening screws. 2. Remove the center high mounted stop lamp assembly. 3. Disconnect the electric connector. 4.
Page 396: Fluid Capacities
394 MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) 10.5 Gallons 40 Liters Engine Oil with Filter 1.4L/1.4L Turbo Engine 4 Quarts 3.8 Liters Cooling System 1.4L/1.4L Turbo Engine (MOPAR® 4.6 Quarts 4.4 Liters Antifreeze/Engine Coolant 10 Year/150,000 Mile Formula) — with Manual Transmission 1.4L/1.4L Turbo Engine (MOPAR®...
Page 397: Fluids, Lubricants And Genuine Parts
MAINTAINING YOUR VEHICLE 395 FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant - 1.4L/1.4L Turbo Engine We recommend you use MOPAR® Antifreeze/Coolant 10 Year/ 150,000 Mile Formula OAT (Organic Additive Technology) meet- ing the requirements of Chrysler Material Standard MS-12106. Engine Oil - 1.4L Engine We recommend you use API Certified SAE 5W-30 Engine Oil, meeting the requirements of Chrysler Material Standard MS-...
Page 398: Chassis
396 MAINTAINING YOUR VEHICLE Chassis Component Fluid, Lubricant, or Genuine Part Manual Transmission – If Equipped We recommend you use MOPAR® C635 DDCT/MTX Transmission Fluid Automatic Transmission – If Equipped Use only MOPAR® AW-1 Automatic Transmission Fluid or equivalent. Failure to use the correct fluid may affect the function or performance of your transmission.
Page 399: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS MAINTENANCE SCHEDULE ... . .398 Maintenance Chart ....400...
Page 400 398 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a Your vehicle is equipped with an automatic oil change scheduled oil change is performed by someone other indicator system.
Page 401 MAINTENANCE SCHEDULES 399 Once A Month Or Before A Long Trip: At Every Oil Change Interval As Indicated By Oil • Check engine oil level. Change Indicator System: • Change oil and filter. • Check windshield washer fluid level. • Rotate the tires. Rotate at the first sign of irregu- •...
Page 402 400 MAINTENANCE SCHEDULES Maintenance Chart Refer to the Maintenance Schedules on the following pages for the required maintenance intervals. Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, tie rod ends and boot seals, and re- place if necessary.
Page 403 MAINTENANCE SCHEDULES 401 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Maintenance Replace engine air filter. Replace cabin air filter. Clean and lube sun roof tracks. Replace spark plugs (1.4L En- gine). ** Replace spark plugs (1.4L Turbo Engine).
Page 404 402 MAINTENANCE SCHEDULES Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Inspect and replace PCV valve if necessary. Replace the timing belt. ** The spark plug change interval is mileage based only, yearly intervals do not apply.
Page 405 MAINTENANCE SCHEDULES 403 WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 407: If You Need Consumer Assistance
IF YOU NEED ASSISTANCE ....406 PUBLICATION ORDER FORMS ... .410 FIAT CUSTOMER CENTER ....407 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES .
Page 408: Suggestions For Obtaining Service For Your Vehicle
406 IF YOU NEED CONSUMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with Prepare For The Appointment the service advisor and list the items in order of priority.
Page 409: Fiat Customer Center
• If for some reason you are still not satisfied, talk to the 1–800–423–6343 general manager or owner of the authorized dealer. FIAT CANADA CUSTOMER CENTER They want to know if you need assistance. P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1–800–...
Page 410: Service Contract
408 IF YOU NEED CONSUMER ASSISTANCE (TTY) in the United States, can communicate with the Hotline at 1-800-521-9922 (Canadian residents, call (800) manufacturer by dialing 1–800–380–CHRY. 465–2001 English / (800) 387–9983 French). Canadian residents with hearing difficulties that require The manufacturer will not stand behind any service assistance can use the special needs relay service offered contract that is not the manufacturer’s service contract.
Page 411: Warranty Information
