EVAL-AD5696RSDZ User Guide

EVALUATION BOARD SOFTWARE QUICK START PROCEDURES

INSTALLING THE SOFTWARE

The EVAL-AD5696RSDZ evaluation board uses the
evaluation software, a desktop software application that allows
the evaluation and control of multiple evaluation systems.
The ACE installer installs the necessary SDP drivers and the
Microsoft® .NET Framework 4 by default. The
available for download from the
page, and must be installed before connecting the
the USB port of the PC, to ensure that the
recognized when it connects to the PC. For full instructions on
how to install and use this software, see the
on the Analog Devices website.
After the installation is finished, the
evaluation board plug in appears when the
opened.
ACE
ACE software is
EVAL-AD5696RSDZ product
SDP board to
SDP board is
ACE software page
EVAL-AD5696RSDZ
ACE software is
Figure 2. Board View of the
Figure 3. Chip Block Diagram of the

INITIAL SETUP

To set up the evaluation board, take the following steps:
1. Connect the evaluation board to the
connect the USB cable between the
2. Run the ACE
plug ins appear in the attached hardware pane of the Start
tab.
3. Double click the board plug in to open the board view
shown in Figure 2.
4. Double click the AD5696R chip to access the chip block
diagram. This view provides a basic representation of
functionality of the board. The main function blocks of the
board are labeled in Figure 3.
EVAL-AD5696RSDZ
AD5696R
Rev. C | Page 3 of 13
SDP board, and then
SDP board and the PC.
application. The EVAL-AD5696RSDZ
UG-726
board
