1. Feature

Design Flexibility
Super high airflow
New DC fan motor and large length & diameter fan design,
provide the 2880 m3/h (800l/s) above air flow with
250m3/h/kW (70L/s/kW) ,which is 44% more than medium
ESP duct unit.
210Pa ESP setting
210pa ESP give the design flexibility totally , it can meet
difficulty duct requirement.
Easy Installation
Narrow width
Only 490mm depth can meet the Australia compact roof
trusses, easy for installer lifting the unit.
Three side open the panel
There are three side panel which can be opened for easy
maintenance
Top panel and bottom panel can be opened to maintain the
fan and motor;
Electrical panel can be opened to maintain the electrical parts;
Side panel can be opened to maintain the pipe sensor;
Medium ESP duct
Capacity
airflow(m
10.0kW
2000
12.5kW
2250
14.0kW
2500
Haier
210pa (20M air duct)
Normal
100pa (9M air duct)
Line A
Top panel
bottom panel
60
Smart Power
High ESP duct
Promotion
/h)
airflow(m
/h)
3
3
2880
44%
3250
44%
3600
44%
Australia house roof trusses
600mm
Line A
Line A
595mm
490mm
It is easy for the duct unit to go
through the gap between line A;
Put the duct unit on the house beam;
Side panel
Side panel
Line A