However, NHTSA cannot become involved in individual problems between you, your authorized See the Warranty Information Booklet, located on the dealer, and the manufacturer. DVD, for the terms and provisions of FIAT Group Automobiles warranties applicable to this vehicle and market.
Page 412: In Canada
Canada, Motor Vehicle Defect Investigations and diagnosing/troubleshooting, problem solving, maintain- Recalls at 1-800-333-0510 or go to http://www.tc.gc.ca/ ing, servicing, and repairing FIAT Group Automobiles roadsafety/ vehicles. A complete working knowledge of the vehicle, system, and/or components is written in straightforward...
Page 413: Department Of Transportation Uniform Tire Quality Grades
The following tire grading categories were established by assistance of service and engineering specialists to ac- the National Highway Traffic Safety Administration. The quaint you with specific FIAT Group Automobiles ve- specific grade rating assigned by the tire’s manufacturer hicles. Included are starting, operating, emergency and...
Page 414: Treadwear
412 IF YOU NEED CONSUMER ASSISTANCE Treadwear Traction Grades The Treadwear grade is a comparative rating, based on The Traction grades, from highest to lowest, are AA, A, B, the wear rate of the tire when tested under controlled and C. These grades represent the tire’s ability to stop on conditions on a specified government test course.
Page 415: Temperature Grades
IF YOU NEED CONSUMER ASSISTANCE 413 Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, The temperature grade for this tire is established for representing the tire’s resistance to the generation of heat a tire that is properly inflated and not overloaded. and its ability to dissipate heat, when tested under Excessive speed, under-inflation, or excessive load- controlled conditions on a specified indoor laboratory...
Page 417 INDEX...
Page 418 416 INDEX Adding Engine Coolant (Antifreeze) ... .366 Antifreeze (Engine Coolant) ....365 Adding Fuel ......297 Capacities .
Page 419 INDEX 417 Battery ....... . .353 Capacities, Antifreeze (Engine Coolant) ..394 Jump Starting .
Page 420 418 INDEX Child Restraints Convertible Top Maintenance ....381 Child Seat Installation .....73 Coolant (Antifreeze) .
Page 421 INDEX 419 Defroster, Windshield ..... . .80 Electronic Vehicle Information Center (EVIC) ..158 Diagnostic System, Onboard ....345 Exit Trip .
Page 422 420 INDEX Fails to Start ......225 Filters Flooded, Starting ..... . .225 Air Cleaner .
Page 423 INDEX 421 Additives ......295 Gasoline, Reformulated .....293 Capacity .
Page 424 422 INDEX Switch .......111 Interior Lighting ......113 Heated Mirrors.
Page 425 INDEX 423 Leaks, Fluid ......82 Passing ......111 Life of Tires .
Page 426 424 INDEX Maintenance Free Battery....353 Multi-Function Control Lever ....110 Maintenance, General .
Page 427 INDEX 425 Materials Added to ..... .351 Power Recommendation ..... . .349 Door Locks .
Page 428 426 INDEX Recorder, Event Data ..... . .54 Safety Defects, Reporting ....409 Recreational Towing .
Page 429 INDEX 427 Heated .......104 Sport Mode ......246 SENTRY KEY®...
Page 430 428 INDEX Tachometer......157 Pressure Monitor System (TPMS) ... .282 Temperature Control, Automatic (ATC) .
Page 431 INDEX 429 Trailer Towing ......298 Vehicle Identification Number (VIN) ... . .7 Transaxle Vehicle Loading .
Page 432 430 INDEX Windows ....... .23 Power ....... .23 Windshield Defroster .
Page 433 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’ s The antenna cable should be as short as practical and routed electronic system to provide immunity to radio frequency signals. away from the vehicle wiring when possible. Use only fully Mobile two-way radios and telephone equipment must be shielded coaxial cable.
Page 434 Chrysler Group LLC 14FF500-126-AC Third Edition Printed in U.S.A.

This manual is also suitable for:

2014 500c

Fiat 2014 500 Owner's Manual

Introduction

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Maintaining Your Vehicle

Quick Links

Chapters

Related Manuals for Fiat 2014 Fiat 500

Summary of Contents for Fiat 2014 Fiat 500
