UG-726

ORDERING INFORMATION

BILL OF MATERIALS

Table 6.
Qty Reference Designator
1 U1
1 U2
1 U3
1 U4
1 U5
6 C1, C2, C5, C6, C18, C25
3 C4, C17, C19
3 C3, C20, C24
1 C8
1 C21
1 C22
1 C23
1 E1
1 E2
2 EXTREF, EXTSUP
1 P1
2 REF, PWRSEL
1 R12
1 R13
4 R5, R9, R15, R17
2 R2, R3
1 SDP
2 AGND, DGND
4 SCLK/A0, SDIN/A1,
SDO/SDA, SYNCB/SCL
4 VOUTA to VOUTD
19 PMOD, C11, C12, C15,
C16, R1, R4, R6 to R8,
R10, R11, R14, R16, R20,
VOUT_A to VOUT_D
1 FEC refers to Farnell Electronic Component Distributors.
2 Generic indicates that any device with the specified value, size, and rating can be used.
Description
32 kΩ, I C serial EEPROM (24LC32)
2
150 mA, low quiescent current, CMOS linear regulator
2.5 V precision micropower, low dropout, low voltage reference
Quad, 16-bit nanoDAC+ with 2 ppm/°C on-chip reference and I
interface
Micropower, high accuracy, 5.0 V voltage reference
Capacitor, 0.1 µF, 16 V, 0402
Capacitor, 1 µF, 25 V, X5R
Capacitor, 10 µF, 10 V, tantalum
Capacitor, 1 µF, 16 V, tantalum
Capacitor, 10 µF, 25 V, X5R
Capacitor, 4.7 µF, 25 V, X5R
Capacitor, 0.1 µF, 25 V, X8R
Ferrite bead, 600 Ω
Ferrite bead, 330 Ω
2-pin terminal block
2-pin link/jumper
6-pin link/jumper
Resistor, 1.8 Ω, 5%, 1/10 W, thick film chip
Resistor, 0 Ω, SMD
Resistor, 0 Ω, 5%, 1/16 W, 0603
Resistor, 100 kΩ, 1%, 1/10 W
120-pin female connector
Black test point
White test point
Red test point
Do not insert/do not populate
Rev. C | Page 12 of 13
EVAL-AD5696RSDZ User Guide
Supplier/Part Number
FEC/1331330
Analog Devices/ADP121
Analog Devices/REF192
2 C Analog Devices/AD5696R
Analog Devices/ADR3450
Generic
Generic
Generic
Generic
Generic
Generic
Generic
Generic
Generic
Generic
Generic
Generic
Generic
Generic
Generic
Generic
FEC/1324660 or Digi-Key/H1219-ND
Generic
Generic
Generic
Not inserted
1, 2
